Page 1 Manual WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Fieldbus Coupler Modbus TCP; Generation 4 Version 1.0.2...
Page 2 We wish to point out that the software and hardware terms as well as the trademarks of companies used and/or mentioned in the present manual are generally protected by trademark or patent. WAGO is a registered trademark of WAGO Verwaltungsgesellschaft mbH. Manual Version 1.0.2...
Page 3: Table Of Contents
WAGO-I/O-SYSTEM 750 Table of Contents 750-362 FC Modbus TCP; G4 Table of Contents Notes about this Documentation .............. 9 Validity of this Documentation ..............9 Copyright....................9 Property rights..................10 Symbols ....................11 Number Notation ..................13 Font Conventions ................... 13 Important Notes ..................
Page 4 WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 3.6.2 Fieldbus Cables................. 46 3.6.3 Shielded Signal Lines ................ 47 3.6.4 WAGO Shield Connecting System ............ 47 Device Description ................... 48 View ....................... 50 Connectors ..................... 52 4.2.1 Device Supply ................... 52 4.2.2 Fieldbus Connection................
Page 5 Assigning IP Address via Address Selection Switch ......85 8.3.2 Assigning IP Address via DHCP ............87 8.3.2.1 Enable DHCP via "WAGO Ethernet Settings" (without existing IP address)" ..................89 8.3.2.2 Enable DHCP via WBM (with existing IP address) ....... 90 8.3.3...
Page 6 Table of Contents WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.1 Implemented Protocols ................ 139 11.1.1 Communication Protocols ............... 139 11.1.1.1 IP (Internet Protocol) ..............139 11.1.1.2 TCP (Transmission Control Protocol) ......... 144 11.1.1.3 UDP (User Datagram Protocol) ..........144 11.1.2...
Page 7: Table Of Contents
WAGO-I/O-SYSTEM 750 Table of Contents 750-362 FC Modbus TCP; G4 12.2.1.5 4 Channel Digital Input Modules ..........198 12.2.1.6 8 Channel Digital Input Modules ..........198 12.2.1.7 8 Channel Digital Input Module NAMUR with Diagnostics and Output Process Data ..............198 12.2.1.8...
Page 8 Table of Contents WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.5.19 Proportional Valve Module ............231 12.2.5.20 M-Bus Master Module ..............232 12.2.5.21 IO-Link Master ................232 12.2.5.22 CAN Gateway ................233 12.2.5.23 Servo Stepper Controller ............234 12.2.5.24 SMI Master Module ..............235 12.2.5.25...
Page 9: Notes About This Documentation
Manual by third parties that violate pertinent copyright provisions is prohibited. Reproduction, translation, electronic and phototechnical filing/archiving (e.g., photocopying) as well as any amendments require the written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany. Non-observance will involve the right to assert damage claims. Manual...
Page 10: Property Rights
Notes about this Documentation WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Property rights Third-party trademarks are used in this documentation. This section contains the trademarks used. The “®” and “TM” symbols are omitted hereinafter. • Adobe and Acrobat are registered trademarks of Adobe Systems Inc.
Page 11: Symbols
WAGO-I/O-SYSTEM 750 Notes about this Documentation 750-362 FC Modbus TCP; G4 Symbols Personal Injury! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury. Personal Injury Caused by Electric Current! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury.
Page 12 Notes about this Documentation WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Additional Information: Refers to additional information which is not an integral part of this documentation (e.g., the Internet). Manual Version 1.0.2...
Page 13: Number Notation
Font Conventions Table 2: Font Conventions Font Type Indicates italic Names of paths and data files are marked in italic-type. e.g.: C:\Program Files\WAGO Software Menu Menu items are marked in bold letters. e.g.: Save > A greater-than sign between two names means the selection of a menu item from a menu.
Page 14: Important Notes
2.1.1 Subject to Changes WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any alterations or modifications. WAGO Kontakttechnik GmbH & Co. KG owns all rights arising from the granting of patents or from the legal protection of utility patents.
Page 15: Technical Condition Of Specified Devices
These modules contain no parts that can be serviced or repaired by the user. The following actions will result in the exclusion of liability on the part of WAGO Kontakttechnik GmbH & Co. KG: •...
Page 16: 2.1.4.1.2 Packaging
Important Notes WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 be disposed of properly after use. WEEE 2012/19/EU applies throughout Europe. Directives and laws may vary nationally. Environmentally friendly disposal benefits health and protects the environment from harmful substances in electrical and electronic equipment.
Page 17: Safety Advice (Precautions)
WAGO-I/O-SYSTEM 750 Important Notes 750-362 FC Modbus TCP; G4 Safety Advice (Precautions) For installing and operating purposes of the relevant device to your system the following safety precautions shall be observed: Do not work on devices while energized! All power sources to the device shall be switched off prior to performing any installation, repair or maintenance work.
Page 18 Important Notes WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Do not use in telecommunication circuits! Only use devices equipped with ETHERNET or RJ-45 connectors in LANs. Never connect these devices with telecommunication networks. Ensure proper contact with the DIN-rail! Proper electrical contact between the DIN-rail and device is necessary to maintain the EMC characteristics and function of the device.
Page 19 WAGO-I/O-SYSTEM 750 Important Notes 750-362 FC Modbus TCP; G4 Avoid electrostatic discharge! The devices are equipped with electronic components that may be destroyed by electrostatic discharge when touched. Please observe the safety precautions against electrostatic discharge per DIN EN 61340-5-1/-3. When handling the devices, please ensure that environmental factors (personnel, work space and packaging) are properly grounded.
Page 20: Special Use Conditions For Ethernet Devices
Please note the following when using ETHERNET devices in your system: • Do not connect control components and control networks directly to an open network such as the Internet or an office network. WAGO recommends putting control components and control networks behind a firewall. •...
Page 21: System Description
The communication between the fieldbus coupler/controller and the I/O modules is carried out via a local bus. The components of the WAGO I/O SYSTEM 750 have clear termination points, light emitting diodes for status display, plug-in mini WSB tags and group marker cards for labeling.
Page 22: Labeling
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Labeling The front labeling includes: Device designation Name of the display elements, connections and control elements Serial number with hardware and firmware version The side labeling includes: Manufacturer's identification Connector pin assignment...
Page 23: Manufacturing Number
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 3.1.2 Manufacturing Number The serial number indicates the delivery status directly after production. Figure 2: Marking Area for Serial Numbers There are two serial numbers in two rows in the side marking. They are left of the release tab.
Page 24: Hardware Address (Mac-Id)
The MAC ID has a fixed length of 6 bytes (48 bits) which are presented hexadecimal. The first three bytes identify the manufacturer (e.g. 00:30 DE for WAGO). The second 3 bytes comprise the unique serial number of the hardware. 3.1.4...
Page 25: Storage, Assembly And Transport
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 Storage, Assembly and Transport Whenever possible, the components are to be stored in their original packaging. Likewise, the original packaging provides optimal protection during transport. When assembling or repacking the components, the contacts must not be soiled or damaged.
Page 26: Assembly Guidelines/Standards
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Assembly Guidelines/Standards • DIN 60204 Electrical equipment of machines • DIN EN 50178 Electronic equipment for use in power installations (replacement for VDE 0160) • EN 60439 Low-voltage switchgear and controlgear assemblies Manual Version 1.0.2...
Page 27: Power Supply
Therefore, you should always dimension the overcurrent protection according to the anticipated power usage. The system and field voltage of the WAGO-I/O-SYSTEMs 750 is supplied on the head stations and bus supply modules. For components that work with extra low voltage, only SELV/PELV voltage sources should be used.
Page 28: Isolation
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 3.4.2 Isolation Within the fieldbus node, there are three electrically isolated potentials: • Electrically isolated fieldbus interface via transformer • Electronics of the fieldbus couplers/controllers and the I/O modules (local bus) •...
Page 29: System Supply
System Supply 3.4.3.1 Connection The WAGO-I/O-SYSTEM 750 requires a 24 V direct current system supply. The power supply is provided via the fieldbus coupler/controller and, if necessary, in addition via internal system supply modules 750-613. The power supply is reverse voltage protected.
Page 30: Dimensioning
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 System supply only with appropriate fuse protection! Without overcurrent protection, the electronics can be damaged. For 24V system supply input voltage an external fuse, rated max. 2 A, slow acting, min. 30 VDC shall be used.
Page 31: Table 6: Alignment
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 Table 6: Alignment Internal current consumption Current consumption via system voltage (5 V for electronics of I/O modules and fieldbus coupler/controller). Total current for I/O modules Available current for the I/O modules.
Page 32 Consequently, an internal system supply module (750-613), e. g. in the middle of the node, should be added. Recommendation Utilize the smartDESIGNER feature WAGO ProServe software to configure ® fieldbus node assembly. You can test the configuration via the integrated plausibility check.
Page 33: Field Supply
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 Fieldbus coupler or controller = Sum of all the internal current consumption of the (5 V) total connected I/O modules + internal current consumption of the fieldbus coupler/controller Internal system supply module...
Page 34: Figure 7: Field Supply (Sensor/Actuator)
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Figure 7: Field Supply (Sensor/Actuator) Table 7: Legend for Figure “Field Supply (Sensor/Actuator) for ECO Fieldbus Coupler” Field supply 24 V (-15 % / +20 %) Optional ground potential (functional earth)
