Knape & Vogt KD-100 Quick Start Manual

Keyboard Trays
Carton should contain the keyboard tray subassembly and a hardware kit consisting of:
4- height adjustable mounting brackets
4- #8 x ⁄ " self-tapping screws for mounting brackets to tray assembly
1
4
8- #8 x 5 ⁄ " wood screws for mounting keyboard tray to desktop
8
1- AMN mouse tray assembly and installation hardware (KD-110 ONLY)
Assembly, Mounting and Installation
Instructions
Minimum Space Requirements:
23" wide x 17" deep x 2
Step 1. Determine desired keyboard drop
height.
Measure the maximum height of the keyboard that
you will be using. Compare keyboard height with
the adjustment heights in Chart A to determine at
what height position the mounting brackets need to
be installed.
Chart A Max. Keyboard Height (inches)
position 1
position 2
position 3
position 4
position 5
position 6
position 7
Alternatively, you may use Chart B and figure 1 to
1 ⁄ " high
2
3.60
3.38
3.15
2.93
2.70
2.48
2.25
determine what tray height is desired to allow prop-
er knee clearance or chair clearance underneath
the keyboard tray after installation.
Chart B Height Loss Under Surface (inches)
position 1
position 2
position 3
position 4
position 5
position 6
position 7
Desk top
KD-100/KD-110
3.78
3.56
3.33
3.11
2.88
2.66
2.43
Height loss
Height from
floor to
Desired underneath
surface
Clearance
Floor
