WRIGHT WC13 Installation Instructions

Door closer

Advertisement

Quick Links

BEFORE STARTING THE INSTALLATION

1. PARTS AND ASSEMBLY DIAGRAM

Tools needed for installation: Hammer, #2 Phillips Head Screwdriver, 1/8" and 5/32" drill bits, Punch, Drill & Tape.
Check that all parts shown in the parts list and in the illustration are present.
Match screw size and type to hardware drawing.
3
5
8

2. LOCATION OF CLOSER ON THE DOOR

Determine whether the door is left or right hand using the following
illustrations. Remember that the CLOSER is always mounted inside the
building near the hinge edge of the door

2A. INWARD OPENING DOOR

This illustration shows the mounting for inward opening doors, as
seen from inside the building.
(RIGHT HAND DOOR)

3. INSTALLATION PROCEDURE

Perform each of the following seven steps in sequence.

3A. POSITIONING TEMPLATE

Templates to help position the CLOSER correctly are provided on an enclosed
sheet, BE SURE TO USE CORRECT TEMPLATE.
For installation of model WC13 or WC14, decide the maximum opening angle
for the door (120° or 155°) before cutting out the template. The template must
be cut differently for each angle.
Compare the requirements of the installation with the speci cations below, to make sure the correct model of
CLOSER will be installed.
Model
Type
Maximum door width
Maximum door weight
Maximum open angle
body mounted on door
6/7
4
6/7
2
(LEFT HAND DOOR)
For Customer Care call: Toll Free 800-562-5625 or info@hamptonproducts.com
WC13/WC14 INSTALLATION INSTRUCTIONS
WC13 / WC14
Listed
Ref No.
1
Body
Main Arm
2
Forearm and Link Arm Shoe
3
4
Main Arm Screw (Hex Head), Lock Washer & Washers
5
Forearm Screw (Pan Head), Lock Washer & Washers
6
Phillips Oval Head Wood Screw #10 x 1-1/4"
7
Phillips Oval Head Self-Tapping Screw 10-32 x 3/4"
1
8
Body Cover
FOR WOOD
( 6 )

2B. OUTWARD OPENING DOOR

This illustration shows the mounting for outward opening doors, as
seen from inside the building.
(RIGHT HAND DOOR)
DOOR CLOSER
UL
38"
140 lb.
120°-
155°
Name of Parts
FOR ALUMINUM
OR STEEL
For Body
and
Link Arm Shoe
( 7 )
(SCREWS SHOWN ACTUAL SIZE)
(LEFT HAND DOOR)
©2015 Hampton Products International Corp.
50 Icon, Foothill Ranch, CA 9 2610-3000 USA
Qty.
1
1
1
1
1
6
6
1
www.hamptonproducts.com
1-800-562-5625
91000_WC13-14_REVA 07/15
#95260000
