Summary of Contents for Glensound Divine
- Page 1 DIVINE PoE Powered Network Audio Loudspeaker User Guide Glensound 6 Brooks Place, Maidstone Kent, UK, ME14 1HE Tel: +44 (0)1622 753662 www.glensound.com...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that there are important operating & maintenance instructions in the This symbol is intended to warn that literature accompanying this unit. dangerous voltages within the product are present and constitute a risk of electric shock. -
Page 4: Product Warranty
PRODUCT WARRANTY All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and... -
Page 5: Eu Declaration Of Conformity
PoE Powered Network Audio Monitor Loudspeaker This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the... -
Page 6: Federal Communications Commission (F.c.c.)
6 Brooks Place, Maidstone, Kent, ME14 1HE, United Kingdom Product Name Divine Product Type/ Model: Active Loudspeaker/ Divine Batch/ Serial Number: 000001 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 7: Rohs Directive
RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%... -
Page 8: Waste Electrical And Electronic Equipment Regulations 2006 (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 8 of 39... -
Page 9: Table Of Contents
Front panel volume control ......................16 Input trim control ........................17 MENU & SETUP ............................. 19 POWERING THE DIVINE ........................28 CONNECTING THE DIVINE TO A DANTE® NETWORK ................29 Controller ........................29 Getting Dante ® Connecting Divine device to the network ................... 29 Audio Over IP Network ........................ -
Page 10: Overview
Standard microphone stand threads are also provided in the base for an alternative support solution. Different preset EQs and an LF cut can all be set in the user menu to allow the Divine to be used for a variety of applications. -
Page 11: Quick Start
QUICK START Connect the Divine to a PoE enabled Ethernet switch or to a PoE midspan PoE injector and onwards to a network switch. Connect a Dante® enabled device to provide source audio to your network (such as Dante® Virtual soundcard running on a PC) Using Dante controller route audio from your Dante®... -
Page 12: Front Panel Controls
FRONT PANEL CONTROLS 1. Select Switch 3. Volume Control 2. Input LEDS 1. Select Switch The select switch has two main functions. A) Each single press of the switch will scroll to the next available input channel(s), the currently selected channel(s) will be highlighted by the LEDs. B) Pressing and holding the select switch will enable the currently selected input channel to have its gain adjusted by +/-16dB by using the front panel volume control. - Page 13 2. Input LEDs The 4 input LEDs main role is to indicate which channel(s) is/ are currently being routed to the loudspeaker. Whichever channels’ LED(s) is/ are on indicate which network audio input(s) is/are being routed to the loudspeaker. The LEDs can also be set in the menu system to act as a PPM (either individually, or as a column).
-
Page 14: Rear Panel Controls
3. Menu Buttons 1. VESA Mounts VESA mount points to allow the Divine to be attached to and supported by a standard pc style monitor arm are provided. They conform to the 75 x 75mm (2.95 x 2.95”) standard and accept 4mm metric threaded screws. - Page 15 3. Display The display is used in conjunction with the menu buttons to set the Divine’s parameters. The display will turn itself off after 30 seconds of inactivity and can be awoken by pressing either of the menu buttons. See the menu section of this handbook for more details.
-
Page 16: Day To Day Operation
DAY TO DAY OPERATION (and hidden functions) Selecting a Source Pushing the select switch will scroll the input source to the next available input (note available inputs can be set in the menu system). If Sum (mixing) is enabled then the enabled sum options will be scrolled through after the individual inputs. -
Page 17: Input Trim Control
All functionality remains the same, the LEDs are just much dimmer for situations when bright LEDs are not desirable. Rear Panel LCD The rear panel LCD can be used to setup the various parameters of the Divine. Page 17 of 39... - Page 18 The rear panel display is normally off and will only turn itself on and show the menu system when either of the rear panel blue buttons are pressed. The two blue buttons are used to navigate through the menu system. Whereby the left button selects the next available menu function and the right button selects the options within a menu.
-
Page 19: Menu & Setup
MENU & SETUP (Listed in order) Menu Function Name: Audio EQ Options within menu: Off, Natural, Normal, Pop Description: These three eq settings alter the output frequency response of the loudspeaker. Natural has a frequency/ level response as per the graph below. Normal is a set of filters designed to emulate the sound of the traditional analogue powered monitors. - Page 20 Pop is a set of filters that our software engineer developed that he liked while he was writing code for the Divine and listening to the unit 8 hours a day. You can tell from the extended HF response that our developer is not straight out of university! The frequency/ level output is as per the below graph.
