/ GB TABLE OF CONTENTS Technical specifications How to use the caulking gun? - General data Use and maintenance - International norms and standards General safety instructions Drawing of complete gun and charger TECHNICAL SPECIFICATIONS Battery recharging time: max. 45 min (80% charged Weight: approx.
GB / HOW TO USE THE CAULKING GUN? Battery indicator (5) indicates the amount of power The gun is active when the trigger (1) is activated left in the battery: (diode is green). The piston is quickly driven forward Constantly showing green light > 50% to the starting position, then the driving speed is Shifting between red/green >...
Page 4
/ GB USE AND MAINTENANCE be replaced or cleaned of the set or hardened joint IMPORTANT! filler. The nozzle size must be at least 3.5mm – see The warranty is void if the gun is used without the instruction page 5. protective cuff, and if this results in joint filler get- ting onto the piston rod.
GB / USE AND MAINTENANCE Smallest nozzle size: 3.5mm –4mm NOZZLE SIZE: To ensure problem-free caulking, it is recommended that the nozzle size is as big as possible. If caulking is done with a smaller nozzle size, the speed of the gun should be adjusted down to ensure a) that the cartridge/tube does not leak or break, and b) that the gun is not overloaded.
Page 6
/ GB GENERAL SAFETY INSTRUCTIONS Unplug the charger by pulling at the plug instead of at Warning: Use of accessories or equipment other the wire itself. This will minimize the risk of damaging than those recommended in this user manual may the plug as well as the wire.
Page 7
GB / GENERAL SAFETY INSTRUCTIONS WARNING: If leakage of electrolytic liquid occurs, Charge the battery pack in a well-ventilated place. rinse with water/ a neutralizing agent. If the liquid Do not cover the charger and the battery pack with a has come in contact with the eyes, seek medical aid cloth or similar during the charging process.
