Kreg KPDGB Manual

WARNING:
This product can expose you to chemicals including Carbon 1333-86-4 and other chemicals
which are known to the State of California to cause cancer and reproductive harm. For more information go to
www.P65Warnings.ca.gov.
WARNING:
Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance
known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards
for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
STEP 1.
Use the cams to attach the base to the
small clamp pad of your Kreg face clamp.
STEP 2.
Slide the drill guide from your Kreg Jig
the portable base. Align the mark on the side
of the drill guide that matches the thickness
of the workpiece with the top edge of the
portable base. Screw in the locking pin.
STEP 3.
Clamp the jig to your workpiece and
drill the pocket holes.
contact us through our Website or call Customer Service.
Customer Service • Service à la clientèle • Servicio al cliente
PORTABLE BASE
For assistance with any Kreg product,
www.kregtool.com
800.447.8638
ITEM# KPDGB
into
®
NK8696
Version 3 - 04/2018
