Summary of Contents for Essence WeR@Home ESUG05156
- Page 1 WeR@Home™ Essence HD Camera User Guide ESUGSL073 Version 1.1 February 2019...
-
Page 2: Table Of Contents
Adding Indoor Slim HD Cameras to WeR@Home™ ..............14 Viewing Video ............................16 Viewing Live Video ........................16 Viewing Recorded Video......................17 Recording Video ........................... 18 Changing Camera Settings ........................20 Specifications ............................21 WeR@Home™ Essence HD Camera User Guide... -
Page 3: Introduction
WeR@Home™ HD cameras enable you to view and record high quality video. WeR@Home™ works with the following HD cameras: Outdoor HD Camera (ESUG05156) Outdoor HD Bullet Camera (ES800HDB) Indoor Pan/Tilt HD Camera (ESUG05155) WeR@Home™ Essence HD Camera User Guide... - Page 4 Introduction Indoor Slim HD Camera (ESUG05154) WeR@Home™ Essence HD Camera User Guide...
-
Page 5: Setting Up An Outdoor Camera
Mount the camera on a wall or ceiling Selecting a Location To get the best performance, mount the camera: Within Wi-Fi or No extreme Near power Not in direct cable range temperatures supply sunlight WeR@Home™ Essence HD Camera User Guide... -
Page 6: Adding The Outdoor Camera To Wer@Home
4. Open the WeR@Home™ app. 5. Tap . A menu appears. 6. Tap DEVICES. The Devices screen appears. 7. Tap Add device. A list of devices appears. 8. Tap HD Camera. WeR@Home™ Essence HD Camera User Guide... - Page 7 If WeR@Home™ doesn't find the camera: 1. Ensure that the smartphone and camera are connected to the same network. 2. Press and hold the reset button for five seconds. Wait 30 seconds and try again. Reset button WeR@Home™ Essence HD Camera User Guide...
-
Page 8: Mounting The Outdoor Camera
5. Use the thumbscrew to attach the mount to the camera. You can attach the mount to either the top or bottom of the camera. 6. Attach the mount to the base. 7. Tighten the adjustment knob. 2.3.2 Outdoor HD Bullet Camera (ES800HDB) To mount the Outdoor HD Camera: WeR@Home™ Essence HD Camera User Guide... - Page 9 Setting Up an Outdoor Camera 1. Mark drill sites with the holes in the base. 2. Drill holes. 3. Insert the wall anchors provided. 4. Attach the base to the wall or ceiling with the screws provided. WeR@Home™ Essence HD Camera User Guide...
-
Page 10: Setting Up The Indoor Pan/Tilt Camera
Mount the camera to a wall or ceiling, or place on a flat surface. Selecting a Location To get the best performance, place or mount the camera: Not in direct Near power No extreme Within Wi-Fi or sunlight supply temperatures cable range WeR@Home™ Essence HD Camera User Guide... -
Page 11: Adding The Indoor Pan/Tilt Camera To Wer@Home
9. For wireless use: a. Tap Configure. b. Tap Wi-Fi Network. c. Remove the cable when instructed. If WeR@Home™ doesn't find the camera: 1. Ensure that smartphone and camera are connected to the same network. WeR@Home™ Essence HD Camera User Guide... -
Page 12: Mounting The Indoor Pan/Tilt Hd Camera
3. Insert the wall anchors included with the camera. 4. Attach the mount to the wall or ceiling with the screws provided. 5. Press the camera's base against the mount. Turn the camera clockwise until it clicks into place. WeR@Home™ Essence HD Camera User Guide... -
Page 13: Setting Up The Indoor Slim Hd Camera
Add the camera to WeR@Home™ Place on a flat surface. Selecting a Location To get the best performance, place your camera: Within Wi-Fi or Near power Not in direct No extreme cable range supply sunlight temperatures WeR@Home™ Essence HD Camera User Guide... -
Page 14: Adding Indoor Slim Hd Cameras To Wer@Home
5. Tap DEVICES. The Devices screen appears. 6. Tap Add device. 7. Tap HD Camera. 8. Follow the on-screen instructions. 9. For wireless use: a. Tap Configure. b. Tap Wi-Fi Network. c. Remove the cable when instructed. WeR@Home™ Essence HD Camera User Guide... - Page 15 If WeR@Home™ doesn't find the camera: 1. Ensure that smartphone and camera are connected to the same network. 2. Using a pen, press and hold the reset button for five seconds. Wait 30 seconds and try again. RESET button WeR@Home™ Essence HD Camera User Guide...
-
Page 16: Viewing Video
A slider appears. Run your finger along the slider. Flip the image horiontally Flip the image vertically Save current brightness, contrast and orientation settings as the default view Take a snapshot Image saved to smartphone's gallery. WeR@Home™ Essence HD Camera User Guide... -
Page 17: Viewing Recorded Video
A list of videos appears. 5. Tap for the video you want. The video plays repeatedly until you tap 6. To download the video clip to your smartphone's gallery, tap WeR@Home™ Essence HD Camera User Guide... -
Page 18: Recording Video
4. Tap the camera you want to edit. The camera's settings page appears. 5. Tap SD Card. The SD Card settings screen appears. Tap to set recording mode Tap to enable/disable sound recording NOTE: Sound recording is available for indoor cameras only. WeR@Home™ Essence HD Camera User Guide... - Page 19 3. Tap DEVICES. The Devices screen appears. 4. Tap the camera you want to edit. The camera's settings page appears. 5. Tap SD Card. The SD Card settings screen appears. 6. Tap Format SD card. WeR@Home™ Essence HD Camera User Guide...
-
Page 20: Changing Camera Settings
. A menu appears. 3. Tap DEVICES. The Devices screen appears. 4. Tap the camera you want to edit. The camera's settings page appears. Tap to customize camera's name Tap to change Wi- Fi network WeR@Home™ Essence HD Camera User Guide... -
Page 21: Specifications
Specifications 8. Specifications The technical specifications for Essence HD cameras by model are described in the following tables. Outdoor HD Camera (ES800HDO-M01) Category Specification Value Communications Ethernet RJ45 (100Base-T) Wi-Fi 802.11 b/g/n Camera Image sensor 1/3" CMOS Sensor Video compression H.264... - Page 22 Size, including base (H x L x W) 61 x 171 x 61 mm Weight 640 g (1.4 lbs.) Environment Operating ambient temperature range -10°C to 50°C (14°F to 122°F) Operating humidity ≤ 90% Waterproof and dustproof IP66 Compliance CE, FCC WeR@Home™ Essence HD Camera User Guide...
- Page 23 180 x 128 x 77 mm (7.1 x 5.0 x 3.0 in.) Dimensions Weight 640 g (1.4 lbs.) Operating ambient temperature range -10°C to 50°C (14°F to 122°F) Environment Operating humidity ≤ 90% Compliance CE, FCC WeR@Home™ Essence HD Camera User Guide...
- Page 24 124 x 138 x 116 mm (4.9 x 5.4 x 4.6 in.) Weight 640 g (1.4 lbs.) Environment Operating ambient temperature range -10°C to 50°C (14°F to 122°F) Operating humidity ≤ 90% Compliance CE, FCC WeR@Home™ Essence HD Camera User Guide...
- Page 25 Nothing contained herein shall be construed as conferring by implication, estoppels, or otherwise any license or right, either express or implied, under any patent or trademark of Essence or any third party. No use of any trademark may be made without the prior written authorization of Essence.