Page 35: Fusing Via Power Supply Module
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 Re-establish the ground connection when the connection to the power jumper contacts is disrupted! Some I/O modules have no or very few power contacts (depending on the I/O function). Due to this, the passing through of the relevant potential is disrupted. If you require a field supply via power jumper contacts for subsequent I/O modules, then you have to use a power supply module.
Page 36: Figure 8: Supply Module With Fuse Carrier (Example 750-610)
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Figure 8: Supply Module with Fuse Carrier (Example 750-610) Observe the maximum power dissipation and, if required, UL requirements! In the case of power supply modules with fuse holders, you must only use fuses with a maximum dissipation of 1.6 W (IEC 127).
Page 37: Figure 9: Removing The Fuse Carrier
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 In order to insert or change a fuse, or to switch off the voltage in succeeding I/O modules, the fuse holder may be pulled out. In order to do this, use a screwdriver for example, to reach into one of the slits (one on both sides) and pull out the holder.
Page 38: Fusing External
The 24V input voltage for the field supply is provided with an external fuse with max. 10 A slow acting, min. 30 VDC, to be secured. For the external fusing, the fuse modules of the WAGO series 282, 2006, 281 and 2002 are suitable for this purpose.
Page 39: Figure 15: Fuse Modules With Pivotable Fuse Carrier, Series 2002
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 Figure 15: Fuse Modules with Pivotable Fuse Carrier, Series 2002 Manual Version 1.0.2...
Page 40: Supplementary Power Supply Regulations
750-362 FC Modbus TCP; G4 3.4.5 Supplementary Power Supply Regulations The WAGO-I/O-SYSTEM 750 can also be used in shipbuilding or offshore and onshore areas of work (e. g. working platforms, loading plants). This is demonstrated by complying with the standards of influential classification companies such as Germanischer Lloyd and Lloyds Register.
Page 41: Supply Example
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 3.4.6 Supply Example SupplSggggggggggggggggg The system supply and the field supply shall be separated! You should separate the system supply and the field supply in order to ensure bus operation in the event of a short-circuit on the actuator side.
Page 42: Table 10: Legend For Figure "Supply Example For Fieldbus Coupler/Controller
System Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 10: Legend for Figure “Supply Example for Fieldbus Coupler/Controller” Pos. Description Power Supply on fieldbus coupler/controller via external Supply Module Power Supply with optional ground Internal System Supply Module Separation Module recommended...
Page 43: Power Supply Unit
750-362 FC Modbus TCP; G4 3.4.7 Power Supply Unit The WAGO-I/O-SYSTEM 750 requires a 24 VDC voltage (system supply). Recommendation A stable power supply cannot always be assumed everywhere. Therefore, you should use regulated power supplies to ensure the quality of the supply voltage.
Page 44: Grounding
The optimal setup is a metallic assembly plate with grounding connection which is electrically conductive linked to the carrier rail. The separate grounding of the carrier rail can be easily set up with the aid of the WAGO ground wire terminals. Table 11: WAGO Ground Wire Terminals Order No. Description 283-609 1-conductor ground (earth) terminal block make an automatic contact to the carrier rail;...
Page 45: Grounding Function
WAGO-I/O-SYSTEM 750 System Description 750-362 FC Modbus TCP; G4 3.5.2 Grounding Function The grounding function increases the resistance against electro-magnetic interferences. Some components in the I/O system have a carrier rail contact that dissipates electro-magnetic interferences to the carrier rail.
Page 46: Shielding
Higher shielding performance is achieved via low-impedance connection between shield and ground. For this purpose, connect the shield over a large surface area, e.g., WAGO shield connecting system. This is especially recommended for large-scale systems where equalizing current or high impulse- type currents caused by atmospheric discharge may occur.
Page 47: Shielded Signal Lines
I/O module can be achieved even in the presence of interference acting on the signal cable. On some WAGO devices you can directly clamp the shield. For all other devices use the WAGO shield connecting system.
Page 48: Device Description
750-362 FC Modbus TCP; G4 Device Description The 750-362 Fieldbus Coupler connects as the head station of the node assembly the WAGO-I/O-SYSTEM 750 or 753 to the ETHERNET fieldbus system. This head station can be used for applications in machine and plant construction as well as in the process industry and building technology.
Page 49 WAGO-I/O-SYSTEM 750 Device Description 750-362 FC Modbus TCP; G4 The Modbus TCP/UDP protocol is implemented for exchanging process data. For the management and diagnosis of the system, the HTTP and SNMP protocols are available. For the data transfer via ETHERNET the FTP and SFTP are available.
Page 50: View
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 View The view below shows the different parts of the device: • The fieldbus connection is within the lower range on the left side. • Over the fieldbus connection is a power supply unit for the system supply.
Page 51: Table 12: Legend For Figure "View
WAGO-I/O-SYSTEM 750 Device Description 750-362 FC Modbus TCP; G4 Table 12: Legend for Figure “View” Desig- Pos. Meaning Details see Section nation LINK ACT „Device Description“ > 1, 2, MS, Status LEDs Fieldbus „Display Elements“ NS, I/O Marking possibility on four miniature WSB markers "Connect Devices"...
Page 52: Connectors
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Connectors 4.2.1 Device Supply The device is powered via terminal blocks with CAGE CLAMP connections. ® The device supply generates the necessary voltage to power the electronics of the device and the internal electronics of the connected I/O modules.
Page 53: Fieldbus Connection
WAGO-I/O-SYSTEM 750 Device Description 750-362 FC Modbus TCP; G4 4.2.2 Fieldbus Connection The connection to the fieldbus is made via two RJ-45 plugs, which are connected to the fieldbus controller via an integrated switch. The integrated switch works in store-and-forward operation and for each port, supports the transmission speeds 10/100 Mbit as well as the transmission modes full and half-duplex and autonegotiation.
Page 54: Display Elements
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Display Elements The operating condition of the fieldbus coupler or the node is displayed with the help of illuminated indicators in the form of light-emitting diodes (LEDs). The LED information is routed to the top of the case by light guides. In some cases, the LEDs are multi-colored (red, green or orange).
Page 55: Operating Elements
4.4.1 Service Interface The service interface is located behind the flap. It is used for the communication with the WAGO I/O-CHECK and WAGO Ethernet Settings. Figure 26: Service Interface (Closed and Opened Flap) Table 16: Legend for Figure “Service Interface (Closed and Opened Flap)”...
Page 56: Address Selection Switch
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 4.4.2 Address Selection Switch Figure 27: Address Selection Switch (for example setting “0“) Using the address selection switch, the device can be assigned a fixed IP address. The set value corresponds to the last digit of the IP address (host ID). The complete IP address consists of the base IP address stored in the device (factory setting: 192.168.1.0) and the host ID set on the address selection switch...
Page 57: Technical Data
DHCP, DNS, SNTP, (S)FTP, SNMP Max. number of socket links 15 Modbus TCP Number of I/O modules - with bus extension Configuration via WBM, DIP Switch, WAGO Ethernet Settings Internal file system 1 GB 4.5.3 Supply Table 4: Technical Data - Supply Voltage Supply 24 V DC (-25% ...
Page 58: Fieldbus Modbus Tcp
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Buffer for system power supply! The system power supply must be buffered to bridge power outages. As the power demand depends on the respective node configuration, buffering is not implemented internally.
Page 59: Climatic Environmental Conditions
WAGO-I/O-SYSTEM 750 Device Description 750-362 FC Modbus TCP; G4 4.5.7 Climatic Environmental Conditions Table 22: Technical Data – Climatic Environmental Conditions Surrounding air temperature, operation 0 °C … 55 °C Surrounding air temperature, storage −25 °C … +85 °C Operating altitude 0 …...
Page 60: Mechanical Strength
Acc. IEC 60068-2-32 ≤ 1 m (module in original packing) 4.5.9 Software Compatibility Table 24: Technical Data – Software Compatibility WAGO-I/O-CHECK 759-302 Commissioning software starting from version 3.18.1.2 WAGO Ethernet Settings 759-316 Configuration software starting from version 6.9.9.16 Manual Version 1.0.2...
Page 61: Approvals
Approvals More information about approvals. Detailed references to the approvals are listed in the document “Overview Approvals WAGO I/O SYSTEM 750”, which you can find via the internet under: www.wago.com  DOWNLOADS  Documentation  System Description. The following approvals have been granted to 750-362 fieldbus...
Page 62: Standards And Guidelines
Device Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Standards and Guidelines 750-362 meets the following requirements on emission and immunity of interference: EMC CE-Immunity to interference EN 61000-6-2 EMC CE-Emission of interference EN 61000-6-3 EMC marine applications-Immunity to interference acc.
Page 63: Mounting
Use an end stop in the case of vertical mounting! In the case of vertical assembly, an end stop has to be mounted as an additional safeguard against slipping. WAGO order no. 249-116 End stop for DIN 35 rail, 6 mm wide WAGO order no. 249-117...
Page 64 Mounting WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Increase the total length using a coupler module for internal data bus extension! You can increase the total length of a fieldbus node by using a 750-628 I/O Module (coupler module for internal data bus extension). For such a configuration, attach a 750-627 I/O Module (end module for internal data bus extension) after the last I/O module of a module assembly.
Page 65: Mounting Onto Carrier Rail
WAGO Kontakttechnik GmbH & Co. KG supplies standardized carrier rails that are optimal for use with the I/O system. If other carrier rails are used, then a technical inspection and approval of the rail by WAGO Kontakttechnik GmbH & Co. KG should take place.
Page 66: Wago Din Rails
Mounting WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 5.3.2 WAGO DIN Rails WAGO carrier rails meet the electrical and mechanical requirements shown in the table below. Table 25: WAGO DIN Rails Item No. Description 210-112 35 × 7.5; 1 mm; steel; bluish, tinned, chromed; slotted 210-113 35 ×...
