High End Soundboard nuPro XS-7500
QUICK START
GUIDE
You can find the most recent version of the operating manual here: www.nubert.de/downloads/61/
1
Mounting the out-rigger feet
!
Caution!
Be careful not to scratch the loudspeaker!
Don't let any items fall into the bass reflex ports!
Place the speaker upside down on a soft, non-scratching surface!
Place the out-rigger feet over the threaded bushings as shown in the
picture and mount the feet securely with the supplied bolts and hex
key. You can now turn the loudspeaker around, place it on its feet
and adjust the mini-spikes for a level, stable stand.
Mounting kit with one pair of out-rigger feet
1x hex key
socket screws
2x Out-rigger feet
nuPro XS-7500 · Quick Start Guide · 11/2019
Mini-spike
4x hex
Standard mounting:
out-rigger feet pointing outwards
Alternative mounting:
out-rigger feet pointing inwards.
Standard mounting:
out-rigger feet pointing outwards
Alternative mounting:
out-rigger feet pointing inwards
This method is recommended if the XS-7500 needs to be placed on
a narrow surface or if heavy objects (more than 50 kg's) needs to be
placed on the soundbase.
1
®
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Nubert nuPro XS-7500
Summary of Contents for Nubert nuPro XS-7500
-
Page 1: Quick Start
GUIDE Standard mounting: out-rigger feet pointing outwards Alternative mounting: out-rigger feet pointing inwards. You can find the most recent version of the operating manual here: www.nubert.de/downloads/61/ Mounting the out-rigger feet Caution! Standard mounting: Be careful not to scratch the loudspeaker! out-rigger feet pointing outwards Don’t let any items fall into the bass reflex ports! - Page 2 The remote control has 6 buttons for source selection. Pressing a key repeatedly toggles between its two sources as shown below: Coaxial 1 Wireless coax Bluetooth Coaxial 2 Optical 1 opto analog Optical 2 Digital Port nuPro XS-7500 · Quick Start Guide · 11/2019...
- Page 3 0000. On the selected speaker itself, you will see a blinking Nubert logo. Tap on the Nubert logo in the top left corner of the app to return to the main menu. If you have selected the slave-speaker, an error message will appear –...
- Page 4 The device transmitting the signal is the Master, the device receiving the signal is the Slave. On some devices, this setting is fixed, others, like the nuPro XS-7500, are freely configurable. For more details, please see the setup section in the owner’s manual, on page 11.
