Summary of Contents for GSS.standard HDTV 1200 C CI

  • Page 1 HDTV 1200 C CI...

  • Page 2: Table Of Contents

    o n t e n t s 1 Safety regulations and notes ................ 4 2 General information ..................5 Packing contents ................5 Meaning of the symbols used ............5 Technical data ................5 Description ...................6 Software query................7 How the TPS module works .............7 Station selection ................7 Changing the Transport stream and ORGNET-ID........7 Changing the NIT ................8 Changing the SID ................8...
  • Page 3 Station selection ..............24 Descrambling Stations .............24 Service ID (SID) ..............24 Operation with a CA module ............27 PID monitoring ...............27 CA module ................27 Output data rate ................28 Transport stream ID and the ORGNET-ID.........29 Network Information Table (NIT) ............30 NIT version ................31 Factory reset ................32 Saving settings ................32 Programming via the control software ..........33...

  • Page 4: Safety Regulations And Notes

    a f e t y r e g u l a t i o n s a n d n o t e s • Assembly, installation and servicing should be carried out by authorised electricians. • Switch off the operating voltage of the system before beginning with assem- bly or service work or pull out the mains plug.

  • Page 5: General Information

    2.1 P aC k i n g C o n t e n t s 1 Cassette HDTV 1200 C CI 2 RF cables 1 Brief assembly instructions 2.2 m...

  • Page 6: Description

    Connections SAT inputs: ................2 F sockets RF output: ................1 IEC socket Connection strip (10-pin): ....for supply voltages and control circuits RS-232 socket: ........serial interface for software update Common Interface: ......several channels can be descrambled. Remote maintenance Remotely controllable (via PSW 1000*): ..........yes Remote update (via BEflash*): .............

  • Page 7: Software Query

    of the control unit must be "V 45" or higher. You can find the current operating software for the control unit, the software "BE-Flash" and the current assembly instructions on the website "www.mygss.eu". The cassette is intended for use in the STANDARD LINE head-end stations. 2.5 s o f t wa r e q u e ry...
  • Page 8 nit h a n g i n g t h e The transport stream contains data in the form of tables which the receiv- ers evaluate and require for convenient use. The TPS module can adjust the "Network Information Table" (NIT) to accommodate the new station data. The "NIT"...
  • Page 9 3.2 emC r e g u l at i o n s To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in a head-end station which is installed in a 19" cabinet, make sure the connections leading in and out for the 19" cabinet are made using cable terminals. The attenuation of shielding of the connection lines for antenna must meet the requirements for "Class A". CLASS • Insert the required number of cable terminals in the openings provided in the head-end station or in the 19" cabinet. Tighten the nuts of the cable terminals until the teeth on the lock washers put under have penetrated the exterior coating and a good connection is made between the housing / 19"...
  • Page 10 3.3 o v e rv i e w t h e C a s s e t t e D-SUB socket "RS 232" Slot for CA module SAT input "A" (channel strip "A" Status LED of input "A" SAT input "B" (channel strip "B") Status LED of input "B"...
  • Page 11 3.5 r Ca e t r o f i t t i n g m o d u l e The cassette is equipped with a common interface for CA modules of various scrambling systems and service providers. Scrambled stations can only be descrambled with a CA module suitable for the scrambling system and the corresponding smart card.

