- Page 1 Solid Signal shows you... HOW TO DO IT Assemble the Xtreme Signal HDB91X...
- Page 2 Your guide to free HDTV The Xtreme Signal HDB91X antenna from Solid Signal is a great combination of durability and performance. It’s the right antenna for you if you: • Need an outdoor antenna for good reception • Live more than 50 miles away from the broadcast towers •...
-
Page 3: What's In The Box
WHAT’S IN THE BOX Here’s what you should expect to see in the box, shown here from top to bottom: • Two segments with widely spaced elements. • One segment with narrowly spaced elements. • Dipole antenna assembly. • Mount with cable clamp. •... -
Page 4: Before You Start
OPENING THE ELEMENTS The main antenna is almost completely assembled when you get it. All you need to do is separate the antennas (the x-shaped part) from the reflector (the bars with the plastic.) Find the wingnuts roughly halfway between the outer edge of the main antenna and the center and loosen them slightly. - Page 5 OPENING THE ELEMENTS This image shows one of the segments before and after putting the elements in position. When you are done all the segments should look like this. It’s a good idea to get them ready by facing them all the same way and making sure the same side is...
- Page 6 ASSEMBLING THE ANTENNA SEGMENTS The antenna segments are attached with brackets and wingnuts. These brackets may be already attached or they may be in the parts bag. If they are attached, start by loosening the wingnuts attached to the brackets to allow the bracket to spread wide.
-
Page 7: Attaching The Reflectors
ATTACHING THE REFLECTORS The back end of the antenna (where the elements are most tightly spaced) has a wingnut and bolt. Remove these two items and set them aside. Place the reflector brackets on either side of the antenna and connect the bolt and wingnut, leaving it loose. -
Page 8: Attaching The Mount
ATTACHING THE MOUNT mount uses same connection system as the rest of the antenna but the brackets only have one set of holes. This lets you attach the mount anywhere on the antenna for proper balancing. Start by loosening the wingnuts so the bracket can fit around the antenna. - Page 9 ATTACHING THE MAST BRACKET Now, disassemble mast bracket if it is pre-assembled, as shown. Put this part of the bracket on the mount. It mounts sideways. Note at the top of the photo you see the bottom of the antenna. This is to allow it to properly mount to the mast.
- Page 10 FINISHING UP Mount the antenna on a mast by sliding the mast mount over the mast and tightening the clamps onto the mast. Attach your antenna cable to the bottom of the antenna, using the supplied weatherproof boot to shield the connection.
- Page 11 SolidSignal.com is your source for DIRECTV equipment, supplies, and support. We have over 10 years’ experience in installing and supporting satellite equipment. Our technical staff is ready to answer all your questions! visit SOLIDSIGNAL.COM for the best selection of equipment and supplies for the high-end installer or do-it-yourselfer! FORUMS.SOLIDSIGNAL.COM...
