Summary of Contents for Showgear VIBE FX Polar Beat
- Page 1 MANUAL ENGLISH VIBE FX Polar Beat Ordercode: 950300 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
VIBE FX Polar Beat Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Laser Safety For a Class 2 Laser Product ........................5 Rigging .................................... 7 Connection with the mains............................7 Return Procedure ................................8 Claims .................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showgear VIBE FX Polar Beat ● Audio cable (0,6 m) ●... - Page 4 VIBE FX Polar Beat Please consider that damages caused by manual modifications to the device are not subject to warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only. IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the device.
-
Page 5: Operating Determinations
● If your Showgear device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showgear dealer for service. -
Page 6: Laser Safety For A Class 2 Laser Product
VIBE FX Polar Beat Laser Safety For a Class 2 Laser Product Laser Light is different from any other light source with which you may be familiar with. The light from this product can potentially cause instant eye injury if not set up and used properly. - Page 7 VIBE FX Polar Beat The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use. Further guidelines and safety programs for safe use of lasers can be found in the ANSI Z136.1 Standard “For Safe Use of Lasers”, available from www.laserinstitute.org.
-
Page 8: Rigging
Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! The VIBE FX Polar Beat can ONLY be placed on a flat stage floor. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. -
Page 9: Return Procedure
VIBE FX Polar Beat Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 10: Description Of The Device
VIBE FX Polar Beat Description of the device Features The VIBE FX Polar Beat is a combination of a laser effect, speaker and a Bluetooth device. ● Power supply: 5V/1A DC power adapter (not included) ● Laser class: 2 ●... -
Page 11: Backside
VIBE FX Polar Beat Backside Fig. 02 03) LED indicator The LED indicator shows the current status of the Polar Beat. Bluetooth mode: ● When the Polar Beat is not paired with an external Bluetooth device, the LED will flash in blue. -
Page 12: Installation
Move the switch to the center, to switch the Polar Beat off. 08) Bracket Installation Remove all packing materials from the VIBE FX Polar Beat. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 13: Power On/Off
04) The electric power supply cables must not show any damages or material fatigue. The VIBE FX Polar Beat requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. -
Page 14: Troubleshooting
Suspect three potential problem areas as: the power supply, the laser and the LEDs. 01) Power supply. Check if the unit is plugged into an appropriate power supply. 02) The laser. Return the Polar Beat to your Showgear dealer. 03) The LEDs. Return the Polar Beat to your Showgear dealer. -
Page 15: Product Specifications
VIBE FX Polar Beat Product Specifications Model: Showgear VIBE FX Polar Beat Power supply: 5V/1A DC power adapter (not included) Dimensions: 142 x 80 x 80 mm (LxWxH) Weight: 0,4 kg Electro-mechanical effects Laser class: Light source: 1 x 3W Blue LED... - Page 16 ©2017 Showgear...