Page 67: Mounting Sequence
Always plug a bus end module (750-600) onto the end of the fieldbus node! You must always use a bus end module at all fieldbus nodes with WAGO I/O SYSTEM 750 fieldbus couplers or controllers to guarantee proper data transfer.
Page 68: Inserting And Removing Devices
Mounting WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Inserting and Removing Devices Do not work when devices are energized! High voltage can cause electric shock or burns. Switch off all power to the device prior to performing any installation, repair or maintenance work.
Page 69: Inserting The Fieldbus Coupler/Controller
WAGO-I/O-SYSTEM 750 Mounting 750-362 FC Modbus TCP; G4 5.6.1 Inserting the Fieldbus Coupler/Controller When replacing the fieldbus coupler/controller for an already available fieldbus coupler/controller, position the new fieldbus coupler/controller so that the tongue and groove joints to the subsequent I/O module are engaged.
Page 70: Inserting The I/O Module
Mounting WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 5.6.3 Inserting the I/O Module Position the I/O module so that the tongue and groove joints to the fieldbus coupler or controller or to the previous or possibly subsequent I/O module engaged.
Page 71: Removing The I/O Module
WAGO-I/O-SYSTEM 750 Mounting 750-362 FC Modbus TCP; G4 5.6.4 Removing the I/O Module Remove the I/O module from the assembly by pulling the release tab. Figure 32: Removing the I/O Module (Example) Electrical connections for data or power jumper contacts are disconnected when removing the I/O module.
Page 72: Connect Devices
Connect Devices WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Connect Devices Data Contacts/Local Bus Communication between the fieldbus coupler/controller and the I/O modules as well as the system supply of the I/O modules is carried out via the local bus. The contacting for the local bus consists of 6 data contacts, which are available as self-cleaning gold spring contacts.
Page 73: Power Contacts/Field Supply
I/O modules have male contacts on the left side. Figure 34: Example for the Arrangement of Power Contacts Field bus node configuration and test via smartDESIGNER With the WAGO ProServe Software smartDESIGNER, you can configure the ® structure of a fieldbus node. You can test the configuration via the integrated accuracy check.
Page 74: Connecting A Conductor To The Cage Clamp
Do not connect more than one conductor at one single connection! If more than one conductor must be routed to one connection, these must be connected in an up-circuit wiring assembly, for example using WAGO feed- through terminals. For opening the CAGE CLAMP insert the actuating tool into the opening ®...
Page 75: Function Description
WAGO-I/O-SYSTEM 750 Function Description 750-362 FC Modbus TCP; G4 Function Description Operating System After master configuration and electrical installation of the fieldbus station, the system is operative. The coupler begins running up after switching on the power supply or after a reset.
Page 76: Process Data Architecture
Function Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Process Data Architecture 7.2.1 Basic Structure After switching on the supply voltage, the fieldbus coupler identifies all I/O modules connected with the node that send or receive data (data width/bit width >...
Page 77: Process Data Modbus Tcp
For some I/O modules and their different versions, the structure of the process data depends on the fieldbus. Additional information about the fieldbus specific process image For the fieldbus-specific process image of any WAGO I/O Module, please refer to the section “Structure of the Process Data”. 7.2.2...
Page 78: Data Exchange
Modbus TCP works according to the master/slave principle. The master controller can be a PC or a PLC. The fieldbus couplers of the WAGO-I/O-SYSTEM 750 are slave devices. The master requests communication. This request can be directed to certain nodes by addressing. The nodes receive the request and, depending on the request type, send a reply to the master.
Page 79: Memory Space
WAGO-I/O-SYSTEM 750 Function Description 750-362 FC Modbus TCP; G4 7.3.1 Memory Space Figure 37: Memory Areas and Data Exchange The fieldbus coupler process image contains the physical data for the bus modules. These have a value of 0 ... 255 and word 512 ... 1275.
Page 80: Addressing Of I/O Modules
Function Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 7.3.2.1 Addressing of I/O Modules Addressing first references complex modules (modules that occupy several bytes) in accordance with their physical order downstream of the fieldbus coupler/controller; i.e., they occupy addresses starting from word 0.
Page 81: Data Exchange Between Modbus/Tcp Master And I/O Modules
WAGO-I/O-SYSTEM 750 Function Description 750-362 FC Modbus TCP; G4 7.3.3 Data Exchange between MODBUS/TCP Master and I/O Modules Data exchange between the MODBUS/TCP Master and the I/O modules is conducted using the MODBUS functions implemented in the controller by means of bit-by-bit or word-by-word reading and writing routines.
Page 82 Function Description WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Register functions start at address 0x1000. These functions can be addressed in a similar manner with the MODBUS function codes that are implemented (read/write). The specific register address is then specified instead of the address for a module channel.
Page 83: Commissioning
WAGO-I/O-SYSTEM 750 Commissioning 750-362 FC Modbus TCP; G4 Commissioning This section shows a step-by-step procedure for starting up exemplarily a WAGO fieldbus node. Good example! This description is just an example and only serves to describe the procedure for a local start-up of a single fieldbus node with a PC under Windows.
Page 84: Connecting Client Pc And Fieldbus Nodes
Commissioning WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Connecting Client PC and Fieldbus Nodes 1. Mount the fieldbus node on the TS 35 carrier rail. Follow the mounting instructions found in the “Mounting” chapter. 2. Connect the 24 V power supply to the supply terminals.
Page 85: Assigning The Ip Address To The Fieldbus Node
IP address via the address selector switch. The basic IP address can be changed via the Web-based management or WAGO Ethernet settings (in the delivery state: 192.168.1.0). The subnet mask and default gateway values are taken from the static settings (as delivered: subnet mask = 255.255.255.0, default gateway = 0.0.0.0).
Page 86: Figure 39: Address Selection Switch, For Example The Value Setting "50
You can also change the static base address currently saved in the fieldbus coupler/controller as required. Proceed as described for example in the section “Assigning IP Address via “WAGO Ethernet Settings””. To configure the IP address via the address selection switch by setting the host ID (last position of the IP address) to a value that does not equal 0/255, first convert the host ID to the binary representation.
Page 87: Assigning Ip Address Via Dhcp
DHCP server to be permanently available. If there is no DHCP server available after a Power On reset, the network will remain inactive. If DHCP is not active, it is necessary to enable DHCP, e. g. via "WAGO Ethernet Settings" or via the WBM (see chapters "Enable DHCP via "WAGO Ethernet Settings"...
Page 88 Commissioning WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Via DHCP assigned IP addresses are only temporarily valid! Note that an IP address assigned via DHCP is limited in time. If the DHCP server is not available at the end of its useful life, the fieldbus node sets the IP address free and then the fieldbus node is no longer accessible! In order to use the IP address permanently, change it to “static”...
Page 89: Enable Dhcp Via "Wago Ethernet Settings" (Without Existing Ip Address)
"Dynamic Host Configuration Protocol" (DHCP). However, if DHCP is not active and you do not have access to your fieldbus node via an IP address, you can enable DHCP via "WAGO Ethernet Settings" in the Network tab.
Page 90: Enable Dhcp Via Wbm (With Existing Ip Address)
Commissioning WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 8.3.2.2 Enable DHCP via WBM (with existing IP address) In the delivery state of the head station, the dynamic assignment of the IP address is active by means of "Dynamic Host Configuration Protocol" (DHCP).
Page 91: Assigning Ip Address Via "Wago Ethernet Settings
Flash File System in which the WBM pages of the fieldbus coupler/controller are stored. "WAGO Ethernet Settings" can be used via the serial service interface or via the ETHERNET interface.
Page 92 Click on the [Write] button to apply the settings in the fieldbus node. You can now close "WAGO Ethernet Settings" or make other changes in the Web-based Management System as required. To open the Web-based Management System click on the button [Start WBM] on the right side.
Page 93: Assigning The Ip Address Via Bootp
By default, DHCP is active in the delivery state of the head station. Therefor it is necessary to enable BootP for IP address assignment via BootP, e. g. via "WAGO Ethernet Settings" or via the WBM (see analog the chapters "Activate DHCP via "WAGO Ethernet Settings" (without existing IP address)" or "Activate DHCP via WBM (with existing IP address)").
Page 94 IP address for your fieldbus node. Enable the query/response mechanism of the BootP protocol based on the handling, which depends on the BootP program set or e. g. in “WAGO Ethernet Settings“ (Network tab, Source “BootP”). To apply the new IP address, use e.g. a hardware reset to restart your fieldbus node by interrupt the voltage supply for approx.
Page 95: Reasons For Failed Ip Address Assignment
WAGO-I/O-SYSTEM 750 Commissioning 750-362 FC Modbus TCP; G4 8.3.4.1 Reasons for Failed IP Address Assignment • The PC on whom the BootP server is running is not located in the network as the fieldbus coupler/controller; i.e., the IP addresses do not match.
Page 96: Apply Ip Address Permanently (Option "Static")
Commissioning WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Apply IP address permanently (option “static“) For permanent address assignment, the IP stored in the EEPROM must be used! To apply permanently the new IP address assigned via DHCP or BootP in the fieldbus coupler/controller, the assigned or desired settings for IP address, subnet mask and default gateway must be entered on the WBM “TCP/IP”...
Page 97: Testing The Function Of The Fieldbus Node
WAGO-I/O-SYSTEM 750 Commissioning 750-362 FC Modbus TCP; G4 Testing the Function of the Fieldbus Node To ensure that the IP address is correct and to test communication with the fieldbus node, first turn off the operating voltage of the fieldbus node.
Page 98: Preparing The Flash File System
More information about LED signaling The exact description for evaluating the LED signal displayed is available in the section “Diagnostics” > … > “LED Signaling”. Start the “WAGO Ethernet Settings” program. Manual Version 1.0.2...
