- Page 1 ELECTRONIC BARRIER WITH AUTOMATIC FUNCTION Chamberlain GmbH Alfred-Nobel-Str. 4 D-66793 Saarwellingen www.chamberlain.de e-mail: info@chamberlain.de...
- Page 2 Notes WARNING / ATTENTION IMPORTANT FITTING AND OPERATING INSTRUCTIONS PLEASE START BY READING THESE IMPORTANT SAFETY RULES • SAVE THESE INSTRUCTIONS This safety alert symbol means "Caution" - failure to comply with such an instruction involves risk of per- sonal injury or damage to property. Please read these warnings carefully. This barrier is designed and tested to offer appropriately safe service provided it is installed and operated in strict accordance with the following safety rules.
-
Page 3: Table Of Contents
Notes Contents Important information Use as prescribed 1.1.1 Designated setting Influence of wind Safety 1.3.1 General safety advice 1.3.2 Minimizing the risks 1.3.3 Safety for pedestrians 1.3.4 Explanation of warning signs used in the manual 1.3.5 Installation and maintenance Service 1.4.1 Wearout parts and maintenance Technical changes... - Page 4 Notes 7.8.1 Mounting the articulated-guide 7.8.2 Adjusting the length Fixation and setting of push rod for articulated barrier 7.10 Construction barrier left / right and conversion Spring balance Testing Spring setting Correcting spring settings Removing the spring Electric connection Connection to supply voltage Earthing Main switch Handling in case off power failure...
-
Page 5: Important Information
Notes Important information Use as prescribed Our herein described barrier models and accessories are suitable for locking and opening entries and exits to parking lots, access roads and entries for motor vehicles and motorbikes. A different use or a use beyond the here described ones is not in line with the prescribed use; especially not permissible for pedestrian traffic. -
Page 6: Safety
Notes Safety 1.3.1 General safety advice This barrier is constructed and tested in order to guarantee sufficient safety when installed and when used according to the following safety regulations. The products have left our house free of faults. Still there can be risks involved when mounting or during later operation, if the product has been installed or used improperly. - Page 7 Notes 1.3.5 Installation and maintenance • All units must be connected according to our instructions. • Before opening the control unit the power supply must be disconnected. • In case of maintenance/repair work all command devices (radio, switches, push buttons, loops) must be deactivated, so that the barrier does not move uncontrollably.
-
Page 8: Service
Notes Service Barrier units are not maintenance free and therefore need regular inspection. Hereby the number and extent of the inspections depend on the frequency of use (number of cycles) and where the unit is placed and less on the time span since the previous inspection. The operator must keep an inspection record of all risks which describes and confirms the extent of the inspection. -
Page 9: Technical Changes
A product under warranty which is determined to be defective in materials and/or workmanship will be repaired or replaced (at Chamberlain's option) at no cost to the owner for the repair and/or replacement parts and/or product. Defective parts will be repaired or replaced with new or factory rebuilt parts at Chamberlain's option. -
Page 10: Overview
Notes Overview Overview of models Model Pole length Opening time Alignment BARS1-L 1.5 - 2.5m 1 sec Left BARS1-R 1.5 - 2.5m 1 sec Right BARS3-L 1.5 - 4.5m 3 sec Left BARS3-R 1.5 - 4.5m 3 sec Right BARM6-L 4.5 - 6.0m 6 sec Left... -
Page 11: Installation Examples
Notes Installation examples Example 1 Free exit Safety loop and loop for automatic opening of barrier. Distance between loops: 1.0m Example 2 Opening by means of switch / push button / card reader or safety loop. This installation represents an entry or an exit. Example 3 Safety loop. -
Page 12: Operation Description
Notes Operation description Operation of barrier Barriers are available in models Right / Left. The casing is made of welded sheet steel (apart from specific models) and is powder coated against corrosion. The drive unit and control are integrated into the casing and accessible by lifting off the hood and opening the service door. The drive motor is powered by the control and is fed by line voltage. -
Page 13: Operation Of Barrier (Straight Pole)
Notes Operation of barrier (straight pole) Barriers with straight barrier posts are available in different lengths. The straight pole moves from horizontal to the complete vertical position. Short barrier posts can be opened very quickly (1 second), long posts must be openend more slowly (3 / 6 seconds) in order to ensure lasting and safe operation of unit. -
Page 14: Installation
Notes Installation Foundation construction: barrier A stable position of the barrier casing is imperative. We recommend a foundation with the following minimum requirements. If there is a risk of frost, the foundation must be constructed in a way as to ensure protection against frost –... -
Page 15: Contact Loops (Induction Loops) - Description
