- Page 1 User‘s Manual for Mycusini 3D Food Printer for Private Use For questions please contact us at service@mycusini.com...
-
Page 2: Table Of Contents
4.8.2 Remove cartridge .................. 16 4.8.3 Clean now ..................... 16 4.8.4 Turn off ....................17 Clean ........................17 Cleaning of the stainless steel cartridge ............17 Cleaning of the printing plate ............... 17 For questions please contact us at service@mycusini.com... - Page 3 6.1.2 Extended Cleaning ................21 Create own Objects .................... 22 mycusini-Club ....................22 Produce your own Object from the mycusini Club ........26 More Applications of the mycusini Club ............26 7.3.1 Freehand drawing ................. 26 Trace outlines ....................27 Language Settings mycusini Club ...............
-
Page 4: Basic Information
Basic Information 1.1 General description The Mycusini is an easy-to-use 3D-food-printer for use in private kitchen. It consists of a heatable cartridge holder, which is mounted to a positioning unit and operated via internal monitor. The x and y axis are controlled by a tooth belt, while the z axis and the extruder are set into motion by threaded rods. -
Page 5: Technical Data Mycusini
100-240 VAC; 50 – 60 Hz • Power (DC) 12 V; 5 A; 60W Protection Short circuit / Overload / Over voltage / Over • temperature Software / Connectivity • Interface Display • Connectivity Micro SD-card, USB-B For questions please contact us at service@mycusini.com... -
Page 6: Main Components
5. SD-Card slot 6. Rotary control knob Reset knop 1.4 Schematic overview Y-Axis Z-Axis Choco 3D Printer Sketch with axis label Maximum space: X 250 mm; Y 250 mm; Z 300 mm X-Axis For questions please contact us at service@mycusini.com... -
Page 7: Qualification Of Personnel
WARNING! Danger from moving parts – keep fingers and other body parts away. This symbol indicates the risk of injuries which may occur if the user reaches into the machine during operation. Body parts may be smashed, drawn in, or injured in other ways. For questions please contact us at service@mycusini.com... -
Page 8: General Safety Instruction For The Machine
Warning: Never leave the Mycusini unattended in use Warning: High temperatures may develop in the printing head of the Mycusini. For this reason, never grasp the printer while in operation. Change the food cartridge only after the printer has cooled down sufficiently Warning: The power supply plug must always be in vicinity of the printer and easily be reachable. -
Page 9: Setup, Location Of Operation
3.3.2 Setup, location of operation Place the Mycusini on a stable, horizontal, large enough area only. Please note, that the production plate moves from right to left when operating and thus requires enough space. In addition, some movement also occurs vertically. When selecting operating location, please ensure that the device may move in these directions. -
Page 10: Use In Accordance With Regulations
Please retain all original packaging as well as all shipping and handling material. This is the only way to assure a successful and safe transport of the mycusini, for instance in the case of a return under warranty! -
Page 11: Liability And Guarantee
The user’s manual has to be stored in the vicinity of the device and within reach of all people working on or with the device. The manufacturer reserves the exclusive right to make technical changes to the product in order to improve the operating characteristics and develop the device. For questions please contact us at service@mycusini.com... -
Page 12: Description Of The Functions And Operation Of The Machine
Description of the Functions and Operation of the Machine 4.1 Mycusini and accessories Mycusini Checklist Mycusini 3D Printer Power Supply SD card with USB adapter Flexible mat Cartridge Tweezer 4.2 Overview Main Screen Level indicator Current temperature Info For questions please contact us at service@mycusini.com... -
Page 13: The Main Menu
4.3 The main menu Press the control knob to get to the main menu. In the main menu you will find various options. For more information, take a look at the mycusini Club, where you will find video tutorials for the menus. -
Page 14: Loading 3D Choco And Start Printing Production
Please shorten it at the open edge. Preheating starts automatically When preheating is finished you Choose your object by rotating may choose your object from the the rotary control knob and SD card. confirm by pressing it. For questions please contact us at service@mycusini.com... -
Page 15: Remove 3D Objects From The Flexible Mat
