Ilsintech Swift F1 Quick Reference Manual

Wind Protector
Power Button
Cursor Buttons
Enter & Menu Button
Battery Indicator Button
Remaining Battery Indicator LED
Battery
Pack
F1-2
Charger
Power Requirements
AC power supply for the specified AC power supply for the specified
•
charger is AC 100-240V, 50-60Hz.
Do not use AC power other than
•
the allowable power indicated.
Do not use a battery charger other
•
than the specified charger provided
with product.
The LED light turns Red→Green→
•
No Light (F1-2 Charger).
Auto shutoff devices are built in the
•
batteries to prevent over arc, over
charge and overload.
When these protection functions
are performed, power is automatically
shutoff.
Body Appearance & How to use Keypad
Auto Stripper
Cleaner
Power Supply
AC-DC
Adaptor
AC Code
• Power Indicator LED
LED light turns:
Red→Green→Yellow
Battery Capacity Check
Remaining battery capacity is
•
displayed on both the top right
corner of the Monitor and the
battery indicator LED
Sleeve Heater
Cleaver with Fiber Chip Collector
Splicer
LCD Monitor
Battery Pack
USB Port
Charging the Battery
When charging, LED light blinks
•
Green→Yellow.
Full charging the batteries take
•
approx. 2 hours.
DC DC Adaptor (Option) DC-DC Adaptor (Option)
Connect the DC cord of the charger to
•
Adaptor.
DC adaptor charged while operating
•
and plugged.
Only one Plug-in (Right Side Adapter)
•
Contact : Contact : sales@ilsintech.com sales@ilsintech.com
Swift F1
Quick Reference Guide
Reset / Return Button
Auto Stripper Button
(Start Heating)
Arc Button
(Start Splicing)
Sleeve Heater Button
(Start Heating)
Esc Button
Red→
/ +82- - 42 / +82 42- - 671 671- - 5609~11
DC-DC
Adaptor
5609~11