Notes Contact loops (induction loops) – description A contact loop reacts to metal and is especially suitable for safe operation of barriers. The dimensions, number and installation of loops has to be executed with great care. Principally the following applies: •... -
Page 16: Installation Of Induction Loops - General
Notes Installation of induction loops – general The geometry has to be executed depending on unit: • The loop has to be positioned exactly underneath barrier pole. The barrier pole is positioned on the side of the barrier casing. • The monitored area for cars has to be at least 500mm on both sides. For trucks the loops have to be larger or a second safety loop must be installed. -
Page 17: Installation Of Induction Loops - Procedure
Notes Installation of induction loops – procedure Installation under asphalt or concrete: • Size and positioning of loop(s)has been decided upon. Mark positions on the ground and check again. • The corners of the loops are to be executed at an angle of 45°. See Illustrations. •... -
Page 18: Installation Of Operation Switches
Notes Installation of operation switches Operation/command devices must be placed such as to ensure easy access from inside the vehicle. They must be in direct visual contact with regard to barrier. Poorly placed switches and pillars represent possible safety hazards. Usage of Photocells Photocells are especially suitable as an alternative to a contact loop;... -
Page 19: Mounting
Notes Mounting Service door The included key (2 keys) is necessary to open the service door. It can be found in the accessory package which is included in the barrier’s transport packaging. On the inside of the service door the already pre- installed and partly wired control is situated. -
Page 20: Mounting The Barrier (Casing)
Notes Mounting the barrier (casing) Note: 2 people required! The necessary parts can be found in the accessory package included in the delivery contents of the barrier. 2x U-profiles 4x composite anchors Ø20mm x 110mm long • Indicate drillings for composite anchors and prebore •... -
Page 21: Adjusting The Length
Notes Adjusting the length The unmounted barrier pole is longer than actual barrier operation width. This width is always 270mm shorter. If a barrier pole support is used then operation width is decreased by about 100mm. The barrier pole cannot be shortened on the side of the drive but on the opposite end. The end cap can be removed and then the length of the pole can be adjusted. -
Page 22: Fixation And Setting Of Push Rod For Articulated Barrier
Notes 7.8.2 Adjusting the length The articulated pole can only be shortened at the end behind the articulated mechanism. All other parts are already adjusted to correct measurements ex works. Fixation and setting of push rod for articulated barriers Familiarize yourself with all parts of the push rod. See illustration. Attention: 2 people necessary! Adhere to the following course of action: •... -
Page 23: Spring Balance
Notes Spring balance The spring in the barrier equalizes the weight of the barrier pole. It is essential that the correct spring is combined with the correct barrier length. If the barrier pole is not balanced the unit does not work well, the barrier does not close/open completely and the life span is drastically shortened. Testing Release barrier and lift barrier pole manually and let go in the following different positions: 15°, 30°, 45°, 60°. -
Page 24: Removing The Spring
Notes Removing the spring Attention: if the spring is to be exchanged in one operational step then follow the steps below. If unit is left unmonitored without spring then the barrier must be closed and secured against being opened – or the barrier pole must be dismantled. The power supply must be cut thus preventing the barrier from being operated. -
Page 25: Electric Connection
Notes Electric connection The barrier must be connected to grounded mains. The connection must be executed professionally and must comply with the relevant norms and guidelines of the installation site. The offered models are partially wired ex works in their standard versions. Special edition models may differ from this pattern and may include other controls. -
Page 26: Control Unit
Notes Control unit The control is a modern design micro controller and is purely designated and conceived for the operation of these barriers. The control already has many integrated functions. 10.1 Functions of control unit • Automatic closing (adjustable) • Immediate closing after clearance of loop •... -
Page 27: Installation Description Of Control Unit
Notes 10.5 Installation description of control unit 10.5.1 Description of screw terminals • Motor: outlet to motor 230V o L = black or brown o N = blue o L = brown or black • POWER LINE: connection voltage 230V of control o Grounding •... - Page 28 Notes Note 1: The pace of the vehicles should be slow. All examples should be adapted to the local situations. All of the following examples are executed without oncoming traffic. Note 2: Not suitable for operation with trailers. Note 3: As a third safety device it is necessary to place a Photocell under the barrier pole Note 4: Automatic closing after a certain (preset) time is not possible with this function Note 5: It is important to understand the Vehicle Detector Signal –...
