hidealite SLT15W Quick Start Manual

SLT15W-75W 24V
E-nr
Snro
El.nr
Spänning in, Input voltage,
Tulojännite, Spenning inn
Spänning ut, Output voltage,
Lähtöjännite, Spenning ut
Effekt, Rated Power,
Teho, Effekt
Omgivningstemperatur ta, Ambient temperature ta,
Ympäristön lämpötila ta, Omgivelsestemperatur ta
tc C°, Case temperature C°,
Kotelon lämpötila tc C°, tc C°
Anslutning primär, Primary cable,
Ensiökaapeli, Primær tilkobling
Anslutning sekundär, Secondary cable,
Toisiokaapeli, Sekundær tilkobling
SLT15W
(mm)
121
IP20
For explanation of symbols see www.hidealite.se
A
N
220-240V~
L
SLT15W
79 809 38
40 114 23
66 211 05
220-240V
24VDC
15W
Min -20°C Max. 45°C
Max. 80°C
H03VVH2-F 2x0.75mm2
H03VVH2-F 2x0.75mm2
(mm)
45
16
F
110
SLT30W
52 812 53
40 113 02
66 043 34
220-240V
24VDC
30W
Min -20°C Max. 45°C
Max. 80°C
H03VVH2-F 2x0.75mm²
H03VVH2-F 2x0.75mm²
SLT30W
151
41
30
SLT 24V
SLT75W
52 812 99
40 113 22
66 301 48
100-240V
24VDC
75W
Min -20°C Max. 40°C (100V)
Min -20°C Max. 50°C (120-240V)
Max. 80°C
H03VVH2-F 2x0.75mm²,
SPT-2 18AWG
H03VVH2-F 2x0.75mm²,
SPT-2 18AWG
SLT75W
(mm)
180
-
LED LAMP
+
- SLT15 24V Max.15W
- SLT30 24V Max.30W
- SLT75 24V Max.75W
Artnr: IM00008 Version: 2016/01