  • Page 12: Station Selection

    C o n t r o l P a n e l g l a n C e 4.1 m e n u i t e m s Programme the cassette using the buttons on the control unit of the head-end station.
  • Page 13 r o g r a m m i n g 5.1 P r e Pa r at i o n • Test the software versions of the head-end station and the cassette and up- date them if necessary. The current software versions can be found on the website "www.mygss.eu".
  • Page 14 5.3 P ro g r a m m i n g Pro C e d u r e Bedienhinweise Operating Hints BE–Remote V 45 Ein / On "blättert" Menüs vorwärts. scrolls forward through the menu. please wait … "blättert" Menüs rückwärts. scrolls backward through the menu.
  • Page 15 ◀ ▶ 4A/B – 01/06 + / - / X Das Erste 4A/B – 01/06 auto / 0x0001…0xFFFF 0x6DCA => auto ◀ ▶ Bx 4 Bx 4 01/03 MENU ▶ PID Check => Information *) on / off *) Die angezeigte Information ist abhängig vom verwendeten Bx 4 DATARATE...
  • Page 16 5.4 P r o g r a m m i n g t h e C a s s e t t e —> Pressing the button for longer than 2 seconds cancels the programming procedure. This takes you back to the programme item "Selecting the cassette"...
  • Page 17 • Press the button. —> The "Ouput signal" – "OUTPUT" menu is activated. u t P u t s i g n a l e v e l o d u l ato r In this menu you – set the output level of the cassette, –...
  • Page 18 • Press the button to activate the submenus for the output parameters. —> The "Output parameter" – "QAM-MODE" submenu is activated. (qam u t P u t Pa r a m e t e r m o d u l at i o n n v e r t i n g t h e u s e r...
  • Page 19 u t P u t ym b o l at e In this menu, you can set the output symbol rate. 4A/B QAM-RATE 6900 • Use the buttons to place the cursor under the number to be changed ("Number 1") and set the symbol rate with the buttons .
  • Page 20 / o u t P u t C h a n n e l u t P u t f r e q u e n C y In this menu, you can select the channel or frequen cy setting for the adjustment of the RF output.
  • Page 21 n P u t Pa r a m e t e rs In this menu you select the input, for which you would like to set the input pa- rameters in the submenus. Bx 4 INPUT Tuner A => —> The indication "OK" serve for information: OK - input signal is present at tuner A.
  • Page 22 n P u t s ym b o l r at e dvb m o d e The symbol rates of the satellite transponders can be found in the current chan- nel table of the satellite operator, in various satellite magazines and in the Internet.
  • Page 23 e t t i n g t h e i n P u t f r e q u e n C y If three dots " … " appear in the second line of the display, the cassette is in the "station search"...
  • Page 24 • Press the button. —> The submenu "Station selection" – e.g. "Bx 4A TV – 01/06" is acti- vated. tat i o n s e l e C t i o n es C r a m b l i n g tat i o n s id (sid) e rv i C e By default all stations are deactivated (status LEDs off).
  • Page 25 Further possible terms displayed: "RA" Radio channel type For radio stations, the background of the screen of the connected TV or test receiver is darkened. " + " The selected station is activated. " * " The star means that the TV or radio station selected is scrambled. To enable the stations, the CA module and the appropriate smart card of the station pro- vider are required.
  • Page 26 • Press the button. —> The submenu for SID setting is activated. 4A/B 01/06 0x6DCA => auto Set the SID (0x0001 … 0xFFFF) whished: • Use the buttons to position the cursor under the digit of the hexadeci- mal number to be set. •...
  • Page 27 Ca P e r at i o n w i t h m o d u l e In order for this function of the CA module to be possible, stations capable of being descrambled by the CA module you are using and your smart card must be selected in the "Station selection"...
  • Page 28 —> The display shows e.g.: Bx 4 01/03 MENU Information Meaning of the indicators: "Bx 4" Slot 4 "01/03" The first of three menu items is activated. "MENU" The menu of the CA module is activated. For the explanation of further details please use the operating instructions of the CA module used.
  • Page 29 —> Is the "Number 2" higher than "Number 1" question marks "??" ap- pear in the display. In this case correct the output parameter settings (pages 18 …) or the settings of the station selection (page 24). Bx 4 DATARATE 31667 ??(36772) •...
  • Page 30 (nit) e t wo r k n f o r m at i o n a b l e In this menu you can create a NIT as well as switch off and on the NIT. Chang- ing the NIT version is possible in a submenu. Bx 4 =>...
  • Page 31 nit v e rs i o n In this submenu you can change the NIT version. • In menu NIT press button —> The submenu "NIT version" – "NIT" is activated. Bx 4 Version —> Before a NIT must have been created. •...
  • Page 32 aC to ry r es e t In this menu you can reset all settings to the factory defaults. Bx 4 FACTORY Bx 4 FACTORY ▶ Defaults => STORE => M • Press the button. —> The factory defaults are invoked ("FACTORY STORE"). —>...
  • Page 33 5.6 P r o g r a m m i n g v i a t h e C o n t r o l s o f t wa r e —> For basic operations of the software please note the operating in- structions PSW 1000, you will find at “www.mygss.eu”.
  • Page 34 • Herein also perform all settings. • Return to the menu "Data settings" e.g. using button • Click on button to export the configuration. • Enter a file name, select the target directory and store the file. - 34 - HDTV 1200 C CI...
  • Page 35 m P o r t i n g C o n f i g u r at i o n f i l e • Select the cassette in the left window of the PSW 1000 (tree structure) and activate the menu "Data settings" e.g. using button •...
  • Page 36 -id (sid) e rv i C e By default the SIDs are set automatically. When required the SID can be set manually using the control software PSW 1000 (from version 43 on). —> For basic operations of the software please note the operating in- structions PSW 1000, you will find at “www.mygss.eu”.
  • Page 37 • Enter the desired SID in form of a hexadezimal value (e.g. 5678) and click on button —> The changed SID is displayed in section "Input" (tab "Services") and in Section "Output/Remapping" in form of a hexadezimal / dezimal value. —>...
  • Page 38 i n a l Pro C e d u res After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable connections using an appropriate open-ended spanner. • Measure the output levels of the other cassettes and tune them to a uniform output level using the appropriate level controls or software dependent on the head-end station used.
  • Page 39 h a n n e l a n d f r e q u e n C y t a b l e s Advice for a frequency grid (8 MHz) in the band III 114.00 154.00 194.00 234.00 274.00 122.00 162.00 202.00...
  • Page 40 Declaration of CE conformity GSS Grundig Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 703 8877 • Fax: +49 (0) 911 / 703 9210 www.gss.de/en • info@gss.de CLASS CLASS Service: Phone: +49 (0) 911/703 2221; Fax: +49 (0) 911/703 2326; service@gss.de Alterations reserved.
