Summary of Contents for Canmac DMA EC3R
- Page 1 CANMAC C AT E R I N G E Q U I P M E N T S U P P L I E R ELECTRIC DONER MACHINE INSTRUCTION MANUAL...
- Page 2 ELECTRIC DONER MACHINE INDEX INTRODUCTION TECHNICAL SPECIFICATION SIZES, WARNING SIGNS, LABELLINGS SECURITY MATTERS RELOCATION AND PLACING INSTALLING INTENDED USE AND OPERATING CLEANING AND MAINTENANCE POWER CONNECTION WARRANTY AUTHORISED SERVICES...
-
Page 3: Introduction
ELECTRIC DONER MACHINE 1. INTRODUCTION Doner machines are vertical machines for meat cooking. The cooking unit is of four stages and involves a fuse energy regulator. Doner machines are used in restaurants, fast food take-aways, tourist facilities and canteens. The main body design and functional areas of the device are manufactured from stainless steel, healthy and durable material. -
Page 4: Technical Specification
ELECTRIC DONER MACHINE 2. TECHNICAL SPECIFICATION MODEL NAME ENGINE POWER ENGINE ENGINE DATA POWER DMA EC3R f=50Hz U=220V 1,3 rpm 0.25 kW DMA EC4R f=50Hz U=220V 1,3 rpm 0.25 kW DMA EC5R f=50Hz U=220V 1,3 rpm 0.25 kW DMA EC2R... - Page 5 ELECTRIC DONER MACHINE 3. SIZES, WARNING SIGNS, LABELLING MODEL WIDTH DEPTH HEIGHT WEIGHT RESIST- NUMBER kW/h POWER NAME ANCE OF RESIST- INPUT POWER ANCE DMAEC3R 546 mm 662 mm 862 mm 32 kg 1750 Watts 3 pcs 5.25 kW 13.13 Amp 220V / 400V DMAEC4R 546 mm...
- Page 6 ELECTRIC DONER MACHINE 3. SIZES, WARNING SIGNS, LABELLING 1. Lower Body 8. Skewer 15. Lower Body Rear Cover 2. Upper Body 9. Disk 3. Power Switch 10. Screwer for Skewer 4. Electric Engine On-Off Switch 11. Skewer Security Pin – Top 18.
- Page 7 ELECTRIC DONER MACHINE 4. SECURITY MATTERS This device is for professional use only. Our device is manufactured in accordance with international standards, thank you for choosing and trusting us. We kindly request the device is used in accordance with the instructions given in this manual for a long-lasting, secure and high-performance operating.
- Page 8 ELECTRIC DONER MACHINE 4. SECURITY MATTERS Please make the power connections carefully and in accordance with the instructions. After the connections are made, check each and every connection ports for electric leakage. (Use a voltage tester, DO NOT touch with bare hands!) DO NOT COVER AIR DUCTS! –...
-
Page 9: Security Matters
ELECTRIC DONER MACHINE 4. SECURITY MATTERS In case of any doubt or malfunction, turn off and unplug the device, and immediately contact authorised reseller. Do not operate the device before required maintenance is carried out. Third party intervention may cause damage and personal injuries, please contact authorised tech service. -
Page 10: Installing
ELECTRIC DONER MACHINE 6. INSTALLING Installing of the device should only be held by authorised personnel or certified expert. The environment in which the device will be installed and operated should be well-ventilated. Metal surfaces – especially those contacting the food – of the device should be cleansed before operating. - Page 11 ELECTRIC DONER MACHINE 7. INTENDED USE AND OPERATING Doner machines are vertical devices used for cooking meet, produced with double motors (upper and lower) and of stainless steel. Make sure that the power connections are made in accordance with the related standards and regulations.
-
Page 12: Intended Use And Operating
ELECTRIC DONER MACHINE 7. INTENDED USE AND OPERATING Electric connections should be checked before operating. To let the power in, rotate the knob arrow direction (to the left). First turn the knob till it reaches 1 and let the power in. Power inlet can be observed through observation port. -
Page 13: Cleaning And Maintenance
ELECTRIC DONER MACHINE 8. CLEANING AND MAINTENANCE Unplug the device. Make sure all electric switches are off. Wait for the device to cool down. Wipe the doner fat with a cloth. Electric connections should be checked before each operation. Cleanse the device on a daily basis with proper cleaning agents for food safety. Check the oil drawer regularly during operation. -
Page 14: Power Connection
ELECTRIC DONER MACHINE 9. POWER CONNECTION Power connections should be made by a certified expert, and should be in accordance with EN 60335 standards. Commissioned expert should know and practice the regional power regulations and sanctions. Engine: 230V/50Hz Resistance: 400V/50Hz Ensure an earth line. -
Page 15: Warranty
ELECTRIC DONER MACHINE 9. POWER CONNECTION SUPPLY TABLE EARTH (YELLOW-GREEN) PHASE (BROWN) NEUTER (BLUE) 10. WARRANTY If the power connection is made by authorised service or certified expert, and the device used in accordance with the manual, (6) months material warranty will be effective. 11. - Page 16 CANMAC C AT E R I N G E Q U I P M E N T S U P P L I E R MAKFRY UK LTD Northfield House Farm Rugby Road, Cotesbach LUTTERWORTH LE17 4HT (+44) 01455 697 960 www.canmac.co.uk...
