User's Manual
Docking Station
TS-DPD6N
(Version 1.3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-DPD6N and is the answer not in the manual?

Questions and answers

Related Manuals for Transcend TS-DPD6N

Summary of Contents for Transcend TS-DPD6N

  • Page 1 User’s Manual Docking Station TS-DPD6N (Version 1.3)

  • Page 2: Table Of Contents

    4. Frequently Asked Questions..................... 16 5. Recycling and Environmental Protection.................17 6. Two-year Limited Warranty......................18 6-1 Limitations.......................... 18 6-2 Transcend Warranty Policy..................... 18 7. GNU General Public License (GPL) Disclosure..............19 8. End-User License Agreement (EULA)..................19 9. Federal Communications Commission (FCC) Statement.............22...

  • Page 3: Introduction

    1. Introduction 1-1 Docking Station Overview Transcend’s DPD6N networked docking station is designed specifically for the DrivePro™ Body 30/60 and offers a complete charging, data upload, and camera management solution. Users are allowed to effortlessly charge multiple DrivePro™ Body 30/60 devices at one go, while files (including video recordings and snapshots) may also be shared to an external storage device via a USB port.
  • Page 4 Back View Power Switch Power Supply (ON/OFF) (19V/3.42A) Functions & Description  Six charging ports:  The six ports allow for up to six DrivePro Body cameras to charge and upload at the same time.  LED Power Indicator:  When connected to a power supply source, turn the Power Switch on. The LED Power Indicator will begin by first slowly flashing red, before turning solid red when the connection is finished.

  • Page 5: Package Content

    Functions & Description  LAN port:  For administrative setup  Fixed IP  WAN port:  For data transmission (via network connection)  IP can be modified  USB 3.0 port:  For exporting data to an external storage device (via USB cable) ...
  • Page 6 Ethernet cables (2 pcs) Power adapter Quick Start Guide...

  • Page 7: Installation Guide

    2. Installation Guide 2-1 Getting Started When installing your DPD6N for the first time, please follow the steps below: 1. Plug in the power adapter and turn the power switch on. 2. Connect one Ethernet cable from the LAN port to the computer’s Internet port.
  • Page 8 3. Connect the other Ethernet cable from the WAN port to an active Internet port. 4. Be sure to have both the LAN port and the WAN port connected to their respective internet ports, before proceeding to the next step. If either one of the two cables is not plugged in, auto backup setup will fail.
  • Page 9 7. Enter the default user name “admin” and password “12345678” to log in.

  • Page 10: Administrative Setup

    2-2 Administrative Setup After logging in as administrator, complete the instructions on the web page:...
  • Page 11 Select “Network” for backing up to a regional network space. Entering of storage location and ID information is required. If you encounter problems while installing the DPD6N, please check Transcend’s FAQ page at: https://www.transcend-info.com/Support/No-786) 3.
  • Page 12 Setup is complete. Start charging the DrivePro™ Body and uploading data simultaneously.

  • Page 13: Reset Device

    2-3 Reset Device To reset the DPD6N or when the login password is forgotten, click on “Reset Device”.

  • Page 14: Firmware Update

    1. Open your browser. Link to Transcend’s Support & Download website at: www.transcend-info.com/support/service. 2. Find the firmware update file for TS-DPD6N Docking Station. Download and unzip. 3. Connect one Ethernet cable from the LAN port to the computer’s Internet port.
  • Page 15 7. If the update is successful, you will see the image below.

  • Page 16: Specifications

    Certification CE, FCC, BSMI, C-Tick, KC 2-Year Limited Warranty Warranty * Please access the Transcend website for more information about the Transcend Warranty Policy. Desktop or notebook computer with an Internet port, and one of the following operating systems:  Microsoft Windows 7 System Requirements ...

  • Page 17: Frequently Asked Questions

    DPD6N for repair. If you cannot find any ideal solution to your question below, please consult your dealer, service center, or local Transcend branch office for further help. You can also visit the Transcend website (http://www.transcend-info.com/) for more FAQs and Technical Support services (http://www.transcend-info.com/Support/contact_form).

  • Page 18: Recycling And Environmental Protection

    5. Recycling and Environmental Protection Recycling the Product (WEEE): Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When you see the crossed-out wheel bin symbol attached to a product, it means that the product is covered by the European Directive 2002/96/EC: Never dispose of your product with other household waste.

  • Page 19: Two-Year Limited Warranty

    Transcend Warranty Policy. Proof of the original purchase date is required for warranty service. Transcend will inspect the product and in its sole discretion repair or replace it with a refurbished product or functional equivalent. Under special circumstances, Transcend may refund or credit the current value of the product at the time the warranty claim is made.

  • Page 20: Gnu General Public License (Gpl) Disclosure

    3. Intellectual Property Rights. As between Transcend and Customer, the copyright and all other intellectual property rights in the Licensed Software are the property of Transcend or its supplier(s) or licensor(s). Any rights not expressly granted in this License are reserved to Transcend.
  • Page 21 Licensed Software; (e) remove, alter or obscure any copyright notice or other proprietary rights notice on the Licensed Software or Product; or (f) circumvent or attempt to circumvent any methods employed by Transcend to control access to the components, features or functions of the Product or Licensed Software.
  • Page 22 Agreement or any breach thereof, in any one instance, will not waive such term or condition or any subsequent breach thereof. (e) Transcend may assign its rights under this Agreement without condition. (f) This Agreement will be binding upon and will inure to the...

  • Page 23: Federal Communications Commission (Fcc) Statement

    9. Federal Communications Commission (FCC) Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received including interference that may cause undesired operation. This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
