SLS smartSLED Quick Start Manual

Quick Start Guide
smartSLED
TM
www.slsrfid.com
2） To insert the battery pack into the battery compartment：
1 The metal contacts at the bottom side of the battery must face down to meet the
metal contacts as shown on the below diagram.
2
Make sure that the locking tabs at the front of the battery are inserted into the
slots as shown in the detailed diagram.
3）
The below image shows the battery in its position. The battery
should be fully secured by the battery spring-loaded clip as shown.
Quick Start Guide
This guide provides simple steps 1) to 8) to let you quickly
start using your new smartSLED

1. Open Box and Check Contents:

2. Install the battery (see pictures of Battery Insertion)

3. Initial Charging of the smartSLED

1）To access the battery compartment, remove the battery cover by:
4）
1
2
5）
smartSLED TM Handheld RFID Reader
TM
smartSLED Handheld RFID Reader
1 TM
2 smartSLED battery
TM
3 smartSLED TM USBCtoACable USB Type C to USB Type A cable for
connecting smartSLED TM to PC or charger
smartSLED TM Quick Start Guide
4
It is important to fully charge the unit before using it the first time. It takes
approximately 4 hours to be fully charged. Please refer to the diagrams for battery
installation. After Inserting the battery into smartSLED
Type C plug to smartSLED TM and connect the Type A plug into any USB charger. The
RED charging LED will light. Charge the unit until the red light goes out.
Battery Insertion
1
First fully rotate to release the metal latches at both sides of the battery cover;
2 Then slide horizontally out to release the battery cover.
1
Replace the battery cover. Make sure that the locking tabs at the
front of the battery cover are fully inserted into the slots as shown in
the below diagram.
Fully rotate to close the metal latches to secure the battery cover in
position.
handheld RFID reader.
:
TM
TM , connect the supplied USB
2
