SERVICE DROP-IN REFRIGERATED SELF-SERVICE MERCHANDISER

DO3616R

Model DO2412R.4909

Model DO3616R

Model DO4816R

Note 1. Internal counter height must be at least 28" for refrigeration and proper air flow space.

Note 2. Model DO3637R & 3623R: Service Top Cutout dimensions must be 27.15" Wide x 36.65" Long (with a

minimum 1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated Merchandiser. These combined

dimensions require a 30" minimum counter top space for cutout.

Note 3. Model DO4837R & DO23R: Service Top Cutout dimensions must be 27.15" Wide x 48.65" Long (with a

minimum 1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated

Merchandiser. These combined dimensions require a 30" minimum counter top space for cutout.

I:\Oper Manuals\Impulse_DO2412R-4909_DO3616R_DO4816R Manual_54167.pub

READ AND SAVE THESE INSTRUCTIONS

INSTALLATION &

OPERATING MANUAL

24"L x 28 5/8"D x 12 1/4"H (Upper Display Case Only)

38 1/8"L x 28 5/8"D x 16 7/8"H (Upper Display Case Only)

38 1/8"L x 28 5/8"D x 40 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)

50 1/8"L x 28 5/8"D x 16 7/8"H (Upper Display Case Only)

50 1/8"L x 28 5/8"D x 40 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)

DO4816R

888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com

DO3616R

P/N 54167

DO4816R

DO2412R.4909

Rev K Date: 10.15.2019
