HSI REACT Operating Instructions

1. Upon power-up the unit will resume display of time and
elapsed time.
2. To set the React unit, press and hold the letter "R" in the
word React for approximately five seconds, or press the RESET and
the MODE buttons at the same time and hold for 5 seconds. The
units will activate the set-up mode and a blinking 0 in the upper
[orange] row and numbers in the lower [green] row.
3. Time of Day With the red 0 blinking press the START/STOP
switch and the first green digit will begin to blink, Use the MODE
switch to set the first digit. Press the START/STOP to activate the
second digit and use the MODE to set it. Repeat for the rest of the
digits. Upon completion of the time set, a red blinking 1 will
appear.
Date. With the red 1 blinking press the START/STOP switch and the first green digit will begin to
4.
blink. Continue as in 3 above to set the date.
Brightness. With the red 2 blinking press the START/STOP switch and the last green digit will begin
5.
to blink. Pressing MODE will change the brightness from 0 [dim] to 6 [bright] Do not set at over 6.
6. Mode, With the red 3 blinking press the START/STOP switch and the last green digit will begin to
blink. Press the MODE switch to change the Mode as follows:
0 elapsed timer only
elapsed timer & time of
3
day
7. 12/24 Hour With the red 4 blinking press the START/STOP switch and the last green digit will begin
to blink. Pressing MODE will change the operation for the time of day clock to
0 24 hour time of day display
8. 4/6 Digit Display With the red 5 blinking press the START/STOP switch and the last green digit will
begin to blink. Pressing MODE will change the operation for the time of day clock to
0 24 hour time of day display
Single/Dual Display With the red 6 blinking press the START/STOP switch and the last green digit
9.
will begin to blink. Pressing MODE will change the operation for the time of day clock to
Dual display [elapsed timer in red on
0
top, time of day in green on bottom
Version No. With the red 7 blinking the lower row will display the version number of the unit's
10.
program.
Self Test With the red 8 blinking press the START/STOP switch and the last green digit will begin to
11.
blink. Pressing MODE will cycle all digits through all numbers for testing.
12. After self test the unit will revert to operational mode. After setting any of the above, operational
mode can be attained by pressing RESET. Your last changes will be entered only if the red digit is
when you press RESET.
Hospital Systems, Inc.—750 Garcia Ave—Pittsburg, CA 94565

Operating Instructions

REACT™ Time of Day/Elapsed Timer
1 time of day only
date & elapsed timer &
4
time of day
1 12 hour time of day display
1 4 digit display for time of day HH:MM
Single display, MODE will display either
1 elapsed time
[red] row
phone: 925.427.7800
fax: 925.427.0800
www.HSIheadwalls.com
2 date & time of day
or time of day in top
blinking
©HSI 2014
