Cycle Satiator Programmable Charger - Quick Start Guide

Advantages of using the Cycle Satiator charger:

- Graphical OLED display: Provides realtime and historical information
- Select from multiple charging programs
- Fast charge setting: Up to 70% faster than the stock charger
- Partial charge setting: Dramatically improve battery lifespan
- Watertight,Vibration resistant and fan-less design: made to be carried on the bike
- Programmable and Firmware upgradable

How to use the Cycle Satiator for the First time:

1. Plug the AC cable into the AC Input Jack of the Charger.
2. Connect the DC Output Cable into the Charger and turn the outer ring clockwise to lock the
connector in place.
3. Plug the AC Cable into an electric outlet. The charger will power up.
4. On the first charge, push the lower button for 3 seconds. The Display Screen will show
"FORCE START"
5. Plug the 4 pin connector into the battery.
6. Check the display to see if the Charger is charging.
If the charger is not charging, Disconnect the charger from the bike and try again from Step 4.
The charger may not start if the battery is already full.
Selecting a Charging Profile:
1. Disconnect the charger from the battery
2. Hold the upper button for 3 seconds and release to enter the list of charging profiles
3. Use the upper and lower buttons to scroll through the list of 5 charging profiles.
4. To enter a particular charging profile, hold the lower button for 3 seconds.
5. Connect the battery and the charger will start charging
Juiced Riders Electric Bikes
1055 Bay Blvd, Suite F, Chula Vista, CA 91911
Tel: 619-746-8877 /
www.JuicedRiders.com
/ mail@juicedriders.com
R20151014
