INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER
NOTES TO THE INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical, ANSI Z358.1 and
other applicable codes.
Acorn Safety warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of shipment. Acorn's liability under this warranty shall be discharged solely
by replacement of repair of defective material, provided Acorn is notified in writing within one year from date of
shipment, F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Acorn under this warranty.
Acorn shall not be liable under any circumstances for incidental, consequential or direct charges caused by defects in
materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all other warranties expressed
or implied. Product maintenance instructions are issued with each unit and disregard or non-compliance with these
instructions will constitute an abnormal use condition and void the warranty. Stainless steel must be protected on job
sites during construction and must be properly maintained after the water has been introduced into the safety product
or Acorn's warranty is void.
Acorn Safety
a division of Acorn Engineering
Manual #7109-305-001
Models S0000-AL3
1.800.591.9360
TECHNICAL ASSISTANCE FAX: 1.626.855.4894
LIMITED WARRANTY
UNITED STATES AND CANADA
ACORN SAFETY
P.O. BOX 3527
CITY OF INDUSTRY, CA 91744-0527
UNITED STATES OF AMERICA
WWW.ACORNSAFETY.COM
Revised: 12/10/18
Advertisement
Table of Contents
Summary of Contents for Acorn Safety S0000-AL3
- Page 1 UNITED STATES AND CANADA Acorn Safety warrants that its products are free from defects in material or workmanship under normal use and service for a period of one year from date of shipment. Acorn's liability under this warranty shall be discharged solely by replacement of repair of defective material, provided Acorn is notified in writing within one year from date of shipment, F.O.B.
-
Page 2: Preliminary Steps
2. Separate parts from packaging and verify all necessary parts are accounted for and undamaged. Obtain missing or damaged parts from Acorn Safety prior to beginning installation. 3. Flush water supply lines prior to installation. This will remove unwanted debris from the lines and prevent unwanted blockages in the safety equipment. - Page 3 Installation & Operation Manual ROUGH-IN S0000-AL3 SURFACE MOUNT 3 1 2 " SURFACE MOUNTING ALARM [90] 1 1 4 " 4 7 8 " [125] ALARM HORN HORN / STROBE 2 1 2 " [65] 90 dB AT 10 FEET...
- Page 4 Installation & Operation Manual ELECTRICAL WIRING S0000-AL3 LIGHT SIGNAL SIGNAL LIGHT HORN / STROBE ASSEMBLY BACK WHITE WIRE AND BLACK CONNECTORS BY OTHERS GREEN 4" J-BOX w/ EXTENSION OR ALARM BOX FLOW SWITCH JUNCTION BOX FLOW SWITCH NOTES: WIRE AND CONNECTORS BY...
- Page 5 Installation & Operation Manual ELECTRICAL WIRING S0000-AL3-ASW LIGHT SIGNAL SIGNAL LIGHT HORN / STROBE ASSEMBLY BACK WHITE WIRE AND BLACK CONNECTORS BY OTHERS GREEN SILENCING SWITCH 4" J-BOX w/ EXTENSION OR ALARM BOX FLOW SWITCH JUNCTION BOX FLOW SWITCH NOTES:...
-
Page 6: Supplies Required
Installation & Operation Manual WARNINGS: DO NOT connect AC power to the alarm until directed to in these installation instructions to S0000-AL3 reduce the risk of shock. DO NOT tamper with this device when the signal circuit is energized. Disconnect power... - Page 7 7. Apply power to the circuit and test to verify operation. HANGER PLATE Acorn Safety a division of Acorn Engineering Page 7 of 9 Manual #7109-305-001 Revised: 12/10/18...
- Page 8 1 5 8 " (41) YELLOW BAND WHEN FULLY EXTENDED, A VISIBLE YELLOW BAND WILL APPEAR ON THE PUSHBUTTON SHAFT AT THE REAR OF THE MUSHROOM PUSHBUTTON. Acorn Safety a division of Acorn Engineering Page 8 of 9 Manual #7109-305-001 Revised: 12/10/18...
-
Page 9: Maintenance
HORN 7103-102-000 DPDT FLOW SWITCH, ½” NPT 7103-104-000 DPDT FLOW SWITCH, 1-1/4” NPT 7103-111-001 DPDT FLOW SWITCH, 3/8” NPT 7103-110-001 DPDT FLOW SWITCH, 1” NPT Acorn Safety a division of Acorn Engineering Page 9 of 9 Manual #7109-305-001 Revised: 12/10/18...
