Instrumentation Industries RTC 15-D Installation & Usage Instructions

G Sterilization / Disinfection
RTC 15-D — RTC 15-P — RTC 22-D — RTC 23-D
These products are designed for Single Patient Reuse.
while installed in a breathing circuit.)
They are packaged as non-sterile; Instrumentation Industries, Inc. recommends processing before initial use.
Discard when replacing the circuit according to facility guidelines.
Recommendations for RTC 15-D, RTC 15-P, RTC 22-D, and RTC 23-D:
Carefully follow facility guidelines for preparing products and solutions for the sterilizing and disinfecting methods and
equipment being used. Sterilization and High Level Disinfection Procedures have been validated for the following equipment
and methods:
Sterilization
STERRAD 100S
Full short sterilization cycle (Hydrogen peroxide gas plasma, 55 minutes, 45°C - 55°C (113°F - 131°F)).
High Level Disinfection
Pasteurization
Pasteurize at 70°C +/- 3°C (153° - 163°F) for a minimum of 30 minutes.
®
CIDEX OPA
Prepare CIDEX ® OPA solution. Totally submerge adapter in the disinfectant. Immerse device completely, eliminating air
pockets, in CIDEX ® OPA solution for a minimum of 12 minutes at 20°C (68°F) to destroy all pathogenic microorganisms.
Remove device from the solution and rinse thoroughly as per these rinsing instructions:
• Following removal from CIDEX ® OPA solution, thoroughly rinse the adapter by immersing it completely in a large volume
(e.g. 2 gallons) of water.
Sterile water rinse is recommended unless potable water is acceptable.
• Keep the device totally immersed for a minimum of 1 minute in duration.
• Manually fl ush all devices with large volumes (not less than 100 mL) of rinse water.
• Remove the device and discard the rinse water. Always use fresh volumes of water for each rinse.
Do not reuse the water for rinsing or any other purpose.
• Repeat the procedure two (2) additional times, for a total of three (3) rinses, with large volumes of fresh water to remove
CIDEX ® OPA solution residues. Residues may cause serious side effects.
• Dry using sterile, lint-free cloths.
DO NOT STEAM AUTOCLAVE RTC 15-D — RTC 15-P — RTC 22-D — RTC 23-D!
RTC 22-A — RTC 23-A
These products are designed to be Reusable. (May be processed up to 30 times at the parameters provided below.)
They are packaged as non-sterile; Instrumentation Industries, Inc. recommends processing before initial use.
Reprocess when replacing the circuit at the parameters provided below.
Recommendations for RTC 22-A and RTC 23-A:
Carefully follow facility guidelines for preparing products and solutions for the sterilizing and disinfecting methods and
equipment being used. Sterilization and High Level Disinfection Procedures have been validated for the following equipment
and methods:
Sterilization
Steam Autoclave
Do not exceed 135°C/275°F.
High Level Disinfection
Pasteurization
Pasteurize at 70°C +/- 3°C (153° - 163°F) for a minimum of 30 minutes.
Cold Chemicals
Recommended Chemical: 2-4% Activated Glutaraldehyde
Disinfect according to validated parameters. Follow the chemical manufacturer's recommendation for temperature and soak
time. Chemical disinfection should be followed by sterile water rinse. Exposure time should be based on the manufacturer's
indication for use as a high-level disinfectant or sterilant.
Do not use alcohol or chemicals containing dimethyl ammonium chloride.
Always carefully examine the physical integrity of this product after processing. Do not use if cracking or crazing is seen,
or if parts fi t together improperly after processing.
iiimedical.com/symbols.pdf
Visit
for the Glossary of Symbols used in
Instrumentation Industries, Inc. labeling.
(Can be used to repeatedly administer medications to one single patient
These user instructions are available in Canadian French
at iiimedical.com
Ces instructions d'utilisation sont disponibles en français
canadien à iiimedical.com
H Product Specifi cations
RTC 15-D
RTC 15-P
Metered
Metered
Dose Inhaler
Dose Inhaler
(MDI) Adapter
(MDI) Adapter
Use: Single Patient Reuse Use: Single Patient Reuse
(see Panel A for info) (see Panel A for info)
Inlet: 15mm O.D. Inlet: 15mm I.D.
Outlet: 15mm I.D. Outlet: 15mm I.D.
Length: 2" Length: 2"
Materials Materials
Body: Polystyrene Butadiene Body: Polystyrene Butadiene
Cap: Thermoplastic Rubber Cap: Thermoplastic Rubber
Color Color
Body: Clear Body: Clear
Cap: Clear Cap: Clear
RTC 22-A RTC 22-D
Metered Metered
Dose Inhaler Dose Inhaler
(MDI) Adapter (MDI) Adapter
Use: Reusable Use: Single Patient Reuse
(see Panel A for info)
Inlet: 22mm I.D. Inlet: 22mm I.D.
Outlet: 15mm I.D./22mm O.D. Outlet: 15mm I.D./22mm O.D.
Length: 2" Length: 2"
Materials Materials
Body: Polyetherimide Body: Polystyrene Butadiene
Cap: Silicone Rubber Cap: Thermoplastic Rubber
Color Color
Body: Amber Body: Clear
Cap: Clear Cap: Clear
RTC 23-D
RTC 23-A
Metered
Metered
Dose Inhaler Dose Inhaler
(MDI) Adapter
(MDI) Adapter
Use: Reusable
Use: Single Patient Reuse
(see Panel A for info)
Inlet: 15mm I.D./22mm O.D. Inlet: 15mm I.D./22mm O.D.
Outlet: 15mm I.D./22mm O.D. Outlet: 15mm I.D./22mm O.D.
Length: 2" Length: 2"
Materials Materials
Body: Polyetherimide Body: Polystyrene Butadiene
Cap: Silicone Rubber Cap: Thermoplastic Rubber
Color Color
Body: Amber Body: Clear
Cap: Clear Cap: Clear
Instrumentation
Industries, Inc.
2990 Industrial Blvd.
Bethel Park, PA 15102
US Toll Free: 1-800-633-8577
Business: 1-412-854-1133
US Toll Free Fax: 1-877-633-8661
Fax: 1-412-854-5668
E-mail: sales@iiimedical.com
www.iiimedical.com
Instrumentation
Industries, Inc.
MDI
Adapter
Installation &
Usage
Directions
RTC 15-D
RTC 15-P
RTC 22-A
RTC 22-D
RTC 23-A
RTC 23-D
For use with metered dose inhaler
canisters, with standard size metal
(.109 inch diameter) or plastic
(.124 inch diameter) stems.
— Not made with Natural Rubber Latex
— Not made with Di(2-ethylhexyl) phthalate (DEHP)
Made in USA
2-18 ECO 2526 Rev. J
