DGS Real Life Ninja Starter Pack 1 Assembly Instructions Manual

DGS - 17 Lucienne Ave. Danielson, CT 06239 - 800-932-3339 - info@gymsupply.com
Please visit gymsupply.com for product assembly videos.
Real Life Ninja Starter Pack 1
Assembly Instructions
MATERIALS:
Warped Wall
3 - Main Sections (Only 2 Sections for 10' Warped Wall)
8 – 3" deck screws for joining sections inside of Warped Wall
2 – Rock Wall Panels (with pre-installed t-nuts. Top panel comes with ladder mounting block pre-
installed.)
2" Deck Screws for securing Rock Wall Panels
4 - wedge bolts
Monkey Bars
2 – 13ft. Side Rails, 13 – 4ft. Rungs, 1 - Wooden Lift Support
26 – 3/16" Allen head bolts
Four ½" x 4" Bolts with Flat and Lock Washers (Monkey Bar to Warped Wall)
Eight 3/8"x 2 ¼" Bolts with Flat and Lock Washers (Monkey Bar to Salmon Ladder)
Salmon Ladder
1 – Header Board
2 – Uprights, 4 - Wedge Bolts
26 - Pegs
4 – 3/8" x 4" Carriage Bolts with Flat and Lock Washers
1 – Bar
2 – Pulley Rigs for Top of uprights with 20 - 1 ½" drywall screws for mounting to top of uprights
2 – Weights with rope
2 – Post Pads with 16 - 2" Deck Screws
Pegboard
1 – Pegboard with 4 - 12" Pegs
1 – Pegboard Spacer Block (Pegboard to Warped Wall)
3 – ½" x 10" bolts with flat and lock washers (Pegboard to Warped Wall)
1 – Pegboard Mounting Plate (For Pegboard to Salmon Ladder)
3 - 1/2" x 3 1/2" Carriage Bolts with flat washers, lock washer & nuts (Pegboard to Mounting Plate)
3 – 3/8" x 6" bolts with 2 flat washers & locking nut (For Pegboard Mounting Plate to Salmon Ladder)
