INSTALLATION INSTRUCTIONS
ARCHIVE 1.6 gpf/6 Lpf One-Piece Toilet
Model 97920-60
ARCHIVE 1.28 gpf/4.8 Lpf One-Piece Toilet
Model 97920-28
CHAPEAU 1.6 gpf / 6 Lpf One-Piece Toilet
Model 97820-60
CHAPEAU 1.28 gpf / 4.8 Lpf One-Piece Toilet
Model 97820-28
PORCHER SOLUTIONS
Model 96010-60
PORCHER SOLUTIONS
Model 96010-28
Thank you for selecting Porcher - the benchmark of fine quality. To ensure this product is installed properly,
please read these instructions carefully before you begin. (Certain installations may require professional help.)
Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
RECOMMENDED TOOLS AND MATERIALS
Regular Screwdriver
Wax Ring/Gasket
1
REMOVE OLD TOILET
a. Close toilet supply valve and flush tank completely. Towel or sponge remaining water from tank and bowl.
b. Disconnect and remove supply line. NOTE: If replacing valve, first shut off main water supply!
c. Remove old mounting hardware, remove toilet and plug floor waste opening to prevent escaping sewer gases.
d. Remove closet bolts from flange and clean away old wax, putty, etc. from base area.
NOTE: Mounting surface must be clean and level before new toilet is installed!
Product names listed herein are trademarks of Porcher
© Porcher 2010
™
1.6 gpf / 6 Lpf One-Piece Toilet
™
1.28 gpf /4.8 Lpf One-Piece Toilet
Adjustable Wrench
Flexible Supply Tube
Putty Knife
Sealant
Closet Bolts
Hacksaw
Carpenters Level
Tape Measure
7301361- 100 Rev. D
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Porcher ARCHIVE Series
- Page 1 1.28 gpf /4.8 Lpf One-Piece Toilet Model 96010-28 Thank you for selecting Porcher - the benchmark of fine quality. To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
-
Page 2: Roughing-In Dimensions
The second suggested position is next to the toilet. Between these two positions the space for the supply between wall and toilet is limited to 3-1/4". In this case, check your supply and hose dimensions. PORCHER SOLUTIONS ™ 1.6 gpf / 6 Lpf One-Piece Toilet Model 96010-60 ™... - Page 3 CLOSET FLANGE OPENING TAPERED WASHER CLOSET BOLTS FLANGE CLOSET SEALANT BOLT WAX RING POSITION TOILET ON FLANGE INSTALL WAX SEAL INSTALL CLOSET BOLTS Unplug floor waste opening and install toilet on closet Invert toilet on floor (cushion to prevent Install closet bolts in flange flange so bolts project through mounting holes.
-
Page 4: Troubleshooting
Do not use in-tank cleaners. These products can seriously damage fittings in the tank. WARNING: This damage can cause leakage and property damage. Porcher shall not be responsible or liable for any damage caused by the use of in-tank cleaners. TROUBLESHOOTING IF FILL VALVE SHUTS OFF BUT CONTINUES TO LEAK SLOWLY, repeat Step 12. -
Page 5: Repair Parts List
This warranty shall be void if the product has been moved from its initial place of installation; if it has been subjected to faulty maintenance, abuse, misuse, accident or other damage; if it was not installed in accordance with Porcher's instructions; or if it has been modified in a manner inconsistent with the product as shipped by Porcher.
