Summary of Contents for Cornered Audio CA280DSP
- Page 1 HOW TO CORNER YOURSELF WITH GREAT SOUND User Manual Cornered CA280DSP Network amplifier...
- Page 2 Cornered Audio Introduction Cornered Audio provide aesthetic sound to custom- and com- mercial installations where high-end performance and discreet, elegant design is needed. To get the best out of your Cornered amplifier and loudspeaker system, please study this manual care- fully before installing.
-
Page 3: Rack Mounting
• Check the voltage in your area and use the correct type of mains CA280DSP can be mounted into a rack by attaching two brackets, one short and one long (included) to the mounting holes in the side of the amplifier. Use a 4 mm diam- eter machine screw, ensuring that the length of the screw is suitable for the thickness of the rack shelf. - Page 4 Lorem ipsum Lorem ipsum 3.0 Front and rear panel Rear - from left to right: A. AC line input – Connect the included IEC power cable. B. General purpose in- and output. Connect external control using the four-pole Phoenix connector. C.
- Page 5 Lorem ipsum Lorem ipsum 4.0 Connections 4.0 Connections 4.1.1 Wiring in 2-channel mode 4.2 Wiring in bridge mode * Use 1+ 1- for 70/100V direct drive. Select >16 ohm. * In bridge mode, use 1+ 2+ for 70/100V and 4/8ohm mode...
-
Page 6: Navigation Bar
Lorem ipsum Lorem ipsum 5.0 Navigation bar 6.0 lnstall control software and connect to amplifier 1. Load and Save settings to PC. Store and Recall up to 3 pre-sets locally on the Control and setup of the amplifier can be made via direct Wi-Fi, Ethernet cable or USB type B. - Page 7 Lorem ipsum Lorem ipsum 7.0 Basic amplifier functions 8.0 Advanced amplifier functions Click “Level” in the main navigation bar to access basic amplifier functions. By clicking on 1 or 2 in the main menu, you will access more settings for channel 1 or 2.
-
Page 8: Bridge Mode
Lorem ipsum Lorem ipsum 9.0 Bridge mode 11.0 EQ section When selecting “Bridge Mode”, the “Speaker Drive” menu will appear. To enter the EQ section, press 30 PEQ in the quick menu bar. Then click “edit” in the EQ filters section marked below. •... - Page 9 Lorem ipsum 11.1 Auto EQ With the PC’s ASIO card and an external microphone, CA280DSP is capable of cal- C: Set Frequency range and PEQ filter gain (+ - 3 dB is recommended). Click “Start”. culating and setting room EQ automatically. To enter the Auto EQ Wizard, do the The Auto EQ will sweep the room and calculate EQ settings with gain and Q.
-
Page 10: Declaration Of Conformity
2860 Søborg Denmark Tel +45 4366 1088 www.cornered.dk We, CORNERED Audio ApS, declare under our responsibility that the following product(s): Cornered CA280DSP Type: Amplifier …is in conformity with COUNCIL DIRECTIVE of 3 May 1989 on the approximation of... - Page 11 Contents of the manual are subject to change without notice. CORNERED Audio does not accept any liability for loss or damage caused or alleged to be caused directly or indirectly by these instructions. CORNERED Audio makes no guarantee of any kind with regard to these instructions.
