- Page 1 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Paris500 Cutting Machine Register now and benefit! Jetzt Registrieren und Profitieren! www.smart-iwm.com...
- Page 2 VECTOR DIGITAL – We optimize the quality and prices Looking to the future, sustainability, environment friendly and high on the customer-oriented WARNINGS competence - the key words to which we are responsible. For this reason, we develop our own powerful brand VECTOR . Read and understand this entire Manual and your employer’s safety In VECTOR welding equipment combines advanced inverter technology,the highest practices before installing, operating ,or servicing the equipment.
-
Page 3: Table Of Contents
CUTTING SERIES EQUIPMENT Safety instructions Safety instructions WARNING 1.1 Arc welding damage--------------------------------------------------------------01-04 1.2 Effects of low frequency electric and magnetic fields----------------------- 04-04 PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACEMAKER WEARERS KEEP AWAY UNTIL CONSULTING 1.3 Symbol chart------------------------------------------------------------------------ 05-05 YOUR DOCTOR. - Page 4 CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Safety instructions Safety instructions 6. Be aware that welding on a ceiling, floor, bulkhead, or partition can cause fire on the hidden side. 7. Do not weld on closed containers such as tanks or drums. ARC RAYS can burn eyes and skin, WARNING 8.
-
Page 5: Effects Of Low Frequency Electric And Magnetic Fields
CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Safety instructions Safety instructions 1.3 Symbol Chart Note that only some of these symbols will appear on your model. WARNING MOVING PARTS can cause injury. Moving parts, such as fans, rotors, and belts can cut fingers and hands and catch loose clothing. -
Page 6: Brief Introduction
Welding Power Source must idle and be allowed to cool. be cut off. It can self-protect and prolong the using life. 2.2 Specifications Description SIWM DIGITAL Paris500 7.1 kg Weight Power Source Dimensions H320mmxW/160mmxD380mm... -
Page 7: Layout For The Panel
CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Operation Operation 3.1 Layout For The Panel Behind Front... -
Page 8: Installation Instructions
CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Operation Operation 10. Program downloading port DO NOT TOUCH the electrode wire while it is Change the program downloading connection port, and use the plastic cover to prevent being fed through the system. The electrode the dust from polluting and oxidizing the port after use. - Page 9 CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Operation Operation Air regulator installation and operation 11. Connect air to regulator and adjust regulator to deliver 5-6 bar 90ltr/min 12. Switch the unit on using the main switch located on the back side. 1.
-
Page 10: Troubleshooting
CUTTING SERIES EQUIPMENT CUTTING SERIES EQUIPMENT Troubleshooting Troubleshooting Solution 4.1 Troubleshooting Troubles Reasons Inspect torch parts and replace Torch parts broken if necessary ◆Before arc welding machines are dispatched from the factory, they have already been debugged When torch is accurately. -
Page 11: Maintenance
CUTTING SERIES EQUIPMENT Maintenance 5.1 Maintenance In order to guarantee that arc welding machine works high-efficiently and in safety,it must be maintained regularly.Let customers understand the maintenance methods and means of arc welding machine more, enable customers to carry on simple examination and safeguarding by oneself,try one’s best to reduce the fault rate and repair times of arc welding machine, so as to lengthen service life of arc welding machine.Maintenance items in detail are in the following table.
