  • Page 1 A M P L I F I C A Z I O N I LCOMP2 manual...
  • Page 2: General Information

    ATTENTION ! equipment under electricity general information LCOMP2 manual Version 1.0, 25/03/2010 © by Lombardi Amplificazioni all rights reserved. The information in this guide were checked exactly but no guarantee is given regarding the correctness. Lombardi Amplifications assumes no responsibility for any errors or inaccuracies contained in this manual or products described therein.
  • Page 3 A M P L I F I C A Z I O N I Precautions during use Before using a product of Lombardi Amplifications ensure that you read well the manual in order to observe the safety precautions that will help you make proper use of equipment to prevent and avoid damages.
  • Page 4 ,the quality control with handmade assembly, the fully analog processing signal, the balanced stage output with transformer... all these features give to the LCOMP2 a superlative quality. Also has an original look between vintage comp.
  • Page 5: Technical Specifications

    A M P L I F I C A Z I O N I technical specifications input in A: XLR (Cannon) female parallel with 6.3 mm jack - Balanced in B: XLR (Cannon) female parallel with 6.3 mm jack - Balanced input impedance 47 Kohm - balanced input 25 Kohm - unbalanced input...
  • Page 6 A M P L I F I C A Z I O N I description of the front compressor 5 4 6 mounting RACK THRESHOLD (soglia) There are 4 holes in front panel for rack Potentiometer for adjusting the compression mounting.
  • Page 7 A M P L I F I C A Z I O N I description of the rear compressor switch input jack 6,3mm switch for switching the ground insertable. balanced input jack 6,3mm 1 ground - 2 signal - 3 phase FUSE (fusibile) fuse to protect equipment.
  • Page 8 A M P L I F I C A Z I O N I output transformer male female balance compressor jack stereo jack switch mic / line stereo control threshold input volume ratio input threshold volume output volume ratio control switch to control in "A"...
  • Page 9 A M P L I F I C A Z I O N I calibration Input Circuit R128 R124 instrument calibration The device has a level indicator LED meter. In the rest position (no signal) with the switch set to "Liv. Compressione", the Led bar is lit up at 0 db (yellow LED).
  • Page 10 A M P L I F I C A Z I O N I inputs and connections In the rear panel of the compressor are located input and output connection for each channel. input channel A: XLR (Cannon) male jack 6.3 mm female both connector are balanced and parallel connected 1 ground - 2 signal - 3 phase input channel B:...
  • Page 11 A M P L I F I C A Z I O N I inputs connection use mixer JACK stereo/ input A XLR: balanced 1 ground signal 2 signal input B 3 phase mixer JACK stereo/ XLR: unbalanced 1-3 ground signal 2 signal JACK mono:...
  • Page 12 A M P L I F I C A Z I O N I Cabinet size in mm [inches] front 480 [18,9] rear 442 [17,4] side 365 [14,37] 380 [14,96] page 12 of 13...
  • Page 13 A M P L I F I C A Z I O N I compliance with European Community This device complies with European directives regarding electromagnetic compatibility (EMC) 89/336/EEC as amended made in Italy by Directives 92/31/EC and 93/68/EC and the low voltage directive (LVD) 73/23/EC as amended Directives 93/68/EC.
