Summary of Contents for HydroQuip Baja Sportub ECO-5/6100 Series
-
Page 3: Table Of Contents
ECO-5 / 6100 Series Control Contents · Tools Required Tools & Parts · Parts Required · FLO Message Error Messages · FLC Message · Prr Message · HL Message · Low Level Programming Programming · Nothing Works! Identified Problems · Spa Is Not Heating ·... -
Page 4: Tools & Parts
Tools & Parts ECO-5 / 6100 Series Control This Trouble Shooting Manual has been designed for easy simple step-by-step problem solving and fault isolation. It is important to identify all of the possible causes of the problem before making a final diagnosis. What you see at first is usually a symptom of the problem, not necessarily the problem itself. - Page 5 Pressure or Flow Switch Not Activated ECO-5 / 6100 Error Messages If 3 flashing dots appear below the temperature display, the printed circuit board must be checked to see if the LED error indicator is illuminated. If it is not the 3 flashing dots are related to a problem with the pressure or flow switch. If the system does not detect any pressure when the pump is manually or automatically turned on, 3 flashing dots will appear below the temperature display.
- Page 6 Pressure or Flow Switch Activated ECO-5 / 6100 Error Messages If 3 flashing dots appear below the temperature display, the printed circuit board must be checked to see if the LED error indicator is illuminated. If it is not the 3 flashing dots are related to a problem with the pressure or flow switch. If the system detects any pressure while the pump is turned off, 3 flashing dots will appear below the temperature display.
- Page 7 Temperature Sensor ECO-5 / 6100 Error Messages The system is constantly verifying that the reading of the temperature probe is within limits. If the actual spa water temperature greatly differs from that displayed by the spaside control or if 32°F is constantly displayed, this indicates a problem with the water temperature sensor.
- Page 8 High Limit Sensor / Over Heat ECO-5 / 6100 Error Messages If the temperature of the water is at or higher than 115°F and the display on the Spaside control IS the right temperature, perform the following tests. · Remove the spa cover. Wait until the If the weather is spa cools down (Add cold-water if very warm:...
-
Page 9: Low Level Programming
High Limit Sensor / Over Heat ECO-5 / 6100 Error Messages If the temperature of the water is at or higher than 115°F and the display on the spaside control DOES NOT show the right temperature, perform the following tests. ·... -
Page 10: Nothing Works
Nothing Works! ECO-5 / 6100 Identified Problems If everything is connected properly and nothing seems to work, there is probably a problem with the power supply. If you detect Low or High voltage conditions at the input power connection contact an electrician. Perform the following tests to identify and correct the problem: ·... - Page 11 Spa Is Not Heating! ECO-5 / 6100 Identified Problems · With an accurate thermometer, If the Heater On measure the temperature and compare indicator does not your reading with the temperature value displayed on the spaside control. illuminate: · If the values are different (±2°F), check to make sure the sensor is properly inserted into the dry-well or if hot air is affecting its readings.
-
Page 12: Pump Does Not Work
Pump Does Not Work! ECO-5 / 6100 Identified Problems If pump 1 does not operate, perform the following tests to correct the problem: · Check to see if there is an error message on the spaside control. If this is the case, go to the specific section that refers to that message. -
Page 13: Ozonator Does Not Work
Ozonator Does Not Work! ECO-5 / 6100 Identified Problems If the Ozonator does not work, perform the following tests to correct the problem: · Note: The ozonator has a constant power supply. It does not run only during filtration cycles. ·... -
Page 14: Spaside Does Not Work
Spaside Does Not Work! ECO-5 / 6100 Identified Problems If the keys on the Spaside control seem to not be working, perform the following tests to correct the problem: · Make sure the Programming Jumpers are set properly. (Refer to Programming) ·...
