PacketWave Base Station and Subscriber
Units Installation Instructions
The PacketWave 1000 and 100 Series Base Station and Subscriber Units require
outdoor units, a Radio and Antenna for each Wireless Sub-System (WSS) and an
Integrated Radio/Antenna for the Subscriber Unit. On both the Base Station and
Subscriber outdoor units must be mounted and installed for proper operation. Each
Base Station Unit Antenna is connected to a Base Station Radio Unit using two RF N-
Type female connectors. For both the Base Station and Subscriber Units power and
Intermediate Frequency (IF) signals to the radio unit are supplied, through the RG-6
cable. A CAT5 E Ethernet control cable also connects the indoor unit to the outdoor
radio unit.
Advertisement
Related Manuals for Aperto PacketWave 1000 Series
Summary of Contents for Aperto PacketWave 1000 Series
- Page 1 PacketWave Base Station and Subscriber Units Installation Instructions The PacketWave 1000 and 100 Series Base Station and Subscriber Units require outdoor units, a Radio and Antenna for each Wireless Sub-System (WSS) and an Integrated Radio/Antenna for the Subscriber Unit. On both the Base Station and Subscriber outdoor units must be mounted and installed for proper operation.
- Page 2 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions 1. Base Station Unit Antenna Assembly and Mounting 2.5” – 4.5” (63 mm – 114 mm) Note: Down tilt assembly is an option. Do not install near power lines. Power lines, telephone lines, and guy wires look the same.
- Page 3 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Step 1. Carefully remove contents of shipping boxes. Unpack and verify the contents. Refer to the list below. You need all parts to assemble, install, and operate the antenna. July 2003 Rev 2.0...
- Page 4 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Step 2. Attach bottom mount assembly to bottom mounting plate attached to the antenna as shown. Finger tighten. Step 3. Attach top mount assembly to top mounting plate attached to the antenna as shown. Finger tighten.
- Page 5 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Step 4. Attach antenna assembly to pole. Finger tighten. Step 5. Tighten all hardware. July 2003 Rev 2.0...
- Page 6 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Base Station Unit Radio Assembly and Mounting Step 1. Step 2. July 2003 Rev 2.0...
- Page 7 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Subscriber Unit Integrated Radio/Antenna Assembly and Mounting Step 1. July 2003 Rev 2.0...
- Page 8 PacketWave Base Station and Subscriber Outdoor Units Installation Instructions Step 2. Please refer to the “Cables for PacketWave Product” document for cable specification and standards. July 2003 Rev 2.0...
- Page 9 Installation instructions are written for such installation personnel. Antenna systems should be inspected once a year by qualified personnel to verify proper installation, maintenance, and condition of equipment. Aperto Networks disclaims any liability or responsibility for the results of improper or unsafe installation or maintenance practices.
