Summary of Contents for Xilence INTERCEPTOR
-
Page 1: Table Of Contents
Content Product Introduction Specifications INTERCEPTOR Specifications INTERCEPTORPRO Accessory INTERCEPTOR & INTERCEPTORPRO Additional Accessory INTERCEPTORPRO: Installation Removing the Side Panel Installing the motherboard Installing the DVD drive Installing hard drives Installing 2.5“ hard drives/SSDs Installing the power supply unit Installing the fan in the side panel... -
Page 2: Product Introduction
Product Introduction Specifications INTERCEPTOR Dimensions 230 (W) x 580 (H) x 605 (L) mm Material SECC Front Panel: ABS + Mesh Design Device & HDD 4x 5.25“ (exposed) 4x 2.5” (Hot Swappable Tray) 6x 3.5” (Hot Swappable Tray) 2x 3.5“ (internal) -
Page 3: Specifications Interceptorpro
Specifications INTERCEPTORPRO Dimensions 230 (W) x 780 (H) x 605 (L) mm Material SECC Front Panel: ABS + Mesh Design Device & HDD 6x 5.25“ (exposed) 4x 2.5” (Hot Swappable Tray) 8x 3.5” (Hot Swappable Tray) 2x 3.5“ (internal) PCI-Slots Front Ports Main Case: 1x USB 3.0 + 2x USB 2.0 + HD Audio + Reset + Power... -
Page 4: Accessory Interceptor & Interceptorpro
Accessory INTERCEPTOR & INTERCEPTORPRO • User Manual (1x) • Pedestals / Supporting Feet (2x) • Cable Strap 80mm (5x) • Screw bag containing the following screws: Pedestal Screw Case Screw M4*10 6#6HW-TC Standoff HDD Screw Thumb Screw Motherboard 5H-6#*4- 6#*6.5HCu... -
Page 5: Installation
Installation Removing the Side Panel Remove the thumb screws from the Then pull the side panel rearwards. rear side of the case. INTERCEPTORPRO only: To open the To close again place the side panel into the guide rails and push it for- upper system, press the opening me- wards with care. -
Page 6: Installing The Motherboard
Installing the motherboard PLEASE NOTE: CPU, RAM and any peripheral installations are not included in this manual. Please refer to your motherboard manual for related installation instructions and troubleshooting Place the standoffs in positions that suit your motherboard. Installing the DVD drive Remove the desired DVD drive panel Then push the pre-installed screw in from the front and insert the DVD... -
Page 7: Installing Hard Drives
Installing hard drives Open the front panel on the left hand Push the opening mechanism to the side. left to release the lever. Pull the drive plug-in module out of Fix the 2.5“ or 3.5“ SATA drive in place the case. with the screws supplied. -
Page 8: Installing 2.5" Hard Drives/Ssds
On the INTERCEPTORPRO you will The cabling for all hard drives is only performed once. Behind the HDD find two more HDD plug-in modules plug-in modules you will find several at the top of the case. boards that you should connect in advance. - Page 9 Unlock the 2.5“ plug-in module. Insert the drive with the connections Now close the plug-in slot carefully facing rearwards. Please ensure that and replace the cover with care. the drive sits in the four fixing points.
-
Page 10: Installing The Power Supply Unit
Installing the power supply unit Install the power supply unit in the If you are using a power supply from the XO series that makes use of Direct lower part of the case. In doing so you have a free choice of where to place Airflow Technology, we recommend the fan. -
Page 11: Installing The Fan In The Side Panel
Installing the fan in the side panel The side fan should be installed as You can now remove this completely, giving you open access to the screw follows: Remove the three highlighted screws and gently push the plastic cap holes. It is possible to install either rearwards. -
Page 12: Removing The Top Of The Case
Removing the top of the case To install the fan/radiator with ease Then carefully pull the top panel towards the rear of the case. you can remove the top of the case in just a few steps. Remove the two thumb screws as illustrated. -
Page 13: Interceptorpro: Installing An Extra Itx-System
2.11 INTERCEPTORPRO: Installing an Extra ITX-System The ITX panel and the holding bay You can now insert the motherboard and fix it in place with four screws. The are installed during manufacture. To simplify the installation we recom- case offers you the chance to install an mend removing the top of the case independent single slot graphics card. -
Page 14: Installing The Supporting Feet / Pedestals
2.13 Installing the Supporting Feet / Pedestals The supporting feet supplied with the case should be installed using the M4*10mm screws provided. These can simply be screwed into the underside of the case.
