Stateurop Motorline MC8 User Manual

Electronic Central MC8
Electronic central, for the automation of awnings, with option
to connect a tuned courtesy light, operating via Radio
commander and Wireless Sensor (Sun/Wind/Rain).
T C
ECHNICAL HARACTERISTICS
- Supply:
- Exit motor:
- Exit Courtesy light:
- Working temperature:
- Radio receiver:
- Compatible radio commanders:
- Nr memorisable Radio commanders:
- Number memorisable Wireless Sensors:
- Dimensions:
C T
ONNECTIONS ERMINAL
1:
Input connection Aarding.
2:
Input line 230V~ ( Phase ).
3:
Input line 230V~ ( Neutral ).
4:
Exit Motor Up.
5:
Exit Motor General.
6:
Exit Motor Down.
7:
Exit Courtesy light 230V~ ( Neutral ).
8:
Exit Courtesy light 230V~ ( Phase ).
C T
ONNECTIONS ERMINAL
1:
Input mass antenna.
2:
Input pole antenna.
I O M
NITIAL PERATING ODE
The device is operational only in combination with one or more
radio commanders; upon switching on the central for the First
time, not a single radio commander code is stored in the
memory.
O A
PERATING WNING WITH SEVERAL
IT is possible to program
commanders: by saving one code ( 1 key ) a cyclic operating
Step - Step is obtained (Up - Stop - Down), by saving two
different codes ( 2 keys ) two different commandos are set up,
the first for Up and the second one for Down.

Operating Awning with radio commander 1 Key :

By operating the radio commander with one single key, the
functioning is executed as follows: the first impulse activates
the movement Up until timeout of the motor. The second
impulse activates the movement Down of the guiding systems;
if this impulse is made before the timeout of the motor, the
central will stop the guiding system, a next impulse has the
motor restart in the opposite direction.

Operating Awning with radio commander 2 Keys :

By operating the radio commander by means of 2 keys, the
functioning is executed as follows: the first key ( "Up"
associated with the movement up ) operates Up until timeout
motor and the second key ( "Down" associated with the
movement Down ) operates the movement Down of the
guiding system. If a new command occurs during the
movement Up, the central will proceed with the movement Up,
whereas if a commando Down occurs, the central will stop the
movement.
The same principle applies to the phase Down.
230V~ 50/60Hz 1100W max.
230V~ 500W Max.
230V~ 500W Max.
433,92 MHz
12-18 Bit - Rolling Code
110 x 55 x 25 mm.
B CN1
OX
B CN2
OX
R
ADIO COMMANDERS
several models
GB
I
NVERSION OF THE ROTATION MOVEMENT
Whenever it occurs during the commando ( Up ) of the radio
commander the central associates the movement down
instead of up for the guiding system, one simply needs to
repeat the programming procedure by pressing the key
( Down ) instead of ( Up ), or by inverting the cables Up and
Down at the motor.
C
ENTRALIZING A
Centralizing via radio by means of radio commanding
-10÷55°C
Centralizing one or more centrals via radio allows you moving
Up or Down simultaneously several Awnings.
Centralizing is done by the input of the same codes of a radio
7 Max.
commander ( keys ) at all of the centrals or a Group, located
1 Max.
at a distance of maximum 20 meters away from the
commanding point, so as to become a general or partial
movement of several automations. In order to obtain a
satisfying result of the centralization, the place where to install
should be chosen with utmost care. The range not only
depends on the technical characteristics of the device, but
varies also according to the radio electrical conditions of the
location.
F
UNCTIONING
It is also possible to programme an additional code ( 1 key )
for radio commanding, to operate from a distance switching of
a lamp 230Vac connected to the terminal box ( 8 – 9 ) CN1 on
and off.
Important:
completely, the central will always switch off the courtesy light.
P
ROGRAMME KEYS AND
Key SEL: select the type of function to be saved, the choice is
indicated by a blinking Led. By pressing several times on the
key, the function of your choice can be selected. The selection
remains active for 15 seconds, indicated by a blinking LED,
where after the central returns to the initial mode.
Key SET: executes programming the function, selected with
the key SEL.
Signalling Led's
Led on: option saved.
of radio
Led off: option not saved.
Led blinking: option selected.
---------------------- MAIN DMENU -----------------
Reference
1) CODE
2) CODE LAMP.
3) T. MOT.
1)
CODE ( Programming radio commander for operating the
Awning and Wireless Sensor )
Programming Radio Commander 1 or 2 Keys and Wireless
Sensor:
Programming codes for transmission of the radio commander
is executed as follows: press the key SEL, LED CODE starts
blinking, at the same moment send the previously chosen
code with the radio commander of your choice: the LED
CODE starts blinking very quickly, send the second code to be
saved, LED CODE remains
completed. If the second code is not sent within 10 seconds,
the central will quit programming mode, and selects operating
the Awning with one single key of the radio commander. If all 7
codes have been saved, in case of a successive programming
the signalling LEDs start blinking very quickly to indicate that
further saving is no longer possible.

Programming Wireless Sensor (Sun/Wind/Rain):

1
G G
ROUP OR ENERAL
C R
OURTESY LIGHT BY ADIO COMMANDER
each time the awning has been pulled up
S L
IGNALLING ED
Led Off
No code Code Pgm.
No code Code Courtesy light Pgm.
Time motor 3 min. Time Motor Pgm.
on and programming
'
S
Led On
is
Rev. 1.1 05/07/10
