Bluesky Mount'n Mover Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Download our catalog at:
mountnmover.com/catalog
The Mount'n Mover
wheelchair mounting system
Move it easily and
independently!
no tools required
January 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mount'n Mover and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bluesky Mount'n Mover

  • Page 1 Download our catalog at: mountnmover.com/catalog The Mount’n Mover wheelchair mounting system Move it easily and independently! no tools required January 2019...
  • Page 2 Mount'n Mover community Welcome to the BlueSky Designs is proud to bring you its unique mounting solution. Our Mount is manufactured in the US by the same team that designed it with the input of therapists, people with disabilities and their families.

  • Page 3: Table Of Contents

    Table of Contents Pages: Wheelchair Attachment Plates and Hardware: Wheelchair attachment overview WC-AP Wheelchair Adapter Plate WC-AAP Angle Adjustment Plate WC-LAE L-Angled Extension Plate WC-AP4 Adapter Plate 4 WC-AP2 Adapter Plate 2 WC-AP5 Adapter Plate 5 Wheel Chair Bracket WC-R1 + WC-R7/8 Round Clamp 1”...

  • Page 4: Wheelchair Attachment Overview

    Wheelchair Attachment Overview All plates are considered ‘multi-use plates’ and can be configured, combined, and used in a variety of ways. OPTIONAL OFFSET Anchor to Chair • Round tubing What you use will • Slide track depend on what kind of •...
  • Page 5 Wheelchair Attachment Plates and Hardware...
  • Page 6 Wheelchair Adapter Plate (WC-AP) Multi-Use Plate Scale 1 : 1 Plate to Plate Attachment Options - Non-threaded hole to threaded hole = Good - Non-threaded hole to non-threaded hole with nut = Good 3.0 inches - Threaded hole to threaded hole = Not good ( 76.2mm ) (will damage threads!) Hole Pairing Options...
  • Page 7 Angle Adjustment Plate (WC-AAP) Scale 1 : 1 Plate to Plate Attachment Options 2.40 inches - Non-threaded hole to threaded hole = Good ( 61mm ) - Non-threaded hole to non-threaded hole with nut = Good - Threaded hole to threaded hole = Not good (will damage threads!) 1/4-28 Threaded Holes (Qty = 8) Set Includes:...
  • Page 8 L-Angled Extension Plate (WC-LAE) WC-LAE PLATE being used to offset the Scale 1 : 1 Through Possible solid wheelchair bracket configurations: holes (x4) (WB2) out from chair. 90 degrees 2.625 inches Threaded ( 66.7mm ) holes (x4) ( 1/4-28 ) through hole threaded...
  • Page 9 Adapter Plate 4 (WC-AP4) Multi-Use Plate Plate to Plate Attachment Options Scale 1 : 1 - Non-threaded hole to threaded hole = Good - Non-threaded hole to non-threaded hole with nut = Good 1/4-28 threaded Hole (Qty = 5) - Threaded hole to threaded hole = Not good (will damage threads!) Hole Pairing Options 5/16...
  • Page 10 Adapter Plate 2 (WC-AP2) Multi-Use Plate Plate to Plate Attachment Options - Non-threaded hole to threaded hole = Good 1/4-28 Tapped hole - Non-threaded hole to non-threaded hole with nut = Good (Qty = 4) Threaded hole to threaded hole = Not good (will damage threads!) Hole Pairing Options - Two holes = BEST...
  • Page 11 Adapter Plate 5 (WC-AP5) Multi-Use Plate Plate to Plate Attachment Options - Non-threaded hole to threaded hole = Good Scale 1 : 1 1/4-28 threaded Hole (Qty = 4) - Non-threaded hole to non-threaded hole with nut = Good Threaded hole to threaded hole = Not good (will damage threads!) Hole Pairing Options 5/16...
  • Page 12 Wheelchair Bracket (WB2) 2.39 inches 2.00 inches Mounting (60.8mm) (50.8mm) Scale 1 : 1 holes 1.250” 1.250” Mounting holes 2.75 inches (69.9mm) Set Includes: (1) Wheelchair Bracket (2) 1/4-28 X 0.5” Socket Head Screws Mounting holes change orientation WB2 attached to angle adjustment plate (AAP) Plate has 4 orientations Product: WB2, Wheelchair Bracket...
  • Page 13 Round Clamp (WC-R1) or (WC-R7/8) Scale 1 : 1 Fits 1 inch diameter tube 1.55 inches Channel (39.4mm) captures lock nuts .975 inch (24.8mm) 2.00 inches Fits Close up view (50.8mm) 7/8 inch diameter attached 1.370 tube inches .885 inch (22.5mm) Set Includes: (2) Clamps...
  • Page 14 Round Bridge Clamp (WC-R1B-set) or (WC-R7/8B-set) Scale 1 : 1 1” or 7/8” Fits 1 inch Fits diameter 7/8 inch tube diameter 1.55 inches tube (39.4mm) .885 inch (22 mm) .875 inch 0.96 inch (22.2mm) (24.4mm) Channel is used as a wrench Set Includes: (4) Clamps [1 set -1”] or [1 set-7/8”] (2) 1/4-28 x 2 1/4”...
  • Page 15 T-Nut (WC-TN) (for use with slide track) Scale 1 : 1 T-Nut .375 inch (9.5mm) .625 inch (15.9mm) Set Includes: (1) T-nut (2) 1/4-28 x 5/8” Socket Head Cap Screw Wheelchair Bracket can attach directly to T-Nut T-Nut prior to May of 2015 used 1/4-20 screws Product: WC-TN, T-Nut Weight: 3.0 oz.
  • Page 16 COVED SPACERS 1” (SPACER L) AND 7/8” (SPACER M) Bill of Materials: Nut A • Coved Spacer L (1 inch) set • • Coved Spacer M (7/8 inch) set • Nylon Washer B (x2) • Screw 4E (x2) Washer B •...
  • Page 17 Collar Clamps (Set of two 1” clamps) Mounting on a curve will usually require an WC-AAP (angle adjust) plate to correct the angle to vertical for the WB2 (wheelchair bracket). This will allow the post to be vertical. Collar clamps come in many sizes. If you need a different size we will need to know the WC-AAP...

