SETUP AND OPERATING INSTRUCTIONS
PRODUCT DESCRIPTION: The 924-DFV Foot Valve is a rugged and easy to use, floor mounted
dispenser

SPECIFICATIONS:

Size .......................................................8" x 5" x 5" (20.3 x 12.7 x 12.7 cm)
Weight ............................................. 4 lbs. (1.82 kg)
Input Pressure .................................... 100 psi max (7 bar)
Operating Pressure ..................................... Up to 100 psi (7 bar)

SETUP AND OPERATION

1. Connect hose assembly to foot valve, then to 100 psi maximum dry filtered air supply
2. Insert quick connect end of Receiver Head assembly (air adapter) of syringe or Production
Master Cap Cartridge assembly into Air Outlet port of the Foot Valve and turn clockwise
until secure.
3. Rotate air regulator knob clockwise to increase dispense pressure. Pressure gauge will
indicate desired pressure setting.
4. Press on the foot valve lever to activate the dispense cycle. Material should flow as long as
the pedal is depressed.
5. The amount of material dispensed per cycle depends on the combination of air pressure,
duration or dispense cycle, viscosity of material, temperature and dispense tip size.
