Campbell Hausfeld TL0535 Operation Instructions Manual

See Warranty on page 4 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
Professional air powered cut-off tools
are air tools designed for a variety of
cutting applications, and can be used
on many metals. Used for cutting
rusted exhaust bolts, auto panels and
various home projects.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit.
Safety Guidelines
This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Danger indicates an
imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates a
potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
General Safety
Information
CALIFORNIA PROPOSITION 65
This product can
expose you to
chemicals including lead, which are
known to the State of California to
cause cancer and birth defects or other
reproductive harm. For more
information go to www.P65Warnings.
ca.gov.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2019 Campbell Hausfeld
A Marmon/Berkshire Hathaway Company
Air Cut-Off Tool
You can create dust when you
cut, sand, drill or grind materials
such as wood, paint, metal, concrete,
cement, or other masonry. This dust often
contains chemicals known to cause cancer,
birth defects, or other reproductive harm.
Wear protective gear.
ILLINOIS LEAD POISONING
PREVENTION ACT
CONTAINS LEAD.
MAY BE HARMFUL
IF EATEN OR CHEWED. COMPLIES WITH
FEDERAL STANDARDS.
This product is part of a high pressure
system and the following safety
precautions must be followed at all
times along with any other existing
safety rules.
1. Read all manuals included
with this product care-fully.
Be thoroughly familiar
with the controls and the
proper use of the equipment.
2. Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool.
Do not exceed the
maximum oper-ating
pressure of the air tool (90 psi). This can
reduce the life of the tool.
3. Do not exceed any pressure rating
of any component in the system.
Maximum operating pressure of 90
psi is measured at the tool inlet
while the tool is running. The
pressure drop between the
compressor and tool needs to be
compensated for at the compressor.
4. Disconnect the air tool from air
supply before changing tools or
attachments, servicing and during
non-operation.
Safety
glasses and
ear protection must be worn
during operation.
For parts, product & service information
visit www.campbellhausfeld.com
5. Do not wear loose fitting clothing,
scarves, neck ties or jewelry when
operating any tool. Loose clothing
or jewelry may become caught in
moving parts and result in serious
personal injury.
6. Do not depress trigger when
connecting the air supply hose.
7. Always use attachments designed
for use with air powered tools. Do
not use damaged or worn
attachments.
8. Never trigger the tool when not
applied to a work object. Attach-
ments must be securely attached.
Loose attachments can cause serious
injury.
9. Protect air lines from damage or
puncture.
10. Never point an air tool at oneself or
any other person. Serious injury
MANUAL could occur.
11. Check air hoses for weak or worn
condition before each use. Make
sure all connections are secure.
from the system before
attempting to install, service,
relocate or perform any
maintenance.
12. Keep all nuts, bolts and screws tight
and ensure equipment is in safe
working condition.
13. Do not put hands near or
under moving parts. Keep
hands off guard when
operating. Do not operate
tool without guard
properly secured.
14. Always secure workpiece in a vise or
clamp.
exposure to vibration, work in awkward
positions and repetitive work motions can
cause injury to hands and arms. Stop using
any tool if discomfort, numbness, tingling
or pain occur, and consult a physician.
AT2000, TL0535
Release all
pressure
Do not misuse this
product. Excessive
IN248104 1/19
