Summary of Contents for XtendLan TESTMON351-UL
- Page 1 TESTMON351-UL 3.5” TFT VIDEO / AUDIO & CABLE TESTER USER’S MANUAL...
- Page 2 CONTENTS Purpose ........................2 System specification ....................2 Product Outlook ......................3 Key pad description ....................4 Function item and description..................4 OSD function items and description................4 Coaxial cable test function..................4 8. CAT.5 cable test function……………………………………………………..…………..….5...
- Page 3 1. Purpose: This product can receive the standard NTSC/PAL signal and measure the coaxial cable and CAT.5 quality to display on the 3.5” TFT – LCD 2. System specification: Item Specification Panel Size 3.5 INCH DIAGONAL COLOR TFT Resolution 480(H)x234(H) Dot Active Area 72.00(W)x50.544(H)mm Dot Pitch...
- Page 4 3. Product Outlook: TOP VIEW FRONT PANEL Product Outlook...
- Page 5 4 Key pad description: Key name Function Function select (Camera OSD control、Coaxial tester、CAT.5 tester) MODE Volume increase\ Item select DOWN Volume decrease \ Item select LEFT Screen mirror \ Value decrease RIGHT Screen upside-down \ Value increase EXIT Withdraw setting Keypad definition 5 Function items and description FUNCTION ITEM...
- Page 6 ITEM VALUE CABLE QUALITY 0~30Ω SHORT 30~150Ω GOOD 150Ω~∞ OPEN 8 CAT.5 cable test function ITEM CABLE QUALITY DESCRIPTION OPEN Open loop will appear. SHORT Wire short in same pair will appear All of the RJ45 pins correct. REVERSE When 2 wires in the same pair opposite will appear ERROR Any wire of different pairs short will appear.
