GF_VEDO EL35CT-EL57CT INSTALLATION AND OPERATION MANUAL Code 80951C / Edition 04 - 03-2010 GENERAL INDEX page page Graphic symbols used Preliminary instructions Connection Examples General description Preliminary warnings Summary of Characteristics Installation and Connection Technical-Commercial information Electrical power supply Order code Notes concerning electrical safety and Electromagnetic compatibility Instrument power supply... -
Page 2: Graphic Symbols Used
Gefran S.p.A. does not issue any type of guarantee with regard to this manual, including but not limited to implicit guarantees of marketability and suitability for a defined purpose. -
Page 3: Preliminary Instructions
......(Software version) ce", and if necessary refer to the F.A.Q. Section (Fre- • Check that the terminal is in perfect condition and was quently Asked Questions) on the Gefran Web Site not damaged during shipment. Make sure that the pac- www.gefran.com kage also contains the fastening accessories. -
Page 4: Installation And Connection
2 • INSTALLAZIONE e COLLEGAMENTO This section contains the instructions necessary • if the terminal is used in applications with risk for correct installation of the terminals into the of damage to persons, machinery or materials, it is machine control panel or the host system and essential to connect it up to auxiliary alarm for correct connection of the controller power equipment. -
Page 5: Instrument Power Supply
- the voltage between neutral and earth must not be >1V - the resistance must be < 6Ω; • If the mains voltage fluctuates strongly, use a voltage GEFRAN S.p.A. declines all responsibility for any stabilizer. damage to persons or property caused by tampe- •... -
Page 6: Dimensions
Dimensions All measurements are expressed in mm, with tolerance of ± 0.5. GF_VEDO EL35CT dimensions Fig. 1 - Dimensions and cut-out GF_VEDO EL35CT 3 max 90,5 12,9 66,9 GILOGIK II modules (optional) Fig. 2 - Dimensions GF_VEDO EL35CT 80951C_MHW_GF_VEDO EL35CT-EL57CT_03-2010_ENG... - Page 7 GF_VEDO EL57CT dimensions Fig. 3 - Dimensions and cut-out GF_VEDO EL57CT 3 max 88,5 GILOGIK II modules BUS-G GF_VEDO 57CT Fig. 4 - Dimensions GF_VEDO EL57CT 80951C_MHW_GF_VEDO EL35CT-EL57CT_03-2010_ENG...
-
Page 8: Fixing
Fixing Panel mounting GF_VEDO EL35CT and GF_VEDO EL57CT panels are designed for front panel installation. After making the opening shown on the template drawing, fasten the terminal with the blocks required and supplied with the product. Fig. 5 - Panel mounting GF_VEDO EL35CT Fig. - Page 9 To maintain IP65 protection level during panel installation, pay attention to the following points: • make the edges of the hole for the panel perfectly smooth and flat • tighten each fastening screw The terminals also have an O-Ring inserted at the rear of the display frames. Fig.
-
Page 10: Technical Specifications
3 • TECHNICAL SPECIFICATIONS 3.1 Display 35CT: 3.5” color LCD TFT (Thick Film Transistor) display 57CT: 5.7” color LCD TFT (Thick Film Transistor) display 3.2 CPUs and Memories The terminals are equipped with EP9307 processors with ARM9 core. Memories: 64MB FLASH mass, 64MB DRAM system, 256KB cache. 3.3 Supported Operating Systems The terminal is supplied with the operating system Linux 3.4 Keyboard... -
Page 11: User Connections
3.5 User connections The user connections specified on Table 4 are made at the bottom by means of Gefran standard and custom con- nectors. Fig. 9 - GF_VEDO EL35CT connector Fig. 10 - GF_VEDO EL57CT connector Name Description CANopen Reserved for future use... -
Page 12: Power Supply Port
3.5.1 Power supply port The internal power supply (24Vdc, -15% +20%) is galvanically isolated and protected against polarity reverses and short circuits. The panel has a power terminal. The connector diagram is shown in Figure 11. Note: check that the power supply is able to deliver the power needed for correct operation of the device. The device must always be grounded. -
Page 13: Rs-485 Port
3.5.2 RS-485 port The terminal uses the RS-485 port to dialog according to OSI specifications at the physical level defined by stan- dard EIA-485. The RS-485 port is optically isolated and allows dialog from 9.6 kBaud to 115 kBaud via an RJ10 4p4c connector (Registered Jack type 10 with 4 positions and 4 contacts). -
Page 14: Usb Port
3.5.4 USB port The USB port dialog via USB (Universal Serial Bus) serial communication standard. The terminals support version USB 2.0. The USB port connector is type USB-A (4 pins). Signal assignment is shown in Table 7. Voltage for VBUS is +5V with maximum current of 500mA. Signals D+ and D- refer to the two (pseudo) differential data communication lines. -
Page 15: Battery
3.5.7 Battery The terminals contains a 3V 65mA/h rechargeable lithium battery to maintain data in static RAM and to run the clock when the terminals are not powered by the grid. The battery can be enabled or disabled on the model GF_VEDO EL57CT by inserting a jumper in the appropriate position. -
Page 16: Expansion
3.6 BUS-G expansion Bus The BUS-G expansion lets you use the L-BUS4 back-plane. L-BUS4 module (optional) This module has to be ordered separately. It is a 4-slot back-plane that supports a maximum of 4 GILOGIK II I/O modules. Run the following procedure after this module is installed: •... - Page 17 Fig. 22 - L-BUS4 mounting on GF_VEDO EL57CT Fig. 23 Ground connection on GF_VEDO EL35CT 80951C_MHW_GF_VEDO EL35CT-EL57CT_03-2010_ENG...
- Page 18 Fig. 24 Ground connection on GF_VEDO EL57CT Fig. 25 Assembling GILOGIK II modules Fig. 26 Disassembling GILOGIK II modules 80951C_MHW_GF_VEDO EL35CT-EL57CT_03-2010_ENG...
- Page 19 Wiring the module Tools needed: screwdriver with max. 2.5 mm blade. All of the connectors to wire are screwless. The wires are attached and removed as follows: 1. expose the wire to be connected 2. insert the screwdriver in the slot 3.
-
Page 20: Connection Examples
4 • CONNECTION EXAMPLES Example 1 [HMI] GF_VEDO EL35CT Company Ethernet Modbus RTU Example 2 [HMI] GF_VEDO EL57CT Modbus RTU Example 3 [HMI] GF_VEDO ML104CK [HMI] GF_VEDO EL35CT Modbus TCP/IP 80951C_MHW_GF_VEDO EL35CT-EL57CT_03-2010_ENG... -
Page 21: Summary Of Characteristics
5 • SUMMARY OF CHARACTERISTICS Model GF_VEDO EL35CT GF_VEDO 57CT Power supply Power supply 24Vdc, ±25% (3-pin screw-type female connector) Max consumption without integrated I/O 240mA, 5W 480mA, 8,5W with integrated I/O 360mA, 7W 490mA, 9W Protection Against reversed polarity Against reversed polarity and overcurrents on input circuit Battery... -
Page 22: Technical-Commercial Information
As stated in the Preliminary Warnings of these Instructions for Use, correct interpretation of the Controller order code allows the hardware configuration for the controller to be identified immediately and so it is essential to quote the order code each time the Gefran Customer Care Service is contacted for assistance with any problems. Order code...
