- Page 1 DESIGNED AND MANUFACTURED IN ENGLAND NAVTEX PC PRO MARINE INSTRUMENTS NASA MARINE Ltd. BOULTON ROAD RoHS 2002/95/EC STEVENAGE HERTS SG1 4QG ENGLAND (01438) 354033...
- Page 3 NAVTEX PC PRO DESCRIPTION The NASA Navtex PC Pro is a two-channel receiver (518KHz and 490Khz) for small boat use, and is currently supplied as a kit comprising the receiver (referred to as the “engine”), antenna, power lead, CD containing the PC display software, and a USB adapter and driver disc. The engine output is RS-232 and will connect to a standard serial port if your computer has one.
-
Page 4: Installing The Software
INSTALLING THE HARDWARE AND ANTENNA The NASA Marine PC Navtex Pro receiver is not watertight so it must be mounted in a position which is dry at all times. Mount the antenna in a convenient position outside the cabin, then connect the antenna to the receiver. - Page 5 Confirm your name and organisation, and click “OK” A default folder for the installation is offered by the setup routines. You may change this if you Click “OK” Click the button...
- Page 6 Files are now installed. As the software is specific to Nasa engines, the normal software registration has been supressed. A short-cut will be installed on the desktop, provided you use the default value path as above. That's it – all done! FIRST USE OF THE NAVTEX PRO Install the receiver (“Engine”) and antenna in accordance with the instructions.
-
Page 8: Limited Warranty
Prior to unpacking this instrument read and fully understand the installation instructions. Only proceed with the installation if you are competent to do so. Nasa Marine Ltd. will not accept any responsibility for injury or damage caused by, during or as a result of the installation of this product.
