Summary of Contents for NEXGEN NXG08
- Page 1 WIFI & WIRELESS USER MANUAL NEXGEN NXG088 WRF Wireless WIFI Thermostat including Floor Sensor and free App.(optional) Info@nexgenheating.com| www.nexgenheating.com...
-
Page 2: Table Of Contents
Contents NXG088RF WIFI Wireless Thermostat User Manual Technical Data Home screen Quick Operation Time Setting Holiday Mode Setting Programmable Mode Setting Advanced Setting Setting IP Code Receiver indicator light Wiring Diagram RISK OF ELECTRICAL SHOCK Please arrange for a professional technician to install this product according to drawings and instructions and disconnect power supply before making any connection. -
Page 3: Nxg088Rf Wifi Wireless Thermostat User Manual
NXG088RF WIFI Wireless Thermostat User Manual NXG088RFWW Firstly scan the below QR or download the “Smart RM” app from the Google play store or Apple store. When the thermostat is powered on: Simply long press the receiver button to match it to the WIFI. -
Page 4: Technical Data
Technical Data Receiver: 230Vac 50/60HZ Range of temperature display: 0~40°C USB power supply/4*AAA Batteries. Transmitter: Please remove batteries when USB power is being used. Display accuracy: 0.5°C Insulating condition: Normal environment Probe sensor: NTC (10k)1% Running program: Set per 1 week as a cycle Contact capacity: 5A/250V(WW);16A/250V(WE) Output:... -
Page 5: Quick Operation
Quick Operation Ref: ICON Description Turn ON/OFF function button 1: Short press the button to switch to automatic mode and manual mode 2: In Power on state, long press the button for 3-5 seconds and you will enter into the programmable setting mode. 3: In Power off state, long press the button for 3-5 seconds and you will enter into the advanced setting mode. -
Page 6: Programmable Mode Setting
Press the button to switch days and temperature and then use the buttons to change the value. Press the button again to confirm all your settings. To exit out of the holiday mode simply press Programmable Mode Setting 6 times period setting: 5+2 days (factory default), 6+1 days, 7 days Long press the button for 3-5 seconds and you will enter into the programmable mode setting. -
Page 7: Setting Ip Code
Ref: Description Range Default Temperature Calibration -9-+9℃ 0.5℃ Switching Differential of 0.5-2.5℃ 1℃ the Built in Sensor Switching Differential of 1-9℃ 2℃ the External Sensor Child Lock 0: half lock 1: full lock 1. 35℃-70℃ Max temperature of the 2. When the setting temperature is lower External Sensor than 35℃... -
Page 8: Receiver Indicator Light
Consider battery usage: RF data updates every 20 minutes. A USB power option can be used, if so please remove the batteries and then follow B05 and B06 operation details within the Setting IP section above. Ref: Setting option Data setting function Default IP code low setting 00-FF... -
Page 9: Wiring Diagram
When powered on: Simply long press the receiver button to match the WIFI. When its in normal ON state this is classed as EZ mode, when its blinking it’s in AP mode and successive blinking means its matching. Wiring Diagram WIFI/Wireless User Manual V1 2019...