Page 99 WAGO-I/O-SYSTEM 750 Commissioning 750-362 FC Modbus TCP; G4 In the top menu bar, select [Reset File System] to format the file system and to extract the WBM pages of the flash file system. Formatting and extracting is complete when the status window displays "Resetting the file system successfully".
Page 100: Synchronizing The System Time
Do not set time during a WAGO I/O-CHECK communication! Note that setting the clock during a WAGO I/O-CHECK communication may cause communication errors. Therefore set the time only if WAGO I/O-CHECK is not yet started. Switch off the supply voltage of the fieldbus node.
Page 101 Select “Clock” in the left navigation bar. Enter your user name and password in the displayed query dialog box (default: user = "admin", password = "wago" or: user = "user", password = "user"). The WBM page "Clock" is displayed. Set the current time and date values, as well as the time zone deviation in the input fields, and select the desired option for the display and Daylight Saving Time (DST).
Page 102: Restoring Factory Settings
Switch on the supply voltage of the fieldbus node. Start the WAGO-ETHERNET-Settings program. In the top menu bar, select [Factory Settings] and click [Yes] to confirm. A restart of the fieldbus node is implemented automatically. The start takes place with the default settings.
Page 103: Configuring Via The Web-Based Management System (Wbm)
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 103 750-362 FC Modbus TCP; G4 Configuring via the Web-Based Management System (WBM) An integrated Web server can be used for configuration and administration of the device. The HTML pages together, they are referred to as the Web-based Management System (WBM).
Page 104: Open Wbm
The first time a configuration page is called, a login dialog appears Enter your user name and password in the query dialog (default: user = “admin”, password = “wago” or user = “user”, password = “user”). The corresponding WBM page is loaded.
Page 105: Figure 40: Wbm Page "Information" (Example)
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 105 750-362 FC Modbus TCP; G4 Figure 40: WBM page “Information” (example) Manual Version 1.0.2...
Page 106: Information
106 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Information The WBM page “Information” contains an overview of all important information about your fieldbus coupler. Table 30: WBM Page “Information” Device details Entry Default...
Page 107: Administration
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 107 750-362 FC Modbus TCP; G4 Administration Use the “Administration” WBM page to set configuration options for basic administration purposes, such as boot behavior, authentication, and SSL certificate. These configuration options are stored in non-volatile memory when the [SUBMIT] button is pressed.
Page 108 108 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 The following default groups exist: User: admin Password: wago User: user Password: user User: guest Password: guest SSL Certificates Entry Button Status Description (Example) Select the file with the server certificate and...
Page 109: Clock
00:00:00 a.m. and has to synchronize with the computer’s current time. Use a WAGO RTC module for time synchronization!! You can use a WAGO 750-640 RTC Module for your node to utilize the actual encoded time (Real-time – RTC) in your higher-level control system.
Page 110: Table 32: Wbm Page „Clock
110 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 32: WBM Page „Clock“ Clock Settings Entry Default Value (example) Description Device local time Set current time 00:00:00 08:30:38 (HH:MM:SS) Device local date Set current date...
Page 111: Miscellaneous
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 111 750-362 FC Modbus TCP; G4 Miscellaneous On the Miscellaneous WBM page, you can set configuration options for various features and compatibility options. These configuration options are stored in non-volatile memory when the [SUBMIT] button is pressed.
Page 112: Update
112 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 34: WBM page "Storage Media" Local Disks Entry Value (Example) Description Drive Letter Directory Total Size [kB] 1050184 kB Total size of the file system...
Page 113: Ethernet
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 113 750-362 FC Modbus TCP; G4 9.10 Ethernet Use the “Ethernet” WBM page to set the data transfer rate, the MAC address filter settings and bandwidth limit for each of the two switch ports for data transfer via Ethernet.
Page 114 114 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 MAC Address Filter Settings Entry Default value Description Enable filter Activate MAC address filter.  Depending on the operating mode of the MAC address filter (whitelist / blacklist), the subsequently ...
Page 115 WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 115 750-362 FC Modbus TCP; G4 Switch Settings Entry Default value Description Enable “Fast Aging”  "Fast Aging" ensures that the cache for the MAC addresses is cleared faster in the switch. This may be required if a redundancy system (e.g., using a Jet-...
Page 116 116 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 All ETHERNET ports cannot be disabled! Both ETHERNET ports can be switched off. If both ports are disabled and you press [SUBMIT], the selection is not applied and the previous values are restored.
Page 117: Protocols
To reduce the risk of cyber attacks and, thus, enhance your cyber security, close all ports and services in the control components (e.g., Port 6626 for WAGO I/O-CHECK, Port 2455 for CODESYS 2 and Port 11740 for e!COCKPIT) not required by your application.
Page 118: Snmp
118 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 9.12 SNMP On the HTML pages „SNMP“, you can perform the settings for the Simple Network Management Protocol (SNMP v1/v2c and v3). SNMP is a standard for device management within a TCP/IP network. The...
Page 119: Snmp V1/V2C
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 119 750-362 FC Modbus TCP; G4 9.12.1 SNMP v1/v2c The SNMP version 1/2c represents a community message exchange. The community name of the network community must thereby be specified. Table 38: WBM Page “SNMP v1/v2”...
Page 120: Snmp V3
120 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 9.12.2 SNMP V3 In SNMP version 3, exchanging messages is user-related. Each device, that knows the passwords set via WBM, may read or write values from the fieldbus coupler.
Page 121: Sntp
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 121 750-362 FC Modbus TCP; G4 9.13 SNTP On the WBM page “SNTP”, you can perform the settings for the “Simple Network Time Protocol”. The SNTP client supports configuration of static time servers. Two additional servers may be assigned by dynamic network configuration (e.
Page 122: Tcp/Ip
122 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 9.14 TCP/IP You can configure network addressing and network identification on the “TCP/IP” WBM page. Set the DIP switch to “0” and enable static IP configuration source! Before you change parameters on this page, set the DIP switch to value “0”...
Page 123: Modbus
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 123 750-362 FC Modbus TCP; G4 9.15 MODBUS Use the “MODBUS” WBM page to specify the settings for the Modbus protocol. Table 42: WBM page “MODBUS” Modbus UDP Multicast Address Setup...
Page 124 124 Configuring via the Web-Based Management System (WBM) WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Connection Watchdog Entry Default Description Connection timeout value Monitoring period for TCP links. (x 100 ms) After the completion of this period without any subsequent data traffic, the TCP connection is closed.
Page 125: I/O Config
WAGO-I/O-SYSTEM 750 Configuring via the Web-Based Management System (WBM) 125 750-362 FC Modbus TCP; G4 9.16 I/O Config Click the link “I/O config” to view the number of modules that are connected to your hardware. The data in the second line are not relevant for the present fieldbus coupler, because no I/O configuration will be load onto devices which have no runtime system (PLC).
Page 126: Diagnostics
126 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Diagnostics 10.1 LED Signaling For on-site diagnostics, the fieldbus coupler has several LEDs that indicate the operational status of the fieldbus coupler or the entire node (see following figure). Figure 41: Display Elements The diagnostics displays and their significance are explained in detail in the following section.
Page 127: Evaluating Fieldbus Status
WAGO-I/O-SYSTEM 750 Diagnostics 127 750-362 FC Modbus TCP; G4 10.1.1 Evaluating Fieldbus Status The health of the ETHERNET Fieldbus is signaled through the top LED group ('LINK ACT 1, 2', 'MS', und 'NS'). The two-colored LEDs ‘MS’ (module status) and ‘NS’ (network status) are used to display the status of the system and the fieldbus connections.
Page 128: Evaluating Node Status - I/O Led (Blink Code Table)
128 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 10.1.2 Evaluating Node Status – I/O LED (Blink Code Table) The communication status between fieldbus coupler/controller and the I/O modules is indicated by the I/O LED. Table 46: Node Status Diagnostics – Solution in Event of Error...
Page 129: Figure 42: Node Status - I/O Led Signaling
WAGO-I/O-SYSTEM 750 Diagnostics 129 750-362 FC Modbus TCP; G4 Figure 42: Node Status – I/O LED Signaling Figure 43: Error Message Coding Example of a module error: • The I/O LED starts the error display with the first flashing sequence (approx.
Page 130 130 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Error argument 12 means that the local bus is interrupted behind the twelfth I/O module. The thirteenth I/O module is either defective or has been pulled out of the assembly. Manual...
Page 131: Table 47: Blink Code- Table For The I/O Led Signaling, Error Code 1
WAGO-I/O-SYSTEM 750 Diagnostics 131 750-362 FC Modbus TCP; G4 Table 47: Blink code- table for the I/O LED signaling, error code 1 Error code 1: "Hardware and configuration error" Error Error Description Solution Argument Overflow of the Turn off the power supply of the node.
Page 132: Table 48: Blink Code Table For The I/O Led Signaling, Error Code 2
132 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 47: Blink code- table for the I/O LED signaling, error code 1 Error code 1: "Hardware and configuration error" Error Error Description Solution Argument Turn off the power supply of the node.
Page 133: Table 49: Blink Code Table For The I/O Led Signaling, Error Code 3
WAGO-I/O-SYSTEM 750 Diagnostics 133 750-362 FC Modbus TCP; G4 Table 49: Blink Code Table for the I/O LED Signaling, Error Code 3 Error Code 3: „Protocoll error, local bus“ Error Error Description Solution Argument -- Are there power supply modules with the bus power supply...
Page 134: Table 50: Blink Code Table For The I/O Led Signaling, Error Code 4
