Summary of Contents for Virtus NEF 18 ER

  • Page 1 Group Virtus s.r.l. Virtus roup mbH via Milano 95/e Hüserstraße 53 +39 0 383 89 06 12 +49 (0) 23 81/ 973 71– 0 27045 Casteggio (PV) / Italy 59075 Hamm / Germany +39 0 383 80 96 01 +49 (0) 23 81/ 973 71– 88...
  • Page 2: Cover

    Manual Instructions for Electric Fryer INSTALLATION, OPERATION and MAINTENANCE, INSTRUCTIONS ELECTRIC FRYER MODEL: NEF 18 ER Note: The picture is illustration only. We reserved the right to make technical changes in the interest in progress without prior notice. EURO RANGE...
  • Page 3: Preface

    Manual Instructions for Electric Fryer Dear customer, Thank you for choosing our product as your trusted partner. We ensure you that we always give our best as we produce this appliance by using the finest materials. Electric Fryer is an excellent choice to cook.
  • Page 4: Table Of Contents

    Manual Instructions for Electric Fryer TABLE OF CONTENT Page Cover …………......................... Preface ………… ......................Table of Content …………… ................... General Information …………..................Safety Instructions ………….................... Technical Data ………… .................... Data Table ………… ...................  Overall Dimension …………...................
  • Page 5: General Information

    Manual Instructions for Electric Fryer GENERAL INFORMATION Please read this manual instruction carefully before operating this appliance. Electric Fryer is an excellent cooking appliance. This appliance is using electric power. This appliance used for deep - frying. It is very important to keep this instruction book together with the appliance for future consultation.
  • Page 6: Safety Instructions

    Manual Instructions for Electric Fryer SAFETY INSTRUCTIONS Very important!: Before installing, place the appliance on solid, flat, stable and horizontal surface and connection availability. Read this manual instruction carefully before using Electric Fryer. This appliance is for food preparation only. Below are safety instructions that strictly conformed: ...
  • Page 7 Manual Instructions for Electric Fryer ELECTRIC SHOCK HAZARD ! Authorized and qualified mechanic can do the maintenance and repairs. Turn OFF and disconnect the appliance before opening front panel and accessing electrical area inside the appliance. WARNING ! DO NOT TURN ON THE FRYER WITH EMPTY TANK. IT CAN CAUSE OVERHEATING and MAY DAMAGE THE APPLIANCE.
  • Page 8: Technical Data

    The temperature is adjustable from 50 C up to 200  Data Table Table 1: Technical Data Technical Specification Model NEF 18 ER Width Depth Height Overall Dimension (mm) 850/910...
  • Page 9: Overall Dimension

    Manual Instructions for Electric Fryer  Overall Dimension NEF 18 ER EURO RANGE...
  • Page 10: Electric Wiring Diagram

    Manual Instructions for Electric Fryer  Electric Wiring Diagram CODE DESCRIPTION Circuit Breaker 3 Pole 32A KB.5026 Fryer Heater 18000W/400V PD.4118K C1-C2 KB.5034 Magnetic Contactor 32A PD.414KB Pilot Light Green 230 V Pilot Light Yellow 230 V PD.414JB Thermostat 190°C PD.412E Safety Thermostat 240°C PD.412H...
  • Page 11: Technical Data Plates

    Manual Instructions for Electric Fryer TECHNICAL DATA PLATES Figure 1: Technical plate reports the current gas setting, Electric Fryer nominal data, gases table, categories, and pressures for other CE countries. Fig. 1 EURO RANGE...
  • Page 12: Component List

    Manual Instructions for Electric Fryer COMPONENT LIST EURO RANGE...
  • Page 13 Manual Instructions for Electric Fryer EURO RANGE...
  • Page 14: Installation For The Installer

    Manual Instructions for Electric Fryer INSTALLATION FOR THE INSTALLER Very important!: Before installing, place the appliance on solid, flat, stable and horizontal surface and connection availability. The following instructions are intended for authorized and qualified installer. Before doing installation, adjustment, and maintenance operations, the installer must follow local and legal regulations.
  • Page 15: Position And Fixing

    Manual Instructions for Electric Fryer  Position and Fixing Authorized personnel must do the installation. Install the appliance according to National Safety Standard about electric appliances. Install the appliance under an extractor fan to remove the cooking fumes. Make sure that any object around or under Electric Fryer does not obstruct air volume required for air circulation.
  • Page 16 Please make sure that the connection and electric installation installed in appropriate tension / voltage. Put away all flammable material near the appliance. Put the appliance in good ventilated room. WARNING ! Incorrect voltage may damage the appliance.  NEF 18 ER ( 3N AC 400V 50/60Hz 18,000W) EURO RANGE...
  • Page 17: Control Panel Description

    Manual Instructions for Electric Fryer CONTROL PANEL DESCRIPTION  NEF 18 (ER) Thermostat Control Knob To turn on the appliance and adjust the temperature for cooking Green Pilot Light To indicate the appliance is ON / OFF and ready to use Yellow Pilot Light To indicate the heating process is working Drain Valve Oil...
  • Page 18: Use Instructions (For User)

    Manual Instructions for Electric Fryer USE INSTRUCTIONS (for user)  Warning This appliance is an electric cooker for professional use. It shall be used by authorized people only. Before starting, please make sure that the appliance is in good condition and put it in a good ventilated room.
  • Page 19 Manual Instructions for Electric Fryer 8. Before put the basket into hot oil, carefully drip the food with oil carefully to limit the emulsion and consequent foam. 9. If the oil set on fire, turn OFF the Fryer. Cover the tank with the lid and extinguish the fire with fire extinguisher.
  • Page 20: Turn On / Off

    Manual Instructions for Electric Fryer ATTENTION ! Before frying, fill the oil tank with cooking oil ( ± 18 liters). The Oil Level Mark inside the fryer helps the user to fill the oil in the tank.  Turn Electric Fryer ON / OFF Turn Electric Fryer ON a.
  • Page 21: Routine Cleaning And Maintenance

    Manual Instructions for Electric Fryer ROUTINE CLEANING and MAINTENANCE Clean the appliance to keep the functionality and durability. In the case of any failures, do not attempt to solve the problem but call your dealer immediately to ask for help. Do not attempt to dismantle the appliance, specialized mechanics must do all job.
  • Page 22 Manual Instructions for Electric Fryer ATTENTION! ! If you find the lighting and control devices are difficult to use, please contact the manufacturer immediately, which will provide you necessary assistance or call your dealer. ! Please check the appliance periodically. Contact your dealer that will supply assistance to repair and set interval.
  • Page 23: Trouble Shooting

    Manual Instructions for Electric Fryer TROUBLE SHOOTING PROBLEM CAUSE CORRECTIVE ACTION The oil temperature can not - Thermostat is problem - Check or replace reached Heating element does not - Heating element damaged - Check or replace function - Thermostat is damaged - Check or replace - Contactor is damaged - Check or replace...
