IPS 10 000
Commissioning
English
005843 / 1.0.3 / 2018-12-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPS 10 000 and is the answer not in the manual?

Questions and answers

Related Manuals for dallmeier IPS 10 000

Summary of Contents for dallmeier IPS 10 000

  • Page 1 IPS 10 000 Commissioning English 005843 / 1.0.3 / 2018-12-19...
  • Page 2 All trademarks identified by ® are registered trademarks of Dallmeier electronic. Third-party trademarks are named for information purposes only. Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights.
  • Page 3 2× 2× 2× 1× 6× 32×...

  • Page 5: Table Of Contents

    IPS 10 000 Inhalt 1 Validity 2 Documents This Document Other Applicable Documents 3 Typographical Conventions 4 Safety Instructions 5 General Notes Scope of Delivery Transportation and Packaging Warranty Appropriate Use Approvals/Certifications Note (USA) 6 Requirements 7 Rack Installation Dimensions Preparation Mounting 8 HDD Mounting...

  • Page 6: Validity

    Always follow the contained instructions, notes and warnings and ob- serve the technical specifications. Keep all documents in legible condition and in a suitable location for future reference. Regularly check the website www.dallmeier.com for the latest updates on product documentation. www.dallmeier.com...

  • Page 7: This Document

    IPS 10 000 This Document Commissioning The document “Commissioning” (this document) contains detailed de- scriptions on installation, connection and commissioning of the device as well as safety instructions and general notes. The target audience of this document is trained system integrators.

  • Page 8: Typographical Conventions

    IPS 10 000 Typographical Conventions This document may contain various warning words and symbols that indicate potential sources of danger:  DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.  WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 9 IPS 10 000 For reasons of clarity and readability, various text formatting elements and types of emphasis are used in this documentation: Instructions are indicated by arrows (➡). Bold and italic expressions generally indicate a control element on the device (switches or labels) or on its user interface (buttons, menu items).

  • Page 10: Safety Instructions

    Modifications Do not make any modifications to the hardware or software that have not been tested and approved by Dallmeier. Inappropriate modifications may cause malfunctions, damages and data loss and may result in the loss of warranty.
  • Page 11 Keep all documents in legible condition and in a suitable location for future reference. Regularly check the website www.dallmeier.com for the latest updates of the product documentation. Condensation Water If the device is brought from a cold to a warm environment, resulting con- densation water may cause malfunctions and damages.
  • Page 12 IPS 10 000 Operating Conditions Unfavorable operating conditions may shorten the life of the device and may cause malfunctions, damages and data loss and may result in the loss of warranty. Observe the specifications given in the technical data, the operating con- dition requirements and the maintenance instructions.

  • Page 13: General Notes

    IPS 10 000 General Notes Scope of Delivery Included in the standard scope of delivery is: •  1× SMAVIA Appliance IPS 10 000 •  1× 19-inch rack mount kit (for fixed installation): 2× Side mount fixing rail 2× Rear mount fixing bracket (L-shaped with threaded pin) 6×...

  • Page 14: Transportation And Packaging

    IPS 10 000 Transportation and Packaging Store the original packaging for later transportation. Dallmeier is not responsible for any damage resulting from unprofession- al/improper transportation. The device should only be shipped in the original packaging. If the original packaging is no longer available, ensure that the used pack- aging sufficiently protects the device against damage, moisture, heat and cold.

  • Page 15: Approvals/Certifications

    • RCM • UL • DIN 50130-4 compliant Visit www.dallmeier.com for possible updates. Note (USA) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a commercial environment.

  • Page 16: Requirements

    IPS 10 000 Requirements The device is designed for mounting and operation in a 19'' standard rack with active ventilation. The required rails are included in the scope of delivery. Rack Installation ➡ Ensure a free space of at least 60 cm at the front of the rack in order to be able to fully open the door.
  • Page 17 IPS 10 000 Power Supply ➡ Operate the device with 100/240 V AC, 50/60 Hz. ➡ Use an uninterruptible power supply (UPS) to protect the device from voltage spikes and to keep it in operation in case of power failure. NOTICE...

  • Page 18: Rack Installation

    IPS 10 000 Rack Installation The installation and commissioning of the device may only be carried out by qualified personnel. The following tools are needed for the installation: • Cross recess screwdriver (5 mm) • Star screwdriver (T10) Dimensions 442 mm (17.4")

  • Page 19: Preparation

    IPS 10 000 Preparation ➡ Use the 19" rails included in the scope of delivery. ➡ Shorten the rails if necessary. 6× ➡ Align the guidance of the rails to the rear side. ➡ Align the rails according to the depth of the rack.

  • Page 20: Mounting

    IPS 10 000 Mounting ➡ Mount the 19'' brackets at the rear side of the rack. ➡ Ensure that the guidances face towards the inner side.  CAUTION Risk of injury due to heavy weight ➡ Ensure that at least two persons are available for the installation of the device (holding/mounting).

