geratech EGE-MSI-16x16 Manual

Modüler matrix
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
geratech
EGE-MSI-16x16 Modüler
EGE-MSI-16x16 Modüler
(HDCP - 4Kx2K)
(HDCP - 4Kx2K)
Matrix
Matrix
www.geratech.com.tr
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-MSI-16x16 and is the answer not in the manual?

Questions and answers

Summary of Contents for geratech EGE-MSI-16x16

  • Page 1 ® EGE-MSI-16x16 Modüler EGE-MSI-16x16 Modüler Matrix Matrix (HDCP - 4Kx2K) (HDCP - 4Kx2K) www.geratech.com.tr...

  • Page 2: Table Of Contents

    ® EGE-MSI-16x16 Modüler Matrix CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........5 6.3 RS-232 Protocols .......6...

  • Page 3: Introduction

    ® EGE-MSI-16x16 Modüler Matrix 1. INTRODUCTION The Modularized Matrix series are designed to route the signal of 16 sources to any connected 16 displays, providing resolution up to Full HD 1080p/4Kx2K and WUXGA (1920x1200@60HzRB). Besides the regular matrix functionality, the matrix models are very attractive to the...

  • Page 4: Features

    ® EGE-MSI-16x16 Modüler Matrix 5. FEATURES ‡ HDMI, HDCP 1.1 and DVI 1.0 compliant ‡ Changeable input and output boards ‡ Input and output module types can be mixed and added in increment of 8 from 8x8 up to 16x16 with HDMI, DVI, CAT5e/6/7 and VGA interfaces ‡...

  • Page 5: Operation Controls And Functions

    ® EGE-MSI-16x16 Modüler Matrix 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel STANDBY LOCK POWER RETURN LOCK PAGE MENU SAVE RECALL PAGE OUT/IN ENTER POWER button & LED: Press this button to turn On the device or press it again to switch to standby mode. The LED will illuminate the temperature inside is too high and air circulation is highly suggested.
  • Page 6 ® EGE-MSI-16x16 Modüler Matrix 3. Manual EDID: Support independent EDID by appoint input and output ports. B. IP 1. IP address, 2. Netmask, 3. Gateway. C. Temperature 1. Temperature 1, device inside. D. LCM Contrast Range from 1~4 PAGE displaying the current I/O status or when entering into the menu for detail selection.

  • Page 7: Rear Panel

    ® EGE-MSI-16x16 Modüler Matrix 6.2 Rear Panel IR IN RS232 CONTROL IR ALL SERVICE OUTPUT 0 Note: The above panel is an illustration of HDMI I/O. OUTPUT 1~16: Connect to HD or 3D TV/monitors with HDMI cables up to 16 displays.

  • Page 8: Rs-232 Protocols

    ® EGE-MSI-16x16 Modüler Matrix 6.3 RS-232 Protocols CMSI-1616 Remote Controller Baud Rate: 19200bps Data Bit: 8 bits Parity: None Stop Bit: 1 Flow Control: None www.geratech.com.tr...

  • Page 9: Rs-232 & Telnet Command

    ® EGE-MSI-16x16 Modüler Matrix Command Description Power on. Power off. OxIy Output (x:0~16) set to input (y:1~16). ALLOUT x All output set to input (x:01~16). ACTIVE Report I/O active channels. INDETECT Input channels detect indicator. OUTDETECT Output channels detect indicator.
  • Page 10 ® EGE-MSI-16x16 Modüler Matrix HPDL x Pull the input(x:01~16) Hot-Plug-Detect signal to 'LOW'. HPDH x Pull the input(x:01~16) Hot-Plug-Detect signal to 'HIGH'. HPDLALL Set all input HPD to Low. HPDHALL Set all input HPD to High. HPDSTATUS Report all input Hot-Plug-Detect signal status.

  • Page 11: Telnet Control

    ® EGE-MSI-16x16 Modüler Matrix RESET System Reset to O1I1,O2I2,O3I3,O4I4,O5I5..VERSION Note: All the command will be not executed unless followed with a carriage return. Commands are case-insensitive 6.5 Telnet Control Before attempting to use the telnet control, please ensure that both the Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are connected to the active networks.
  • Page 12 ® EGE-MSI-16x16 Modüler Matrix Once in the command line interface (CLI) type "telnet", then the IP address of the unit and "23", then hit enter. Note: The IP address of the Matrix can be displayed on the device's LCM monitor by pressing the Menu button twice.

  • Page 13: Web Gui Control

    ® EGE-MSI-16x16 Modüler Matrix type “RSTIP” and to use a set static IP, type ”SETIP” (For a full list of commands, see Section 6.4). Note: Any commands will not be executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly.
  • Page 14 ® EGE-MSI-16x16 Modüler Matrix geratech ® Clicking on the 'User Setting' tab allows you to reset the IP any of the settings are changed. The IP address needed to access the Web GUI control will also need to be changed accordingly on the web address entry bar.

  • Page 15: Connection Diagram

    ® EGE-MSI-16x16 Modüler Matrix 7. CONNECTION DIAGRAM Output Display TV/Monitors up to 16 RS232 Equipped PC or Notebook Wireless Router IR IN RS232 CONTROL IR ALL SERVIC UTPUT 0 Input Source equipments up to 16 Power Supply www.geratech.com.tr...
  • Page 16 ® EGE-MSI-16x16 Modüler Matrix 8. SPECIFICATIONS Input ports 16 x HDMI or DVI or CAT5e/6/7 or VGA Output ports 16 x HDMI or DVI or CAT5e/6/7 Power Supply 2 x AC 110~240V (US/EU standards, HMDI Cable I/O Distance 15m/8-bits, 10m/12-bits...
  • Page 17 ® EGE-MSI-16x16 Modüler Matrix CIN-8HS4K 8 ports 4Kx2K HDMI input module Video Bandwidth 25~340MHz Input ports 8 * HDMI Video resolutions PC: VGA ~WUXGA HD: 480i~1080p, 4Kx2K@30Hz Audio transmission LPCM7.1CH, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio (32~192KHz Fs sample...
  • Page 18 ® EGE-MSI-16x16 Modüler Matrix COUT-8HS 8 ports HDMI output module Video Bandwidth 225MHz/6.75Gbps Input ports 8 * HDMI Video resolutions PC: VGA ~WUXGA@60RB HD: 480i~1080p Audio transmission LPCM7.1CH, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio (32~192KHz Fs sample...
  • Page 19 ® EGE-MSI-16x16 Modüler Matrix COUT-8CVL-3PLAY 8 ports HDBaseT output module Video Bandwidth 225MHz/6.25Gbps Features Support HDBaseT/IR/RS232 Output ports 8 * CAT5e/6, 8 * IR Extender, 8 * IR Blaster Video resolutions PC: VGA ~ WUXGA HD: 480i~1080p IR Frequency...

  • Page 20: Acronyms

    ® EGE-MSI-16x16 Modüler Matrix IR Frequency 30~50Hz Audio transmission LPCM7.1CH, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio (32~192KHz Fs sample rate) COUT-8CVL-3PLAY Cable Distance Cable Range Pixel clock Video Data Supported Video Type rate Rate CAT5e/6/7 60 m <=225 MHz <=5.3 Gbps...
  • Page 21 (JH5DWH (OHNWURQLN 0K YH 7LF /WG ùWL 3HUSD 7LFDUHW 0HUNH]L $%ORN .DW 1R   ùLúOL  ø67$1%8/ Tel: (212) 220 34 83 Fax: (212) 220 76 35 info@egerate.com...