- Page 21 As such we have included Gain Boost, to increase the incoming signals by a set amount, to allow the full audio output of the Divine to be achieved. Compressor/ limiter circuits are built in so even when gain boost is on and input levels are high the audio output will be as good as possible.
- Page 22 This menu affects the inbuilt delay for input channel 1. The menu is designed to allow the input channel’s audio to be delayed internally within the Divine to match your working environment (i.e. aligning sound to a processed vision feed).
- Page 23 When enabled the frequency/ level output of a filtered channel is as per the below graph. Input Filter Default = No filters set Menu Function Name: Priority 1 Options within menu: Ch 1, Ch 2, Ch 3, Ch 4, None Description: In priority mode when audio is detected on a priority channel the currently selected channel is dimmed by the dim level (see dim level menu) and the priority channel is...
- Page 24 Priority 3 is the highest priority and whichever channel has been set in the priority 3 menu will dim priority 1 and 2 channels (if set) Priority 2 Default = None Menu Function Name: Priority 3 Options within menu: Ch 1, Ch 2, Ch 3, Ch 4, None Description: In priority mode when audio is detected on a priority channel the currently selected channel is dimmed by the dim level (see dim level menu) and the priority channel is...
- Page 25 Input Select Default = Unlocked Menu Function Name: Volume Pot Options within menu: Unlocked, Locked Description: This feature allows the front panel volume pot (potentiometer (knob)) to be disabled (locked). If it is disabled then the currently set volume cannot be changed by the front panel volume control.
- Page 26 Off, 10 sec, 30 secs, 60 secs, 5 min, 15 min, 30 min, 60 min Description: The power save menu, if enabled, allows the Divine to turn off the power to its power amplifier and save energy when no audio is present. During power saving its network...
- Page 27 Note: The Ultimo chipset is a device from Audinate that provides the Dante® network audio processing. SR: SR = This shows the current digital audio sample rate operating within the Divine and being received from the network. Temp: The internal temperature of the Divine’s microprocessor can be shown in both...
-
Page 28: Powering The Divine
PoE is a standard technique for powering equipment from an Ethernet network and the Divine conforms to IEEE 802.3af-2003. The Divine requires a PoE voltage at the source (i.e. network switch) of a minimum of 44 and a maximum of 57 Volts DC. -
Page 29: Connecting The Divine To A Dante® Network
Connecting Divine device to the network The Divine can be connected to the network that you are going to use for your audio distribution simply by plugging in to the RJ45 network connection on the rear. Once connected to the network it will be possible to see the Divine from within the Dante ®... -
Page 30: Running Dante ® Controller
At the time of writing this manual the Dante Controller looks as per the screenshot ® below: The Divine will have been named at the factory during test to allow them to be identified by the Dante controller. ® The format used for the factory name is: ‘DIV-01-sn-XXXXX’... -
Page 31: Device Not Showing Up In Dante Controller
Device not showing up in Dante Controller ® If your Dante device does not show up in Dante Controller then the most likely issue is ® ® that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 32: Aes67 Mode
Audinate. Turning On AES67 Mode If you want to use your Divine on an AES67 network and it has not been set to AES67 mode then this can be set in Dante controller by double clicking the Divine to open ®... -
Page 33: Sending Aes67 Audio
Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select up to 4 channels to be included in the flow then click ‘Create’... -
Page 34: Receiving Aes67 Audio
Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the ® AES67 flows will appear in the Dante Transmitters section in the Routing tab. ® AES67 Restrictions AES67 flows can only be generated with the following constraints: •... -
Page 35: Updating Firmware
There are two ways of finding out the current version of installed DFU and the latest available version. 1) Using the rear LCD screen and menu buttons on the rear of the Divine navigate down to ‘INFO’ and then select ‘DFU’ the currently installed DFU version will be displayed. - Page 36 1) Open GlenController 2) Click the 3 lines 3) Click the settings ICON 4) Click the ‘Maintenance’ spanner Page 36 of 39...
- Page 37 5) Click ‘Enter Maintenance Mode’ 6) Select the device to be updated 7) Click Update Selected Page 37 of 39...
- Page 38 8) Click Start Your device will now have the latest .DFU file loaded. Page 38 of 39...
-
Page 39: Updating The Ultimo .Dfu Firmware
/ AES67 network audio streams. There is one Ultimo Chipset in ® each Divine. We supply special code (a .DNT file) that sets up/ initiates the Ultimo Chipset and makes it work in particular way that is compatible to the Divine.