134 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 50: Blink Code Table for the I/O LED Signaling, Error Code 4 Error Code 4: „Physical error, local bus“ Error Error Description Solution Argument Turn off the power supply of the node.
Page 135: Table 52: Blink Code Table For The I/O Led Signaling, Error Code 6
WAGO-I/O-SYSTEM 750 Diagnostics 135 750-362 FC Modbus TCP; G4 Table 52: Blink Code Table for the I/O LED Signaling, Error Code 6 Error Code 6: " Configuration error, node configuration" Error Error Description Solution Argument Turn off the power supply of the node.
Page 136: Table 55: Blink Code Table For I/O Led Signaling, Error Code 12
If the error still exists, please contact the I/O Support. 1. Reset the file system using “WAGO Ethernet Settings“, button [Reset File System] in the menu above. General error of the file 2. Restart the fieldbus node by turning the power supply system off and on again.
Page 137: Fault Behavior
WAGO-I/O-SYSTEM 750 Diagnostics 137 750-362 FC Modbus TCP; G4 10.2 Fault Behavior 10.2.1 Fieldbus Failure A fieldbus and thus a connection failure occurs if the set time-out time of the watchdog has elapsed without being triggered by the higher-level controller. This can happen, for example, when the master is switched off or the fieldbus cable is interrupted.
Page 138 138 Diagnostics WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 If the end module is re-inserted into the fieldbus node, the local bus will restart after a few seconds. After the initialization blink code is completely, the I/O LED lights up again in a steady green and the transmission of the process data is resumed.
Page 139: Fieldbus Communication
WAGO fieldbus coupler/controller based on ETHERNET. These protocols are explained in more detail in the other sections.
Page 140: Table 58: Network Class A
140 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 IP Addresses To allow communication over the network each fieldbus node requires a 32 bit Internet address (IP address). IP Address must be unique! For error free operation, the IP address must be unique within the network.
Page 141: Table 61: Key Data Class A, B And C
192.000.000.XXX ... Approx. 2 Million 223.255.255.XXX Each WAGO ETHERNET fieldbus coupler or controller can be easily assigned an IP address via the implemented BootP protocol. For small internal networks we recommend selecting a network address from Class C. Do not set IP addresses to 0.0.0.0 or 255.255.255.255! Never set all bits to equal 0 or 1 in one byte (byte = 0 or 255).
Page 142: Table 62: Example: Class B Address With Field For Subnet Ids
142 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 62: Example: Class B Address with Field for Subnet IDs Network ID Subnet ID Host ID Subnet Mask A subnet mask was introduced to encode the subnets in the Internet. This involves a bit mask, which is used to mask out or select specific bits of the IP address.
Page 143 WAGO-I/O-SYSTEM 750 Fieldbus Communication 143 750-362 FC Modbus TCP; G4 Specification of the network mask necessary! Specify the network mask defined by the administrator in the same way as the IP address when installing the network protocol. Gateway The subnets of the Internet are normally connected via gateways. The function of these gateways is to forward packets to other networks or subnets.
Page 144: Tcp (Transmission Control Protocol)
144 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 physically receives every packet. The resolution of IP address to Ethernet address is solved by the use of algorithms, IP multicast addresses are embedded in Ethernet multicast addresses. 11.1.1.2 TCP (Transmission Control Protocol) As the layer above the Internet protocol, TCP (Transmission Control Protocol) guarantees the secure transport of data through the network.
Page 145: Configuration And Diagnostics Protocols
WAGO-I/O-SYSTEM 750 Fieldbus Communication 145 750-362 FC Modbus TCP; G4 11.1.2 Configuration and Diagnostics Protocols 11.1.2.1 BootP (Bootstrap Protocol) The “Bootstrap Protocol” (BootP) can be used to assign an IP address and other parameters to the head station of the fieldbus node in a TCP/IP network.
Page 146: Dhcp (Dynamic Host Configuration Protocol)
146 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 67: BootP Options Option Meaning [OPT1] Subnet mask 32-bit address mask that displays which bits of the IP address identify the network and which identify the network stations. [OPT2] Time zone Time difference between the local time and the UTC (Universal Time Coordinated).
Page 147 WAGO-I/O-SYSTEM 750 Fieldbus Communication 147 750-362 FC Modbus TCP; G4 Manual assignment • In this mode, the IP addresses are permanently assigned on the DHCP server to specific MAC addresses. The addresses are assigned to the MAC address for an indefinite period.
Page 148: Http (Hypertext Transfer Protocol)
The HTTP server uses port number 80. 11.1.2.4 DNS (Domain Name Systems) The DNS client enables conversion of logical Internet names such as www.wago.com into the appropriate decimal IP address represented with separator stops, via a DNS server. Reverse conversion is also possible. Manual Version 1.0.2...
Page 149: Sntp-Client (Simple Network Time Protocol)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 149 750-362 FC Modbus TCP; G4 The addresses of the DNS server are configured via DHCP, BootP or web-based management. Up to 2 DNS servers can be specified. The host identification can be achieved with two functions; an internal host table is not supported.
Page 150: Snmp (Simple Network Management Protocol)
“MIB objects”. The SNMP of the ETHERNET controller includes both the general MIB acc. to RFC1213 (MIB II) and a special WAGO MIB. SNMP is processed via port 161. The port number for SNMP traps (agent messages) is 161. Both ports must be enabled to use SNMP.
Page 151: 11.1.2.7.1 Mib Ii Description
WAGO-I/O-SYSTEM 750 Fieldbus Communication 151 750-362 FC Modbus TCP; G4 11.1.2.7.1 MIB II Description MIB II acc. to RFC1213 is divided into the following groups: Table 70: MIB II groups Group Identifier System Group 1.3.6.1.2.1.1 Interface Group 1.3.6.1.2.1.2 IP Group 1.3.6.1.2.1.4...
Page 152: 11.1.2.7.2 Traps
152 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.1.2.7.2 Traps Standard Traps For specific events, the SNMP agent will independently send one of the following messages without polling the manager. Enable event messages (traps) in the WBM! Initially enable the event messages in the WBM in menu “SNMP” under “Trap Enable”.
Page 153: Application Protocols
WAGO-I/O-SYSTEM 750 Fieldbus Communication 153 750-362 FC Modbus TCP; G4 11.1.3 Application Protocols If fieldbus specific application protocols are implemented, then the appropriate fieldbus specific communication is possible with the respective coupler/controller. Thus the user is able to have a simple access from the respective fieldbus on the fieldbus node.
Page 154: Modbus Functions
154 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2 Modbus Functions 11.2.1 General Modbus is a manufacturer-independent, open fieldbus standard for diverse applications in manufacturing and process automation. The Modbus protocol is implemented according to the current Internet Draft of the IETF (Internet Engineering Task Force) and performs the following functions: •...
Page 155: Table 73: Basic Data Types Of Modbus Protocol
WAGO-I/O-SYSTEM 750 Fieldbus Communication 155 750-362 FC Modbus TCP; G4 More information More information on the “Open MODBUS/TCP specification” you can find in the Internet: www.modbus.org Therefore the MODBUS protocol based essentially on the following basic data types: Table 73: Basic Data Types of MODBUS Protocol...
Page 156 156 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 To execute a desired function, specify the respective function code and the address of the selected input or output channel or of the register. Note the number system when addressing! The examples listed use the hexadecimal system (i.e.: 0x000) as their numerical...
Page 157: Use Of The Modbus Functions
WAGO-I/O-SYSTEM 750 Fieldbus Communication 157 750-362 FC Modbus TCP; G4 11.2.2 Use of the MODBUS Functions The example below uses a graphical view of a fieldbus node to show which MODBUS functions can be used to access data of the process image.
Page 158: Description Of The Modbus Functions
11.2.3 Description of the MODBUS Functions All MODBUS functions are executed as follows: A MODBUS TCP master (e.g., a PC) makes a request to the WAGO fieldbus node using a specific function code based on the desired operation.. The WAGO fieldbus node receives the datagram and then responds to the master with the proper data, which is based on the master’s request.
Page 159: Function Code Fc1 (Read Coils)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 159 750-362 FC Modbus TCP; G4 Reading and writing of outputs via FC1 to FC4 is also possible by adding an offset! In the case of the read functions (FC1 ... FC4) the outputs can be additionally...
Page 160: Table 78: Assignment Of Inputs
160 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 lowest value. The assignment is thus made from 7 to 0 as follows: Table 78: Assignment of Inputs OFF OFF OFF ON OFF OFF ON OFF Coil Exception Table 79: Exception of Function Code FC1...
Page 161: Function Code Fc2 (Read Discrete Inputs)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 161 750-362 FC Modbus TCP; G4 11.2.3.2 Function Code FC2 (Read Discrete Inputs) This function reads the input bits from a slave device. Request The request specifies the reference number (starting address) and the bit count to be read.
Page 162: Table 83: Exception Of Function Code Fc2
162 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Exception Table 83: Exception of Function Code FC2 Byte Field name Example Byte 7 MODBUS function code 0x82 Byte 8 Exception code 0x01 or 0x02 Manual Version 1.0.2...
Page 163: Function Code Fc3 (Read Multiple Registers)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 163 750-362 FC Modbus TCP; G4 11.2.3.3 Function Code FC3 (Read Multiple Registers) This function reads the contents of holding registers from a slave device in word format. Request The request specifies the reference number (start register) and the word count (register quantity) of the registers to be read.
Page 164: Function Code Fc4 (Read Input Registers)
164 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.3.4 Function Code FC4 (Read Input Registers) This function reads contents of input registers from the slave device in word format. Request The request specifies a reference number (start register) and the word count (register quantity) of the registers to be read.
Page 165: Function Code Fc5 (Write Coil)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 165 750-362 FC Modbus TCP; G4 11.2.3.5 Function Code FC5 (Write Coil) This function writes a single output bit to the slave device. Request The request specifies the reference number (output address) of output bit to be written.
Page 166: Function Code Fc6 (Write Single Register)
