V1. 05/18
A11BM03004
BMW Steering Wheel Control Interface
Vehicle Application
BMW 3 Series (E46) 1998 - 2005
BMW 5 Series (E39) 2000 - 2004
BMW Z4 (E85) 2002 - 2008
BMW Mini (R50/R52)* 2001 - 2006
BMW X5 (E53) 2000 - 2006
*i-Bus Vehicles (Pre CAN-Bus)
Key Features
• Retains Steering Wheel Controls
• Retains Factory Phone Buttons
The information provided in this document is subject to change without notice due to changes and/or
improvements to the product/s.
Advertisement
Table of Contents
Summary of Contents for Setma A11BM03004
- Page 1 V1. 05/18 A11BM03004 BMW Steering Wheel Control Interface Vehicle Application BMW 3 Series (E46) 1998 - 2005 BMW 5 Series (E39) 2000 - 2004 BMW Z4 (E85) 2002 - 2008 BMW Mini (R50/R52)* 2001 - 2006 BMW X5 (E53) 2000 - 2006...
- Page 2 Please ensure that the correct tools are using during the installation to avoid damage to the vehicle or product. SETMA can not be held responsible for the installation of this product.
- Page 3 FITTING GUIDE 1. Remove and disconnect the original head unit. 2. Connect the 12 way molex connector of the head unit patch lead (supplied separately) to the interface. 3. Connect the opposite end of head unit patch lead to the head unit steering wheel control input on the back of the aftermarket head unit.
- Page 4 FITTING GUIDE 6. Connect the female vehicle specific connector on the harness to the male vehicle connector from the vehicle. Test head unit for correct operation. STEERING WHEEL CONTROL FUNCTIONALITY Original Button Function Plus Icon Volume + Minus Icon Volume - Up Arrow Track + Down Arrow...
- Page 5 E02UN00001 Universel Patch Lead Configuration Assignments (1=Link made, O=No Link) Pin Configuration Pin 1 Descrintion Systems Connector Reserved Jack/Keyl Reserved Keyl BEAT/Philips/Nakamichi Reserved Analoa 2 Swc Clarion Jack GND Swc Kenwood Keyl Analog 1 Swc Link J3 Jack Alpine Link J3 Panasonic Keyl Link J2...