  • Page 18: Device Plates

    Device Plates...

  • Page 19: Dp-T2

    DP-T2 Attaches to: Devices I-12 and I-15 Device plate DP-T2 to device M4-.7 x 10 mm (X3) 8.824” 3.5” (224.129 mm) (88.86 mm) Quick release plate (QRP) to DP-T2 8-32 x 3/8” (x4) 3.315” (134.82 mm) Foam Product: DP-T2, Tobii Weight: 10.2 oz.
  • Page 20 DP-T2 Tobii I Device Plate Attachment Instructions Place your Tobii face down. Remove the existing plate. Plate removed Place the DP-T2 plate on the device so the two hooks fit into the grooves at the base of the device (see image below left) and the three countersunk holes on the plate align with the three holes on the device where you just removed the original plate (see image below right).
  • Page 21 DP-T2 Attach the Quick Release Plate (QRP) (x4) 8-32 x 3/8” Tobii I device mounted to Mount’n Mover with the quick release plate Attach the QRP to the device plate using the screws from the included bag labeled “QRP to DP-T2 Available option using the Universal Rotator (DP-UR) in addition to the QRP.

  • Page 22: Dp-Multi1

    DP-Multi1 Mobi (Jabbla) Tellus (Jabbla) Mobi/Tellus//Rolltalk/AMDI/Tobii Dynavox Attaches to: Eyemobile (Mini)/VESA (50,75,100mm)/ Smartbox Mobi (Jabbla) (Screw (Nylon Spacer M4-.7 x 16mm length 3/8” OD x 1/8” thick Tellus (Jabbla) (same 4 screws [NNN] and 4 spacers [H] as Mobi) Rolltalk (Abilia) AMDI Rolltalk (Abilia) (Steel washer...