166 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.3.6 Function Code FC6 (Write Single Register) This function writes the value of one single output register to a slave device in word format. Request The request specifies the reference number (register address) of the first output word to be written.
Page 167: Function Code Fc11 (Get Comm Event Counter)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 167 750-362 FC Modbus TCP; G4 11.2.3.7 Function Code FC11 (Get Comm Event Counter) This function returns a status word and an event counter from the slave device’s communication event counter. By reading the current count before and after a series of messages, a master can determine whether the messages were handled normally by the slave.
Page 168: Function Code Fc15 (Write Multiple Coils)
168 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.3.8 Function Code FC15 (Write Multiple Coils) This function sets a sequence of output bits to 1 or 0 in a slave device. The maximum number is 256 bits. Request The request message specifies the reference number (first coil in the sequence), the bit count (number of bits to be written), and the output data.
Page 169: Table 101: Exception Of Function Code Fc15
WAGO-I/O-SYSTEM 750 Fieldbus Communication 169 750-362 FC Modbus TCP; G4 Exception Table 101: Exception of Function Code FC15 Byte Field name Example Byte 7 MODBUS function code 0x8F Byte 8 Exception code 0x01 or 0x02 Manual Version 1.0.2...
Page 170: Function Code Fc16 (Write Multiple Registers)
170 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.3.9 Function Code FC16 (Write Multiple Registers) This function writes a sequence of registers in a slave device in word format. Request The Request specifies the reference number (starting register), the word count (number of registers to write), and the register data .
Page 171: Function Code Fc22 (Mask Write Register)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 171 750-362 FC Modbus TCP; G4 11.2.3.10 Function Code FC22 (Mask Write Register) This function manipulates individual bits within a register using a combination of an AND mask, an OR mask, and the register’s current content.
Page 172: Function Code Fc23 (Read/Write Multiple Registers)
172 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.3.11 Function Code FC23 (Read/Write Multiple Registers) This function performs a combination of a read and write operation in a single request. The function can write the new data to a group registers, and then return the data of a different group.
Page 173 WAGO-I/O-SYSTEM 750 Fieldbus Communication 173 750-362 FC Modbus TCP; G4 Note that if the register ranges overlap, the results are undefined! If register areas for read and write overlap, the results are undefined. Manual Version 1.0.2...
Page 174: Modbus Register Mapping
174 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.4 MODBUS Register Mapping The following tables display the MODBUS addressing and the internal variables. Via the register services the states of the complex and digital I/O modules can be determined or changed.
Page 175: Table 112: Register Access Writing (With Fc6 And Fc16)
WAGO-I/O-SYSTEM 750 Fieldbus Communication 175 750-362 FC Modbus TCP; G4 Register Access Writing (with FC6 and FC16) Table 112: Register Access Writing (with FC6 and FC16) MODBUS address IEC 61131 Memory range [dec] [hex] address 0...255 0x0000...0x00FF %QW0...%QW255 Physical output area (1) First 256 Words of physical output data 256...511...
Page 176: Table 113: Bit Access Reading (With Fc1 And Fc2)
176 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Bit Access Reading (with FC1 and FC2) Table 113: Bit Access Reading (with FC1 and FC2) MODBUS address Memory range Description [dec] [hex] 0...511 0x0000...0x01FF Physical input area (1) First 512 digital inputs 512...1023...
Page 177: Modbus Registers
WAGO-I/O-SYSTEM 750 Fieldbus Communication 177 750-362 FC Modbus TCP; G4 11.2.5 Modbus Registers Table 115: Modbus Registers Register Acces Length Description address (Word) 0x1000 Watchdog time read/write 0x1001 1 … 2 Watchdog coding mask 1…16 0x1002 Watchdog coding mask 17…32...
Page 178: Table 116: Modbus Registers (Continuation)
178 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 116: MODBUS registers (Continuation) Register Acces Length Description address (Word) 0x2020 1 … 16 Short description controller 0x2021 1 … 8 Compile time of the firmware 0x2022 1 … 8...
Page 179: Accessing Register Values
WAGO-I/O-SYSTEM 750 Fieldbus Communication 179 750-362 FC Modbus TCP; G4 11.2.5.1 Accessing Register Values You can use any den Modbus application to access (read from or write to) register values. Both commercial (e.g., “Modscan”) and free programs (from http://www.modbus.org/tech.php) are available.
Page 180: Modbus Watchdog Register
180 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 => Select the operating mode "Standard" for this. However, the Modbus TCP connection will still work to access the Modbus configuration and status registers. => Set the register 0x1009 to the value '0'.
Page 181: Table 118: Register Address 0X1001
WAGO-I/O-SYSTEM 750 Fieldbus Communication 181 750-362 FC Modbus TCP; G4 Table 118: Register Address 0x1001 Register address 0x1001 (4097 Value Watchdog function coding mask, function code 1...16, WDFCM_1_16 Access Read/write Default 0xFFFF Description Using this mask, the function codes can be set to trigger the watchdog function.
Page 182: Table 121: Register Address 0X1004
182 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 121: Register Address 0x1004 Register address 0x1004 (4100 Value Minimum current trigger time, WD_AC_TRG_TIME Access Read Standard 0xFFFF Description This register saves the minimum current watchdog trigger time. For user this register is irrelevant.
Page 183: Table 126: Register Address 0X1009
WAGO-I/O-SYSTEM 750 Fieldbus Communication 183 750-362 FC Modbus TCP; G4 Table 126: Register Address 0x1009 Register address 0x1009 (4105 Value Close Modbus socket after watchdog timeout Access Read/write Standard 0x0000 Description 0: Modbus socket is not closed 1: Modbus socket is closed...
Page 184: Table 129: Register Address 0X100B
184 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Setting the watchdog for a timeout of 10 minutes or more: Write 0x1770 (= 10*60*1000 ms / 100 ms) in the register for time overrun (0x1000). (Register 0x1000 works with a multiple of 100 ms;...
Page 185: Diagnostic Registers
WAGO-I/O-SYSTEM 750 Fieldbus Communication 185 750-362 FC Modbus TCP; G4 11.2.5.4 Diagnostic Registers The following registers can be read to determine errors in the node: Table 130: Register Address 0x1020 Register address 0x1020 (4128 Value LedErrCode Access Read Description Declaration of the error code...
Page 186: Configuration Registers
186 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 11.2.5.5 Configuration Registers The following registers contain configuration information of the connected modules: Table 132: Register Address 0x1022 Register address 0x1022 (4130 Value CnfLen.AnalogOut Access Read Description Number of word-based outputs registers in the process image in bits (divide by 16...
Page 187: Table 137: Register Address 0X102A
WAGO-I/O-SYSTEM 750 Fieldbus Communication 187 750-362 FC Modbus TCP; G4 Table 137: Register Address 0x102A Register address 0x102A (4138 ) with a word count of 1 Value MODBUS/TCP connections Access Read Description Number of TCP connections Table 138: Register Address 0x102B...
Page 188: Constant Registers
188 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 143: Register Address 0x1050 Register address 0x1050 (4176 ) with a word count of 3 Value Diagnosis of the connected I/O modules Access Read Description Diagnosis of the connected I/O modules, length 3 words...
Page 189: Table 148: Register Address 0X2004
WAGO-I/O-SYSTEM 750 Fieldbus Communication 189 750-362 FC Modbus TCP; G4 Table 148: Register Address 0x2004 Register address 0x2004 (8196 Value Mask 1, GP_5555 Access Read Description This constant is used to verify that all bits are accessible to the fieldbus master.
Page 190: Firmware Information Registers
) with a word count of 1 Value Series code, INFO_SERIES Access Read Description WAGO serial number, e.g. 0x02EE (750 dec.) for WAGO-I/O-SYSTEM 750 Table 155: Register Address 0x2012 Register address 0x2012 (8210 ) with a word count of 1 Value Order number, INFO_ITEM...
Page 191: Table 159: Register Address 0X2021
WAGO-I/O-SYSTEM 750 Fieldbus Communication 191 750-362 FC Modbus TCP; G4 Table 159: Register Address 0x2021 Register address 0x2021 (8225 ) with a word count of up to 8 Value Description, INFO_DESCRIPTION Access Read Description Time of the firmware version, 8 words...
Page 192: Table 162: Register Address 0X2030
192 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 162: Register Address 0x2030 Register address 0x2030 (8240 ) with a word count of up to 65 Value Description of the connected I/O modules Access Read module 0...64 Description Length 1...65 words...
Page 193: Table 165: Register Address 0X2033
WAGO-I/O-SYSTEM 750 Fieldbus Communication 193 750-362 FC Modbus TCP; G4 Table 165: Register Address 0x2033 Register address 0x2033 (8243 ) with a word count of up to 65 Value Description of the connected I/O modules Access Read modules 193 ... 255 Description Length 1…63 words...
Page 194: Table 169: Register Address 0X2043
194 Fieldbus Communication WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 169: Register Address 0x2043 Register address 0x2043 (8259 Value 0x55AA Access Write Description Factory settings The default settings are applied after the next reset, e.g., software reset via Modbus register address 0x2040.
Page 195: O Modules
WAGO-I/O-SYSTEM 750 I/O Modules 195 750-362 FC Modbus TCP; G4 I/O Modules 12.1 Overview For modular applications with the WAGO I/O SYSTEM 750, different types of I/O modules are available • Digital Input Modules • Digital Output Modules • Analog Input Modules •...
Page 196: Process Data Architecture For Modbus-Tcp
Intel format. The following section describes the process image for various WAGO-I/O-SYSTEM 750 and 753 I/O modules with Modbus-TCP. Equipment damage due to incorrect address! Depending on the specific position of an I/O module in the fieldbus node, the process data of all previous byte or bit-oriented modules must be taken into account to determine its location in the process data map.
Page 197: Channel Digital Input Modules
WAGO-I/O-SYSTEM 750 I/O Modules 197 750-362 FC Modbus TCP; G4 12.2.1.2 2 Channel Digital Input Modules 750-400, -401, -405, -406, -407, -410, -411, -412, -427, -438, (and all variations), 753-400, -401, -405, -406, -410, -411, -412, -427, -429 Table 171: 2 Channel Digital Input Modules...
Page 198: Channel Digital Input Modules
198 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.1.5 4 Channel Digital Input Modules 750-402, -403, -408, -409, -414, -415, -422, -423, -428, -432, -433, -1420, -1421, -1422, -1423 753-402, -403, -408, -409, -415, -422, -423, -428, -432, -433, -440...
