WA619 -- Battery Contact Cover
WA619 A/B/C Battery Contact Cover for ADX2 Transmitters
Use battery contact covers to prevent reflections from the battery contacts during broadcasts or live performances.
Choose the battery cover model that matches the frequency range of your transmitter:
Model Variation
WA619A
WA619B
WA619C
Important: Cover installation must be performed by Shure service for transmitters in the JB band and G62 band.
1. Remove the transmitter handle.
2. Remove both screws securing the cover with a TR8 Tamper-Resistant TORX screwdriver.
3. Gently pull the cover to remove.
4. Align the antenna contacts and slide the battery cover into place.
5. Gently tighten the screws to secure the cover and replace the transmitter handle.Note: Only use screws pro
vided by Shure.
Frequency Range
470-636 MHz
606-810 MHz
750-960 MHz
1/2
Advertisement
Table of Contents
Summary of Contents for Shure WA619 Series
- Page 1 606-810 MHz WA619C 750-960 MHz Important: Cover installation must be performed by Shure service for transmitters in the JB band and G62 band. 1. Remove the transmitter handle. 2. Remove both screws securing the cover with a TR8 Tamper-Resistant TORX screwdriver.
- Page 2 Shure Incorporated Note: WA619 antenna covers are only compatible with ADX2 transmitters.
