Summary of Contents for Rolbak NGD2118
- Page 1 ASSEMBLY INSTRUCTIONS NGD2118...
- Page 2 THANK YOU! Thank you for your purchase of this Rolbak product. We work around the clock and around the globe to ensure that Rolbak products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact your retailer to submit parts requests or warranty claims.
- Page 3 WARNINGS!
- Page 4 TABLE OF CONTENTS...
- Page 5 PARTS IDENTIFIER (NOT TO SCALE)
- Page 6 ASSEMBLY INSTRUCTIONS PART 1 - ATTACHING THE ROLBAK NET | METHOD A - EXTENSION ARM ATTACHMENT 1. Assemble three pieces of Square Black Tubes to form Lower Support Tube. Attach Tubes using two Hex Head Screws and the Small Hex Wrench supplied.
- Page 7 METHOD A - EXTENSION ARM ATTACHMENT 10. Join the three Round Silver Tubes together-swaged ends fit into one another and lock forming one Assembled Tube. 11. Slide Assembled Tube through the opening at the top of the Rolbak Net Header.Assembled Tube.
- Page 8 METHOD A - EXTENSION ARM ATTACHMENT 13. Insert square end of Pipe Insert Bracket into one open end of Lower Support Tube. Place circular end of Bracket into Assembled Tube/Rolbak Net Header below. Lock into place with Locking Pin. (PG. 14)
- Page 9 ASSEMBLY INSTRUCTIONS (CONT.) PART 1 - ATTACHING THE ROLBAK NET | METHOD B - RIM MOUNTING BRACKETS 1. Assemble three pieces of Square Black Tubes to form Lower Support Tube. Attach Tubes using two Hex Head Screws and the Small Hex Wrench supplied.
- Page 10 METHOD B - RIM MOUNTING BRACKETS 7. Join the three Round Silver Tubes together-swaged ends fit into one another and lock forming one Assembled Tube. 8. Slide Assembled Tube through the opening at the top of the Rolbak Net Header.
- Page 11 METHOD B - RIM MOUNTING BRACKETS 10. Insert square end of Pipe Insert Bracket into one open end of Lower Support Tube. Place circular end of Bracket into Assembled Tube/Rolbak Net Header below. Lock into place with Locking Pin. (PG. 14)
- Page 12 ASSEMBLY INSTRUCTIONS (CONT.) PART 1 - ATTACHING THE ROLBAK NET | METHOD C - SADDLE BRACKET Call 800-759-0977 for part 1. Assemble three pieces of Square Black Tubes to form Lower Support Tube. Attach Tubes using two Hex Head Screws and the Small Hex Wrench supplied.
- Page 13 4. Join the three Round Silver Tubes together-swaged ends fit into one another and lock forming one Assembled Tube. 5. Slide Assembled Tube through the opening at the top of the Rolbak Net Header. 7. Insert square end of Pipe Insert Bracket into one open end of Lower Support Tube. Place circular end of Bracket into Assembled Tube/Rolbak Net Header below.
- Page 14 ASSEMBLY INSTRUCTIONS (CONT.) PART 2 - SECURING THE NET BASE | METHOD A - SAND BAG (PG. 16)
- Page 15 ASSEMBLY INSTRUCTIONS (CONT.) PART 2 - SECURING THE NET BASE | METHOD B - WATER BAG (PG. 16)
- Page 16 SUGGESTED USAGE For longer system life, disassemble and store your Rolbak Return Net during winter months.