Page 199: Table 176: 8 Channel Digital Input Module Namur With Diagnostics And Output
WAGO-I/O-SYSTEM 750 I/O Modules 199 750-362 FC Modbus TCP; G4 Table 176: 8 Channel Digital Input Module NAMUR with Diagnostics and Output Process Data Input Process Image Input byte D0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3...
Page 200: Channel Digital Input Module Ptc With Diagnostics And Output Process Data
200 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.1.8 8 Channel Digital Input Module PTC with Diagnostics and Output Process Data 750-1425 The digital input module PTC provides via one logical channel 2 byte for the input and output process image.
Page 201: Table 178: 16 Channel Digital Input Modules
WAGO-I/O-SYSTEM 750 I/O Modules 201 750-362 FC Modbus TCP; G4 12.2.2 16 Channel Digital Input Modules 750-1400, -1402, -1405, -1406, -1407 Table 178: 16 Channel Digital Input Modules Input Process Image Input Byte D0 Bit 7 Bit 6 Bit 5...
Page 202: Digital Output Modules
202 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.2.1 Digital Output Modules Digital output modules use one bit of data per channel to control the output of the corresponding channel. These bits are mapped into the Output Process Image.
Page 203: Channel Digital Input Modules With Diagnostics And Input Process Data
WAGO-I/O-SYSTEM 750 I/O Modules 203 750-362 FC Modbus TCP; G4 12.2.2.4 2 Channel Digital Input Modules with Diagnostics and Input Process Data 750-507 (-508), -522, 753-507 The digital output modules have a diagnostic bit for each output channel. When an output fault condition occurs (i.e., overload, short circuit, or broken wire), a diagnostic bit is set.
Page 204: Channel Digital Output Modules
204 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.2.5 4 Channel Digital Output Modules 750-504, -515, -516, -519, -531, 753-504, -516, -531, -540 Table 183: 4 Channel Digital Output Modules Output Process Image Bit 7 Bit 6 Bit 5...
Page 205: Channel Digital Output Modules With Diagnostics And Input Process Data
WAGO-I/O-SYSTEM 750 I/O Modules 205 750-362 FC Modbus TCP; G4 12.2.2.8 8 Channel Digital Output Modules with Diagnostics and Input Process Data 750-537, 753-537 The digital output modules have a diagnostic bit for each output channel. When an output fault condition occurs (i.e., overload, short circuit, or broken wire), a diagnostic bit is set.
Page 206: 12.2.2.10 8 Channel Digital Input/Output Modules
206 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.2.10 8 Channel Digital Input/Output Modules 750-1502, -1506 Table 188: 8 Channel Digital Input/Output Modules Input Process Image Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2...
Page 207: Analog Input Modules
Information on the structure of control and status bytes For detailed information on the structure of a particular I/O module’s control/status bytes, please refer to that module’s manual. Manuals for each module can be found on the Internet at www.wago.com. 12.2.3.1 1 Channel Analog Input Modules...
Page 208: Channel Analog Input Modules Hart
"WagoLibHart_0x.lib" library. The data is tunneled to the application via the mailbox and decoded by means of the library, so that the evaluation and processing takes place directly at the application level. The operating mode is set using the WAGO-I / O-CHECK commissioning tool. Manual Version 1.0.2...
Page 209: Channel Analog Input Modules
WAGO-I/O-SYSTEM 750 I/O Modules 209 750-362 FC Modbus TCP; G4 Table 191: 2-Channel Analog Input Modules HART Input Process Image Byte Destination Offset Description High Byte Low Byte Measured Value Channel 1 Measured Value Channel 2 Table 192:: 2 Channel Analog Input Modules HART + 6 bytes Mailbox...
Page 210: Channel Analog Input Modules
210 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.3.5 8 Channel Analog Input Modules 750-451, 750-458, 750-496, 750-497 Table 194: 8 Channel Analog Input Modules Input Process Image Byte Destination Offset Description High Byte Low Byte Measured Value Channel 1...
Page 211: 3-Phase Power Measurement Module
WAGO-I/O-SYSTEM 750 I/O Modules 211 750-362 FC Modbus TCP; G4 12.2.3.6 3-Phase Power Measurement Module 750-493 The above Analog Input Modules have a total of 9 bytes of user data in both the Input and Output Process Image (6 bytes of data and 3 bytes of control/status).
Page 212: Table 196: 3-Phase Power Measurement Modules 750-494, -495
212 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 750-494, -495, (and all variations) The 3-Phase Power Measurement Modules 750-494, -495, (and all variations) have a total of 24 bytes of user data in both the Input and Output Process Image (16 bytes of data and 8 bytes of control/status).
Page 213: Analog Output Modules
Information on the structure of control and status bytes For detailed information on the structure of a particular I/O module’s control/status bytes, please refer to that module’s manual. Manuals for each module can be found on the Internet at www.wago.com. 12.2.4.1 2 Channel Analog Output Modules...
Page 214: Channel Analog Output Modules
Output Value Channel 8 12.2.5 Specialty Modules WAGO has a host of Specialty I/O modules that perform various functions. With individual modules beside the data bytes also the control/status byte is mapped in the process image. The control/status byte is required for the bidirectional data exchange of the module with the higher-ranking control system.
Page 215: Table 200: Counter Modules 750-404, (And All Variations Except Of /000-005)
WAGO-I/O-SYSTEM 750 I/O Modules 215 750-362 FC Modbus TCP; G4 Table 200: Counter Modules 750-404, (and all variations except of /000-005), 753-404, -404/000-003 Input Process Image Byte Designation Offset Description High Byte Low Byte Status byte Counter value Output Process Image...
Page 216: Table 202: Counter Modules 750-633
216 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 750-633 The above Counter Module has a total of 5 bytes of user data in both the Input and Output Process Image (4 bytes of counter data and 1 byte of control/ status).
Page 217: Pulse Width Modules
WAGO-I/O-SYSTEM 750 I/O Modules 217 750-362 FC Modbus TCP; G4 Output Process Image Byte Designation Offset Description High Byte Low Byte Control byte of Counter 1 Counter Setting Value of Counter 1 Control byte of Counter 2 Counter Setting Value of Counter 2 12.2.5.2...
Page 218: Serial Interface Modules With Standard Data Format
Thus, each Serial Interface Module uses between 8 and 48 bytes in the process image. The sizes of the input and output process images are always the same. The process image sizes are set with the startup tool WAGO-I/O-CHECK. Manual...
Page 219: Data Exchange Module
WAGO-I/O-SYSTEM 750 I/O Modules 219 750-362 FC Modbus TCP; G4 Table 207: Serial Interface Modules 750-652, 753-652 Input and Output Process Image Process Byte Designation image Offset Description High Byte Low Byte size Control/Status byte Control/Status byte C1/S1 C0/S0 C1/S1...
Page 220: Incremental Encoder Interface Modules
220 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 209: SSI Transmitter Interface Modules Input Process Image Byte Designation Offset Description High Byte Low Byte Data bytes 750-630/000-004, -005, -007 In the input process image, SSI transmitter interface modules with status occupy 5 usable bytes, 4 data bytes, and 1 additional status byte.
Page 221: Table 212: Incremental Encoder Interface Modules 750-634
WAGO-I/O-SYSTEM 750 I/O Modules 221 750-362 FC Modbus TCP; G4 750-634 The above Incremental Encoder Interface module has 5 bytes of input data (6 bytes in cycle duration measurement mode) and 3 bytes of output data. The following tables illustrate the Input and Output Process Image, which has 4 words mapped into each image.
Page 222: Dc-Drive Controller
222 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Digital Pulse Interface module 750-635, 753-635 The above Digital Pulse Interface module has a total of 4 bytes of user data in both the Input and Output Process Image (3 bytes of module data and 1 byte of control/status).
Page 223: 12.2.5.10 Stepper Controller
WAGO-I/O-SYSTEM 750 I/O Modules 223 750-362 FC Modbus TCP; G4 Output Process Image Byte Designation Offset Description High Byte Low Byte Control byte C1 Control byte C0 Setpoint position Setpoint position (LSB) Setpoint position Setpoint position (MSB) 12.2.5.10 Stepper Controller...
Page 224: 12.2.5.11 Rtc Module
224 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.5.11 RTC Module 750-640 The RTC Module has a total of 6 bytes of user data in both the Input and Output Process Image (4 bytes of module data and 1 byte of control/status and 1 byte ID for command).
Page 225: 12.2.5.13 Dali Multi-Master Module
WAGO-I/O-SYSTEM 750 I/O Modules 225 750-362 FC Modbus TCP; G4 12.2.5.13 DALI Multi-Master Module 753-647 The DALI Multi-Master module occupies a total of 24 bytes in the input and output range of the process image. The DALI Multi-Master module can be operated in "Easy" mode (default) and "Full"...
Page 226 226 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Output Process Image Byte Designation Offset Note High Byte Low Byte res. Bit 0: Broadcast ON Bit 1: Broadcast OFF Bit 2: (1 button operation): - short: Broadcast ON/OFF - long: Broadcast dimming...
Page 227: Table 220: Dali Multi-Master Module 753-647 In The "Full" Mode
WAGO-I/O-SYSTEM 750 I/O Modules 227 750-362 FC Modbus TCP; G4 Table 220: DALI Multi-Master Module 753-647 in the "Full" Mode Input and Output Process Image Byte Designation Offset Note High Byte Low Byte MBX_C/S C0/S0 Mailbox control/status byte control/status byte...
Page 228: Lon Ftt Module
The process image of the LON FTT module consists of a control/status byte and ® 23 bytes of bidirectional communication data that is processed by the WAGO-I/O- PRO function block "LON_01.lib". This function block is essential for the function of the LON FTT module and provides a user interface on the control side.
Page 229: 12.2.5.16 Mp Bus Master Module
The internal structure of the Bluetooth process data can be found in the documentation for the Bluetooth ® ® 750-644 RF Transceiver. The mailbox and the process image sizes are set with the startup tool WAGO- I/O-CHECK. Manual Version 1.0.2...
Page 230: 12.2.5.18 Vibration Velocity/Bearing Condition Monitoring Vib I/O
230 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 224: Bluetooth RF-Transceiver 750-644 ® Input and Output Process Image Process Byte Destination image Offset Description High Byte Low Byte size Control/status C0/S0 not used byte 12 bytes …...
Page 231: 12.2.5.19 Proportional Valve Module
WAGO-I/O-SYSTEM 750 I/O Modules 231 750-362 FC Modbus TCP; G4 12.2.5.19 Proportional Valve Module 750-632, -632/000-100 The size of the process image of the proportional valve modules depends on the set operating mode. The operating mode with one valve occupies has a total of 6...
Page 232: 12.2.5.20 M-Bus Master Module