  • Page 23: Dp-Dv1

    Attaches to: DP-DV1 Maestro, V, Vmax, M3, and T10 (Contact us for other models) Maestro to device plate 8-32 x 1” (x3) 1/4”ID x 1/2”OD x 5/8”L (x3) V & Vmax to device plate 8-32 x 3/8” (x2) DV4 & MT4 to device plate M4 x 16mm (x4) M4 x 14mm (x2)
  • Page 24 DP-DV1 Stand for V or Vmax is no longer usable once device Maestro plate is in place Vmax align spacers attach device plate 8-32 x 3/8” (x2) attach device plate attach 8-32 x 1” (x3) quick release plate 8-32 x 1/4” (x4) attach quick release...
  • Page 25 DP-DV1 Dynavox T10 Order T10 with Mount Plate (not supplied by BlueSky Designs) QRP to device plate 8-32 x 1/4 “ (x4) Device plate Requires Dynavox part: to T plate Mount Plate for ConnectIT (item #502139) 8-32 x 1/4 “ (x3)

  • Page 26: Dp-Prc1

    DP-PRC1 Attaches to: ECO2, ECOpoint (with eyegaze) ECO-14, Vanguard, Pathfinder 2 and Accent 1400 Device to device plate 8-32 x 5/8” flathead (x4) 8-32 x 3/8” panhead (x4) 6/32 x 1/2” Flat Head (x4) Quick release plate (QRP) to device plate 8-32 x 1/4”...
  • Page 27 DP-PRC1 ECO 2 and ECOpoint (with eyegaze) *For all models, the original Leave mounting plate screws should mounting be removed first. plate in place mounting plate Attach 8-32 x 5/8” device plate Mount QRP lower when attaching to ECOpoint (eye gaze) 8-32 x 1/4”...
  • Page 28 DP-PRC1 PRC Accent 1400 Place DP-PRC1 over the Accent 1400 Remove screws from mounting bracket. Leave mounting bracket in place. mounting bracket. Line up the four holes between the two plates and the Accent 1400. Attach using the four screws provided (6/32 x 1/2”). cont.

  • Page 29: Dp-Ur

    DP-UR Universal Rotator Attaches to: All Mount’n Mover device plates and trays Universal rotator to device plate or tray (These screws are not provided with Universal Rotator; Provided with device plate) 8-32 x 1/4” Flathead Screws (x4) Loosen knob, rotate plate 45 degrees to expose holes for attachment to device plate or...
  • Page 30 DP-UR Universal Rotator To adjust rotation: Attach device plate to device 1. Loosen knob (shown with Dynavox Eyemax) 2. Rotate device 3. Tighten knob 1. Loosen knob Screw QRP to UR. 3. Screw UR to (screws included 2. Rotate plate to expose device plate with QRP) device attachment holes...
  • Page 31 DP-QCP Quick Connect Plate DP-QCR Quick Connect Receiver Angled slots in the DP-QCR line up with angles on the edges of the DP-QCP. The DP-QCR slides onto the DP-QCP starting from the bottom. Slide the DP-QCR up until it “clicks” into the lock position. Attach the Quick Release Plate (QRP) to the Quick Connect Receiver (QCR) See page 27.
  • Page 32 Easy Mover Instructions To Tighten or Loosen Joints Elbow Joint Shoulder Joint Wrist Joint Use a 3/16 inch Hex Wrench with a ball end (included) Attach the Quick Connect Receiver (QCR) to the Quick Connect Plate (QRP) Grooves Screws enter from this side! Quick Connect Receiver (QCR) and the Quick Release Plate (QRP).
  • Page 33 Mount n Mover TableClamp Assembly • Use...
  • Page 34 Simple Mount - Small and Large CAUTION! Lip Supports Do not loosen Caution! Do not use Simple Mount or remove bolt! as a lift support Small (3.5” x 7.0” x .25”) Simple Mount Small includes 1 Lip Support Simple Mount 1/2”...
