ZEP 430 Operating & Maintenance Instructions

Self-contained carpet extractor
Hide thumbs

Advertisement

Quick Links

Download this manual
430 SELF-CONTAINED
CARPET EXTRACTOR
INTRODUCTION
This operator's book has important information for the
use and safe operation of this machine. Read this book
carefully before starting the machine. Keep this book
and tell all operators to read the book. If you do not
follow the instructions, you can cause an injury or dam-
age equipment, furniture or buildings.
For new books write to:
Zep Inc. - Equipment Division
1340 Seaboard Industrial Blvd.
Atlanta, GA 30318
Carefully inspect all components to ensure that there is
no concealed freight damage. If such damage is dis-
covered, file a "CONCEALED DAMAGE REPORT" im-
mediately with the delivering carrier.
OPERATING & MAINTENANCE
READ THIS BOOK
The contents of this manual are based on the latest
product information available at the time of publication.
Pacific Steamex reserves the right to make changes or
improvements to its machines without notice.
FOR YOUR CONVENIENCE, RECORD THE
FOLLOWING INFORMATION:
MODEL_______________________________
SERIAL NUMBER______________________
PART NUMBER _______________________
DATE PURCHASED ____________________
INSTRUCTIONS