Depending on the set mailbox size, another data storage area is available behind the SIO byte in which cyclical process data can be transferred from IO-Link devices. The mailbox and the process image sizes are set with the startup tool WAGO- I/O-CHECK. Manual...
Page 233: 12.2.5.22 Can Gateway
"Mapped Mode", in this area transmitted and received CAN telegrams can be mapped to the process image without using any protocoll. The operating mode and also the mailbox and the process image sizes are set with the startup tool WAGO-I/O-CHECK. Table 230: CAN Gateway 750-658 Input and Output Process Image...
Page 234: 12.2.5.23 Servo Stepper Controller
234 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 C/D_MBX / CAN_X C/D_MBX / CAN_X 16 bytes C/D_MBX / CAN_X C/D_MBX / CAN_X C/D_MBX / CAN_X C/D_MBX / CAN_X 20 bytes C/D_MBX / CAN_X C/D_MBX / CAN_X C/D_MBX / CAN_X...
Page 235: 12.2.5.24 Smi Master Module
WAGO-I/O-SYSTEM 750 I/O Modules 235 750-362 FC Modbus TCP; G4 12.2.5.24 SMI Master Module 753-1630, -1631 The 753-1630 I/O module has a cyclic 12 byte process image for the local bus in both the Input and Output Process Image. Process data communication with the SMI master module is conducted in fieldbus coupler mode via a cyclic process image and in Full mode via the Mailbox 2.0 protocol.
Page 236: 12.2.5.25 As-Interface Master Module
236 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Extended S1/C1 S0/C0 Control/Status byte Control/Status byte MBX0 MBX_C/S Mailbox Mailbox Control/Status byte MBX2 MBX1 MBX4 MBX3 MBX6 MBX5 MBX8 MBX7 MBX10 MBX9 Mailbox MBX12 MBX11 MBX14 MBX13 MBX16 MBX15...
Page 237 WAGO-I/O-SYSTEM 750 I/O Modules 237 750-362 FC Modbus TCP; G4 24 bytes * 32 bytes … 40 bytes … 48 bytes … *) Factory Setting Manual Version 1.0.2...
Page 238: 12.2.5.26 System Modules
238 I/O Modules WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 12.2.5.26 System Modules 12.2.5.27 System Modules with Diagnostics 750-606 The modules provide 2 bits of diagnostics in the Input Process Image for monitoring of the internal power supply. Table 235: System Modules with Diagnostics 750-606, -611...
Page 239: Table 238: Binary Space Module
WAGO-I/O-SYSTEM 750 I/O Modules 239 750-362 FC Modbus TCP; G4 The Binary Space Modules behave alternatively like 2 channel digital input modules or output modules and seize depending upon the selected settings 1, 2, 3 or 4 bits per channel. According to this, 2, 4, 6 or 8 bits are occupied then either in the process input or the process output image.
Page 240: Application Examples
13.2 Visualization and Control using SCADA Software This chapter is intended to give insight into how the WAGO ETHERNET fieldbus coupler/controller can be used for process visualization and control using standard user software. There is a wide range of process visualization programs, called SCADA Software, from various manufacturers.
Page 241 The operation of these programs is very specific. However, a few essential steps are described to illustrate the way an application can be developed using a WAGO ETHERNET fieldbus node and SCADA software in principle: Load the Modbus ETHERNET driver and select Modbus ETHERNET Enter the IP address for addressing the fieldbus node At this point, some programs allow the user to give the node an alias name, i.e.
Page 242: Figure 45: Example Scada Software With Modbus Driver
242 Application Examples WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Example of the Modbus Addressing In the case of SCADA Software Lookout from National Instruments the Modbus function codes are used with a 6 digit coding, whereby the first digit represents...
Page 243: Use In Hazardous Environments
Use in Hazardous Environments 243 750-362 FC Modbus TCP; G4 Use in Hazardous Environments The WAGO I/O SYSTEM 750 (electrical equipment) is designed for use in Zone 2 hazardous areas and shall be used in accordance with the marking and installation regulations.
Page 244: Marking Configuration Examples
244 Use in Hazardous Environments WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 14.1 Marking Configuration Examples 14.1.1 Marking for Europe According to ATEX and IECEx Figure 46: Marking Example According to ATEX and IECEx Figure 47: Text Detail – Marking Example According to ATEX and IECEx Manual Version 1.0.2...
Page 245: Table 240: Description Of Marking Example According To Atex And Iecex
WAGO-I/O-SYSTEM 750 Use in Hazardous Environments 245 750-362 FC Modbus TCP; G4 Table 240: Description of Marking Example According to ATEX and IECEx Marking Description TUEV 07 ATEX 554086 X Approving authority resp. certificate numbers IECEx TUN 09.0001 X Dust...
Page 246: Figure 48: Marking Example For Approved Ex I I/O Module According To Atex
246 Use in Hazardous Environments WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Figure 48: Marking Example for Approved Ex i I/O Module According to ATEX and IECEx Figure 49: Text Detail – Marking Example for Approved Ex i I/O Module According to ATEX and...
Page 247: Table 241: Description Of Marking Example For Approved Ex I I/O Module According To Atex And Iecex
WAGO-I/O-SYSTEM 750 Use in Hazardous Environments 247 750-362 FC Modbus TCP; G4 Table 241: Description of Marking Example for Approved Ex i I/O Module According to ATEX and IECEx Marking Description TUEV 12 ATEX 106032 X Approving authority resp. certificate numbers...
Page 248: Marking For The United States Of America (Nec) And Canada (Cec)248
248 Use in Hazardous Environments WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 14.1.2 Marking for the United States of America (NEC) and Canada (CEC) Figure 50: Marking Example According to NEC Figure 51: Text Detail – Marking Example According to NEC 500...
Page 249: Figure 52: Text Detail - Marking Example For Approved Ex I I/O Module
WAGO-I/O-SYSTEM 750 Use in Hazardous Environments 249 750-362 FC Modbus TCP; G4 Figure 52: Text Detail – Marking Example for Approved Ex i I/O Module According to NEC 505 Table 243: Description of Marking Example for Approved Ex i I/O Module According to NEC 505...
Page 250: Figure 54: Text Detail - Marking Example For Approved Ex I I/O Modules
250 Use in Hazardous Environments WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Figure 54: Text Detail – Marking Example for Approved Ex i I/O Modules According to CEC 18 attachment J Table 245: Description of Marking Example for Approved Ex i I/O Modules According to CEC 18...
Page 251: Installation Regulations
Special Notes including Explosion Protection The following warning notices are to be posted in the immediately proximity of the WAGO I/O SYSTEM 750 (hereinafter “product”): WARNING – DO NOT REMOVE OR REPLACE FUSED WHILE ENERGIZED! WARNING – DO NOT DISCONNECT WHILE ENERGIZED! WARNING –...
Page 252 252 Use in Hazardous Environments WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Explosive atmosphere occurring simultaneously with assembly, installation or repair work must be ruled out. Among other things, these include the following activities • Insertion and removal of components •...
Page 253: Special Notes Regarding Ansi/Isa Ex
WAGO-I/O-SYSTEM 750 Use in Hazardous Environments 253 750-362 FC Modbus TCP; G4 14.2.2 Special Notes Regarding ANSI/ISA Ex For ANSI/ISA Ex acc. to UL File E198726, the following additional requirements apply: • Use in Class I, Division 2, Group A, B, C, D or non-hazardous areas only •...
Page 254: List Of Figures
Figure 18: Carrier Rail Contact (Example) ............45 Figure 19: Cable Shield at Ground Potential ............46 Figure 20: Examples of the WAGO Shield Connecting System ......47 Figure 21: Application of the WAGO Shield Connecting System ......47 Figure 22: View FC Modbus TCP; G4 ..............50 Figure 23: Device Supply ..................
Page 255 WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Figure 47: Text Detail – Marking Example According to ATEX and IECEx ..244 Figure 48: Marking Example for Approved Ex i I/O Module According to ATEX and IECEx ....................246 Figure 49: Text Detail – Marking Example for Approved Ex i I/O Module According to ATEX and IECEx ..............
Page 256: List Of Tables
Table 9: Filter Modules for 24 V Supply ............... 40 Table 10: Legend for Figure “Supply Example for Fieldbus Coupler/Controller” . 42 Table 11: WAGO Ground Wire Terminals ............44 Table 12: Legend for Figure “View” ..............51 Table 13: RJ-45 Connector and RJ-45 Connector Configuration ......53 Table 14: Display Elements Fieldbus Status ............
Page 257 WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 46: Node Status Diagnostics – Solution in Event of Error ....... 128 Table 47: Blink code- table for the I/O LED signaling, error code 1 ....131 Table 48: Blink Code Table for the I/O LED Signaling, Error Code 2 ....132 Table 49: Blink Code Table for the I/O LED Signaling, Error Code 3 ....
Page 258 Table 96: Request of Function code FC11 ............167 Table 97: Response of Function Code FC11 ............ 167 Table 98: Exception of Function Code FC 11 ............ 167 Table 99: Request of Function Code FC15 ............168 Table 100: Response of Function Code FC15 ..........168 Table 101: Exception of Function Code FC15 ...........
Page 259 WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Table 146: Register Address 0x2002 ..............188 Table 147: Register Address 0x2003 ..............188 Table 148: Register Address 0x2004 ..............189 Table 149: Register Address 0x2005 ..............189 Table 150: Register Address 0x2006 ..............189 Table 151: Register Address 0x2007 ..............
Page 260 Table 189: 1 Channel Analog Input Modules ............. 207 Table 190: 2 Channel Analog Input Modules ............. 207 Table 191: 2-Channel Analog Input Modules HART .......... 209 Table 192:: 2 Channel Analog Input Modules HART + 6 bytes Mailbox .... 209 Table 193: 4 Channel Analog Input Modules .............
Page 261 WAGO-I/O-SYSTEM 750 750-362 FC Modbus TCP; G4 Tabelle 232:SMI Master Module 753-1630, -1631 in Fieldbus Coupler Mode... 235 Table 233: SMI Master Module 753-1630, -1631 in „Full Mode“ ....... 235 Table 234: AS-interface Master Module 750-655, 753-655 ....... 236 Table 235: System Modules with Diagnostics 750-606, -611 ......238 Table 236: System Modules with Diagnostics 750-610, -611 ......
Page 262 WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 • D - 32385 Minden Hansastraße 27 • D - 32423 Minden Phone: +49 571 887 – 0 Fax: +49 571 887 – 844169 E-Mail: info@wago.com Internet: www.wago.com...

WAGO -I/O-SYSTEM 750 750-362 Manual

Table of Contents

Table of Contents

Notes about this Documentation

Important Notes

System Description

Device Description

Mounting

Connect Devices

Function Description

Commissioning

Configuring Via the Web-Based Management System (WBM)

Diagnostics

Fieldbus Communication

O Modules

Application Examples

Use in Hazardous Environments

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for WAGO WAGO-I/O-SYSTEM 750 750-362

Summary of Contents for WAGO WAGO-I/O-SYSTEM 750 750-362
