Summary of Contents for 42FOUNDRY ETCH
- Page 3 quick installation guide...
- Page 4 Descriptions USB port for light Button for manual settings Wire for wall-mounting Openings for aluminium freestanding Threaded opening for plexiglas support for freestanding setup ETCH Clock back side...
-
Page 5: Power Supply
Power supply To connect the ETCH Clock please plug the connector into the power entry that is located at the bottom behind the clock. Now there are two ways to install the clock: it can hang on the wall, or standing . - Page 6 Wall hanging setup Hanging on the wall, the power cable can be just pending down toward a power socket (Fig. A). If there is a wall power supply available on the wall directly behind the clock, the cable can be hidden behind. Eventu- ally the cable can be shortened or cut.
- Page 7 If you choose the plexiglas support, please remove the protective film from the feet starting at the corner. With the provided screws, fix the feets at the bottom of the ETCH Clock aluminium frame, where there are two threaded openings. fig. A...
- Page 8 After plugging the power cable, the clock start displaying numbers. By default ETCH Clock is set to Central European Time. It is better if you setup the ETCH Clock the first time through the dedicated application “ETCH Sync Time” available via Apple Store or Google store.
- Page 9 When I plug the ETCH Clock it display weird numbers, why? When you plug the power, the clock might be in the mid- dle of a display sequence, thus the first displayed time will show random segments. After this first sequence, the next will be correct.
-
Page 10: Warranty
Do not place ETCH Clock in greasy areas like industrial kitchens, very small kitchen with bad ventilation,etc. ETCH Clock should never be exposed to direct sunlight, very high or very low temperatures, moisture or strong vibrations. Normal temperature range for operating are between 15 °C and 30 °C. -
Page 11: Technical Support
Technical support If you need any technical support, please contact us: tech@42foundry.com SUPPORT US If you like our project, and you want to support us, please drop us a mail: johnny@42foundry.com... - Page 12 www.etchclock.com follow us a product of...
-
Page 13: Technical Data
Technical data: Dimensions Body: 400 x 400 x 55 mm Acrylic supports: 80 x 120 x 10 mm Aluminium supports: 120 x 8 mm Plug Input: AC 110-230 V. Max 0.2 Amp Internal DC: 5 V, max 3 Amp Mean power: less than 10W Input frequency: 45 to 65 Hz... - Page 14 42FOUNDRY SA Via Cassarinetta 2 6900 Lugano Switzerland email: johnny@42foundry.com...
