BEFORE YOU START:
WARNING: Don't overestimate your technical capacities. This stem must
be fitted by a competent cycle mechanic using the correct tools. Incorrect
installation could result in loss of steering control that could cause serious
or fatal injuries.
•
Ensure the handlebar clamp area is clean and dry (NO GREASE!)
•
Remove all bolts from the stem and apply a small amount of grease
to the threads and under the head of the bolt.
PRODUCT SPECIFICATION:
•
Compatible with: 2009 FOX40 forks and onwards.
All Rock Shox Boxxer forks. 2013 Marzocchi 888 and onwards.
All Marzocchi 380 forks.
•
Handlebar clamp diameter : 31.8mm (oversize) only
•
Bar position: 40 or 50mm reach - 18mm rise above upper crown top face
TOOL REQUIRED:
5mm allen key, torque wrench required.
NOTE:
•
All bolts used in the crown are custom made for Hope.
•
Do not use any lower strength bolts.
•
Do not use shorter bolt length than the one specified here.
•
Full thread engagement is required.
MAINTENANCE:
•
Periodically check the hardware for tightness.
•
Be careful not to over-tighten the bolts!
•
Periodically regrease hardware using appropriate grease.
•
Regulary inspect all parts of the stem for damage and cracks,
especially after any BIG CRASH!
WARRANTY:
All Hope Technology components are covered for two years from original date of purchase
against manufacturer defects in material and workmanship.
Proof of purchase is required. Products must be returned to the original place of purchase or to
Hope Technology to process any warranty claim. Please print and fill the "goods returned form"
found on the tech support section of our website should you wish to send a product back.
This warranty does not cover any damage caused through normal wear, mis-use or failing
to comply by the recommendations given. This warranty does not affect your statutory rights.
HOPE TECHNOLOGY
Hope Mill
Barnoldswick,
Lancashire
BB18 5PX, United Kingdom
info@hopetech.com
40mm
50mm
40mm/50mm DIRECT MOUNT STEM
INSTALLATION GUIDE
info@hopetech.com
NOTES:
hopetech.com
hopetech.com
Advertisement
Related Manuals for Hope DIRECT MOUNT STEM
Summary of Contents for Hope DIRECT MOUNT STEM
- Page 1 Proof of purchase is required. Products must be returned to the original place of purchase or to Hope Technology to process any warranty claim. Please print and fill the “goods returned form” found on the tech support section of our website should you wish to send a product back.
- Page 2 Remove the existing stem if present STEP 2: STEP 2: Install the direct mount stem on the top of the upper crown and thread Install the direct mount stem on the top of the upper crown and thread in by hand the 2x M6x18mm bolts in by hand the 4x M6x18mm bolts.