  • Page 21: Hdd Mounting

    The device has to be equipped with six identical hard disk drive at least to ensure the required storage speed. Note that all installed hard disks • have to be tested and released for installation by Dallmeier (see HDD whitelist at www.dallmeier.com). • must not be formatted or partitioned.
  • Page 22 IPS 10 000 ➡ Place the HDD tray on the bottom side of the HDD. ➡ Ensure that the connections of the HDD are positioned at the rear side of the HDD tray. ➡ Ensure that HDD and HDD tray are flush at the rear side.
  • Page 23 IPS 10 000 ➡ Slide the HDD tray back into the appliance housing. ➡ Ensure that the HDD tray and housing are flush. ➡ Lock the HDD tray with the key. The HDD will be initialized and set into operation during the first start of the device.

  • Page 24: Indicators

    IPS 10 000 Indicators Information and status messages are output with a display and status LEDs on the front side of the device. The hard disk drives can be accessed with the integrated HDD trays. A B C D E F G Hard disk drive 1 3,5" HDD on HDD tray Power (blue) Always lights up while the device is switched on.
  • Page 25 IPS 10 000 A B C D E F G Serial number Status hard disk drives 1 to 8 HDD is active and OK HDD is defective HDD is not active and OK (RAID spare HDD) HDD is in recovery process (RAID) HDD is not mounted...

  • Page 26: Connections

    IPS 10 000 10 Connections The connections can differ depending on the ordered equipment or variant. A B C D E F G H I J K L M N O P Q R S Power Supply Unit 1 Video OUT Interface IEC C14 socket, 115/230 V AC ±5%, 50/60 Hz DVI-D, Dual Link (24 + 5), 1920 × 1080 (configuration) Power Supply Unit 2 Ethernet Interface 2 IEC C14 socket, 115/230 V AC ±5%, 50/60 Hz RJ45, 10/100/1000 Mbps (optional)
  • Page 27 IPS 10 000 1 2 3 4 5 Serial interface (J) D-SUB, 9 Pins 6 7 8 9 Assignment Assignment Pin Assignment DCD (Data Carrier Detect) DTR (Data Terminal Ready) RTS (Request to Send) RxD (Receive Data) CTS (Clear to Send) TxD (Transmit Data)

  • Page 28: Commissioning And Local Login

    IPS 10 000 11 Commissioning and Local Login Commissioning ➡ Connect the device to the voltage supply. ➡ Ensure that a monitor and a mouse are connected. ➡ Switch on the monitor and the device. The user interface is displayed in the initial state as soon as the start is complete.
  • Page 29 IPS 10 000 ➡ Click the Login button. ➡ The Recorder Login dialog is displayed. ➡ Click Later to login without changing a password. The configuration interface is displayed. ➡ Refer to the corresponding “Configuration” documentation. www.dallmeier.com...

  • Page 30: Commissioning And Remote Login

    IPS 10 000 12 Commissioning and Remote Login Commissioning ➡ Connect the device to the network. ➡ Connect the device to the power supply. ➡ Switch on the device. The device is ready for remote configuration via Ethernet as soon as the startup is complete (up to approx.
  • Page 31 IPS 10 000 ➡ Enter the serial number (e.g. DAX5-12345678) as the Password. ➡ Confirm with Login. The configuration interface is displayed. The configuration interface is compressed for narrowband connections before transmission if the Slow Network check-box is activated. ➡ Refer to the corresponding “Configuration” documentation.

  • Page 32: Specifications

    IPS 10 000 13 Specifications Components Multi-Core 16 GB Flash module 8 GB (for operating system and application) Hard disks Up to 8× 3.5" HDD (optional) 3× with automatic speed adaptation Power supply unit 1 Integrated Power supply unit 2 Integrated Power supply unit 3...
  • Page 33 IPS 10 000 Electrical Data Voltage supply 115/230 V AC ±5%, 50/60 Hz Power consumption Max. 230 W Thermal output Max. 785 BTU/h Mechanical Data Dimensions (W × H × D) Approx. 483 × 133 × 533 mm (19.0 × 5.3 × 21.0 inches) Weight Approx. 20 kg (44 lbs) with 8 HDDs...

  • Page 34: Maintenance

    IPS 10 000 14 Maintenance The device may only be opened by qualified personnel for commission- ing, inspection, maintenance and repair.  WARNING Danger of electric stroke The device is equipped with redundant power supply units. ➡ Ensure that all supply lines are disconnected from the supply circuit.
  • Page 35 IPS 10 000 Notes www.dallmeier.com...
  • Page 36 Dallmeier electronic GmbH & Co.KG Bahnhofstr. 16 · 93047 Regensburg · · Germany Phone +49 941 87 00-0 · Fax +49 941 87 00-180 www.dallmeier.com · info@dallmeier.com...
