Summary of Contents for Marecoluce Stud Solar
- Page 1 Stud Solar Pag. 3 installation of the fitting Challenge Solar Pag. 4 installation of the fitting Electronic circuit board Pag. 6 Deva Solar and Stud Solar Programming Pag. 7 Deva Solar Programming Pag. 8 Stud Solar Programming Pag. 9...
-
Page 2: Installation Of The Fitting
DEVA SOLAR Installation of the fitting Electronic circuit board pre-installed and factory set (for programming modes see pag.6-7) 2.5 Nm To facilitate the installation Mareco Luce recommends to connect the luminaire and the pole-top to the pole first, and then to fix the pole to the ground. - Page 3 Clamp mark N Neutral wire Clamp mark T Ground wire Movement sensor: Stud Solar 1/2 is pre-set for the connection of the remote sensor through a terminal block placed inside the electrical compartment. The sensor must be in "clean contact" with a supply...
- Page 4 CHALLENGE SOLAR Installation of the fitting 24LL Electronic circuit board pre-installed and factory set (for programming modes see pag.8-9-10) 2.5 Nm 0.8 Nm 2.5 Nm 0.8 Nm 2.5 Nm User's manual...
- Page 5 To facilitate the installation Mareco Luce recommands to connect the luminaire and the pole-top to the pole first, and then (12) to fix the pole to the ground 2.5 Nm (11) Untighten the screws (1a and 1b) and remove the DX (2) part of the luminaire.
- Page 6 Electronic circuit board (ECB) Deva Solar Factory standard programming: SMART MODE operating mode with on at sunset for 8 hours and a battery duration of 5 nights; the luminosity for the grid connection is set at 100% and the time for the movement sensor is set to 2 minutes.
- Page 7 Electronic circuit board (ECB) Stud Solar Factory standard programming: SMART MODE operating mode with on at sunset for 8 hours and a battery duration of 3 nights (the luminosity for the grid connection is set at 100% and the time for the movement sensor is set to 2 minutes.
- Page 8 Programming Deva Solar Factory standard programming: SMART operating mode with on at sunset for 8 hours and a battery duration of 5 or 8 nights; the luminosity for the grid connection is not set at 100% and the time for the movement sensor is set to 2 minutes. switch 2 switch 1 Dip 1-Battery duration (SMART mode)
- Page 9 Programming Stud Solar Factory standard programming: SMART operating mode with on at sunset for 8 hours and a battery duration of 2 or 3 nights; the luminosity for the grid connection is not set at 100% and the time for the movement sensor is set to 2 minutes.
- Page 10 Electronic circuit board (ECB) Deva Solar and Stud Solar ECB warnings Led1 Power supply to electronic circuit is ok (from either the panel or the battery). By removing either the panel wire or the battery wire it is possible to verify from where the power is being supplied.
- Page 11 Electronic circuit board of Challenge Solar Max. module input short 15 A circuit current at 50°C Max. load output 15 A current at 50°C System voltage 12 V Ambient temperature -25°C / +50°C allowed Max. voltage of 47 V DC Solar panel Temperature compensation -4mV/K/Cell...
- Page 12 Electronic circuit board Challenge solar – Operating status LED indicators LED displays Status Meaning illuminates green Normal operation Info LED Flashing red Indicates a fault (see "Faults and remedies") Flashing quickly Battery state of charge ≥30% <40% Red LED Activation of deep-discharge protection Flashing state of charge <30% Illuminates...
- Page 13 Faults and remedies Challenge Solar Fault Cause Remedy Info LED Charging interrupted due to - Charging automatically continues as soon as the charging flashing red excessive charging current current lies back to the permissible range Luminaires output is switched off - Check the luminaires due to battery overvoltage - Disconnect the lumiaires...
-
Page 14: Cleaning The Panel
Cleaning the panel • The accumulation of dirt on the transparent cover of the panel reduces the efficiency. • The frequency of the cleaning depends directly on how quickly dirt is accumulated. • We recommend to clean the panels 2 times per year. •... - Page 15 WARNINGS & WASTE DISPOSAL IT IS FORBIDDEN TO MODIFY THE FITTING WITHOUT AUTHORISATION • Any tampering of the luminaire will render the warrantee void, and may render the product dangerous. •The installation and programming of the product conducted by qualified personnel. •...
- Page 16 47032 Bertinoro (FC) Italia Via S.Croce, 121 (z.i) tel. +39 0543 4687 fax +39 0543 449051 info@marecoluce.it marecoluce.it...