- Page 29 Notes • SERIAL COMMUNICATION o Inactive for these barrier models • LOOP – output to loop o Only if socket VEHICLE DETECTOR SOCKET is occupied o The functionis identical to output: Vehicle Detector Signal • PHOTO SIGNAL INPUT Terminal for Photocell input N/O contact (closer) 2 modes of operation possible: Adjustment via DIP switch 3 DIP switch 3 OFF:...
-
Page 30: Description Of Socket Connectors
Notes 10.5.2 Description of socket connectors • SHORTCUT CONNECTOR: terminal blocked for particular type of loop detector. Cable not included in range of offer. Serves the same purpose as the VEHICLE DETECTOR SIGNAL • CAPACITOR X2: capacitor terminal o Power: 2x 9μF/450Volt o Clamp occupancy from left to right: •... -
Page 31: Description Of Switches
Notes 10.5.3 Description of switches • FAN: test switch for fan operation ON/OFF o If a fan is installed in the barrier, see occupancy socket: TEST (resp. model), it can be tested with this switch o Normal setting: OFF o Test setting: ON o NOTE: if motor temperature rises above 70°C the fan automatically starts •... -
Page 32: Description Of Signal Led's
Notes 10.5.4 Description of signal LED’s • POWER o Colour: red o On: power on o Off: no power supply • UP o Colour: red o On: signal OPEN applied o Off: no signal • DOWN o Colour: red o On: signal CLOSE applied o Off: no signal •... -
Page 33: Adjusting The Barrier
Notes Adjusting the barrier The power supply and at least one switch OPEN-CLOSE must be connected. The barrier pole has to be installed and balanced. Attention: the traffic lane and the area surrounding the moving barrier pole must be blocked from traffic in the mean time. 11.1 Adjustment of limit switches The adjustment of limit switches is only possible if barrier pole is balanced. -
Page 34: Completion (Finalizing Installation)
Notes Completion (finalizing installation) • All electrical connections must be correct • All safety devices must have been checked concerning proper function • All modes of operation of unit must have been tested • All mechanical parts must be securely tightened. Even if no adjustments have been carried out on mechanical parts ALL setting screws and connection screws of o Spring o Spring pole... -
Page 35: Trouble Shooting And Faq's
Notes Trouble shooting and FAQ’s 13.1 Barrier does not work (no movement) (refer to 13.2) 13.2 Does not open Description Remedy / Reason / Solution - barrier shows no reaction - power supply interrupted - NO LED lighting up in control unit - main switch turned off - protection switch F1 has triggered - fuse in control unit has blown... -
Page 36: Does Not Open / Close, Incomplete Movement Or Is Slow
Notes 13.4 Does not open / close, incomplete movement or is slow Description Remedy / Reason / Solution Barrier does not close resp. does not close as desired - barrier has been released (see also: Does not open) - a connected accessory item fails (switch, push button, loop, Photocell) - wrong setting of motor type to control unit - limit switch already triggered;... -
Page 37: Other
Notes 13.6 Other Description Remedy / Reason / Solution Barrier closes as soon as loop has been unblocked Normal control unit function. Delay has to be set at loop diagnosis unit. Barrier comes to standstill during travel Power failure during operation. See also: Barrier does not work. - Page 38 Notes Model and carton content chart Mounting Limit Radio Mounting bolt Service Electronic Switch Release Release connector Number of Model Drive Unit Bar (2x) (concrete) Door control (optical) (manual) Radio cable cartons ● ● ● ● ● ● ● BARS1 ●...
-
Page 39: Dimensions Of Articulated Barrier Pole
Notes 14.2 Dimensions of articulated barrier pole 90° 1940 1260 1940 3200 [ mm ] 14.3 Articulated and folding barrier pole 180° 1260 1440 3000 [ mm ] 39/40... -
Page 40: Lattice Barrier Pole
We are happy to send you an up-to-date list of spare parts on request. Please contact the installer of the unit or our customer service department. Only use original parts from our Chamberlain product range. Usage of non-original parts is not permitted.