1. Wait till the object has cooled down and turned solid. 2. Remove the flexible mat. 3. Slightly bend the mat to remove your printed mycusini Choco object. 4. Clean the surface of the flexible mat (washable) in order to use for the next time. -
Page 16: Remove Cartridge
Select: "No" to return to the main menu 4.8.3 Clean now Select "Clean now" if you want to clean the mycusini. Detailed instructions can be found on the next page under point 5. Cleaning. For questions please contact us at service@mycusini.com... -
Page 17: Turn Off
4.8.4 Turn off If you want to switch off your mycusini, please select "Turn off" Select "Turn off" to switch your mycusini off Turn off ? Select: "Yes" to turn off Refill R█EFI 11 % mycusini Next action: ►... -
Page 18: Cleaning Of The Stamp
“Cleaning done” Wait till it stops moving. and continue with “Closed” if you finished cleaning Clean the stamp now Close cartridge holder Stamp is moving up ► Cleaning done ► Closed For questions please contact us at service@mycusini.com... -
Page 19: Extended Cleaning Of The Stamp
Extended Cleaning >> 6.1.1 Insert Stamp This menu allows you to move the stamp upwards should it not have gone all the way up in one of your previous steps or has been completely removed. For questions please contact us at service@mycusini.com... -
Page 20: Info
6.1.1 Calibrate Your mycusini is adjusted for printing with mycusini 3D Choco. If you notice, that the tip of your cartridge is too low or too high during the first layer of printing, you may calibrate it using the "Calibrate" menu. With this service menu you may reset or adjust the tip to the printing area. -
Page 21: Extended Cleaning
Choose „Calibrate“ Click "Yes" when you In the interior of the mycusini is want to start the calibration located, at the rear left, a set screw. By turning this screw the distance of the cartridge tip to the production plate can be adjusted. -
Page 22: Create Own Objects
Open your browser, preferably Chrome, and type www.mycusini.club in the search bar. • Now you can enter your login information and access the mycusini Club. • If you haven’t logged in yes, please register under "register here" For questions please contact us at service@mycusini.com... - Page 23 Important! Always use the Google Chrome browser to log in to the mycusini club, otherwise errors may occur. • For the Registration you need your E-Mail Adress and the Serial number of your mycusini • You can find the serial number at the back of your mycusini...
- Page 24 If you want to generate multiple texts press "insert this text" and write your second text. Press "insert this text" again to add the second text. • You may change the position of the text with the arrow keys on the screen For questions please contact us at service@mycusini.com...
- Page 25 • when you click "Reflect", you may reflect your message • If you are happy with your object, confirm with "Next". • Now create a name (no special characters). For questions please contact us at service@mycusini.com...
-
Page 26: Produce Your Own Object From The Mycusini Club
• Click "Continue". You will get back to the homepage of the mycusini club. • If you like to download your 3D object onto your micro-SD-card, you can press the arrow beneath Download • In this case, the file will be automatically downloaded in the “Download” folder and you may save your 3D object manually onto your micro-SD-Card. -
Page 27: Trace Outlines
In the Trace Outlines application, you may upload an image and use it as drawing template. 7.5 Language Settings mycusini Club • Open the settings tab on the upper right side of the main menu to change the language settings For questions please contact us at service@mycusini.com... -
Page 28: Notifications
After several minutes no movement of the printer occurs, the user interface, however, is visible on the computer/laptop/tablet: • Switch off the mycusini, wait at least 20 seconds and turn it back on. Despite an audible movement of the motor and the fill level display, there is no food coming out of the dosing tip: For questions please contact us at service@mycusini.com... -
Page 29: Returning Old Devices
• Be sure to safely remove the micro SD card • Put the micro SD card in the designated slot. Then switch on the mycusini If the fault continues to occur even after following the instructions, switch off the device. Please contact our customer service at service@mycusini.com... - Page 30 Liebigstraße 11 85354 Freising Germany www.mycusini.com We hope you have a great time with your mycusini and look forward to hearing your feedback, comments, and creative ideas. Your mycusini-Team Please think of the environment before printing this manual? For questions please contact us at service@mycusini.com...
