LPC P-cap Series User Manual
Panel PC, Intel® Braswell Celeron®3160, IP65 Compliant
Published in Taiwan
Release Date : Oct 2017
Revision : V1.0
Warning!
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in
accordance with the instructions manual, it may cause interference to radio communications. It has
been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules,
which are designed to provide reasonable protection against such interference when operated in a
commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures may
be required to correct the interference.
Electric Shock Hazard – Do not operate the machine with its back cover removed. There are dangerous
high voltages inside.
Bezel & Wide Range Power Input
Advertisement
Table of Contents
Summary of Contents for EL GENS LPC P-cap Series
- Page 1 LPC P-cap Series User Manual Panel PC, Intel® Braswell Celeron®3160, IP65 Compliant Bezel & Wide Range Power Input Published in Taiwan Release Date : Oct 2017 Revision : V1.0 Warning! This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications.
-
Page 2: Packing List
◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 3: Table Of Contents
3 . 9 S a v e & E x i t ............5 4 ELGENS CO., LTD LPC P-cap Series User Manual... - Page 4 5.4 Graphics Driver Setup……………………..……..………………….…………..……65 5.5 LAN Driver Setup............…… 67 5.6 SIO Driver Setup............…… 69 5.7 TXE Driver Setup............…… 71 5.8 USB3.0 Driver Setup............…… 73 Chapter 6 Touch Screen Driver Installation Appendix WDT sample code ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 5: Getting Started
Getting Started Brief Description of LPC P-cap Series The LPC P-cap series is a power-optimized and delivers robust performance-per-watt for embedded HMI, powered by a Celeron® N3160 Quad Core 1.6 GHz processor. It comes with a mSATA slot and a SATA 2.5-inch hard disk drive, up to 8GB DDR3 memory, audio jack, 2 Ethernet, DC input, and 4 USB 3.0 ports. - Page 6 19" P-cap Panel PC, Celeron® N3160, 1024 x 768 Reso, 420 nits LED LPC-P190S backlight, 4 COM, 4 USB, 2 LAN, DC 9~36V with 3-pin Power Terminal Block LPC-P215W 21.5" P-cap Panel PC, Celeron® N3160, 1920 x 1080 Reso, 250 nits LED ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 7: Dimension
B = Power Board for Input on board fuse Input reverse protection Over current Output short circuit protection V = Vandal Proof Glass T = Backside Heatsink for Operating Temperature 60°C Dimension ELGENS CO., LTD LPC P-cap Series User Manual... - Page 8 LPC-P121S-01 Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 9 LPC-P150S Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 10 LPC-P156W / 156W-01 Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 11 LPC-P170S Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 12 LPC-P173W Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 13 LPC-P185W Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 14 LPC-P190S Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 15 LPC-P215W Drawing ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 16: General Rear Io Replacement
1.4 General Rear IO Placement COM 1 is RS-485 as below pin definition, adjustable to RS-422 by BIOS Power input terminal block pin definition is as below. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 17: Front View
1.5 Front View of LPC- Pcap Series ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 18: Rear View
1.6 Rear View of LPC- Pcap Series ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 19: Installation Of Hdd
1.7 Installation of HDD (Below example is LPC-P185W) 1.7.1 Remove screws from below red circles. Notice : below screws located in right and left side should be removed as well. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 20 DRAM is located the bottom side of main board, as a result, we strongly suggest our client to purchasing DRAM from ELGENS in order to save time & labor cost, and avoid the warranty issue. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 21: Chapter 2 Main Board Introduction
Chapter 2 Main Board Introduction 2.1 Mainboard Specification 2.1.1: Mainboard Overview ELGENS CO., LTD LPC P-cap Series User Manual... - Page 22 Mainboard Specifications Board Size 146 mm x 102 mm (3.5-inch size) Processor Intel® Celeron® N3160 Processor Chipset Integrated in SoC Memory Support 1 SO-DIMM slot for single-channel DDR3L 1600MHz Up to 8GB ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 23 2 x RJ45 GbE LAN ports 4 x USB 3.0 ports Software programmable 1 – 255 second by Super I/O Watchdog Timer Operation Temperature 0~60 Degree Humidity 10% - 90%, non-condensing, operating EMI/EMS Meet CE/FCC class A ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 24: Ju Mp E Rs Settin G An D Co N N Ec To
2.2 Jumpers Setting and Connectors Power Supply DC-In Power Connector: JPWR1 This connector is used to provide power to the motherboard. SATA Power Connector: JPW1 This connector is used to provide power to SATA devices. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 25 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Important Please do not fold the SATA cable into a 90-degree angle. Otherwise, data loss may occur during transmission. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 26 This connector allows you to connect the front panel audio and is compliant with Intel Front Panel I/O Connectivity Design Guide. Audio Amplifier Connector: JAMP1 The connector is used to connect audio amplifiers to enhance audio performance. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 27 RS232 Serial Port Connector: JCOM2, JCOM3, JCOM4 This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach serial devices to it through the optional serial port bracket. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 28 RS232/422/485 Serial Port Connector: JCOM1 This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach a serial device to it through an optional serial port bracket. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 29 LVDS jumper to proper power voltage. Important Pin 12 is a detect pin. When using a customized LVDS cable, pin 12 should be asignal ground with a low impedance. Otherwise, LVDS will not function. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 30 Note that the pins of VCC and GND must be connected correctly to avoid possible damage. LPC Debug Port Connector: JLPC1 (With TPM Support) This connector works as LPC debug port and supports TPM modules through an adapter. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 31 You can clear CMOS by shorting 2-3 pin while the system is off. Then return to1-2 pin position. Avoid clearing the CMOS while the system is on; it will damage the motherboard. AT/ATX Select Jumper: JAT1 This jumper allows users to select between AT and ATX power. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 32 LVDS Power Jumper: JVDD1 Use this jumper to specify the operation voltage of the LVDS display. LVDS Inverter Power Jumper: JINV1 Use this jumper to specify the operation voltage of the LVDS inverter. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 33 When adding or removing expansion cards, make sure that you unplug the power supply first. Meanwhile, read the documentation for the expansion card to config- ure any necessary hardware or software settings for the expansion card, such as jumpers, switches or BIOS configuration. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 34: Chapter 3 Bios Setup
The items under each BIOS category described in this chapter are under continuous update for better system performance. Therefore, the description may be slightly different from the latest BIOS and should be held for reference only. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 35 <F1>. The Help screen lists the appropriate keys to use and the possible selections for the highlighted item. Press <Esc> to exit the Help screen. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 36: The Menu Bar
Use this menu to specify your settings for power management. ▶ Save & Exit This menu allows you to load the BIOS default values or factory default settings into the BIOS and exit the BIOS setup utility with or without changes. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 37: M A I
This setting allows you to set the system date. The date format is <Day>, <Month>,<Date> <Year>. ▶ System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. ▶ SATA Mode Selection This setting specifies the SATA controller mode. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 38: A D V A N C E
This item is used to determine the display mode when an optional ROM is initialized during POST. When set to [Force BIOS], the display mode used by AMI BIOS is used. Select [Keep Current] if you want to use the display mode of optional ROM. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 39 You can enable the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 40 ▶ H/W Monitor These items display the current status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds. ▶ Smart Fan Configuration ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 41 This setting enables/disables the Smart Fan function. Smart Fan is an excellent feature which will adjust the CPU/system fan speed automatically depending on the current CPU/system temperature, avoiding the overheating to damage your system. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 42 When disabled, the processor will return the actual maximum CPUID input value of the processor when queried. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 43 This setting enables/disables the onboard audio controller. ▶ Launch OnBoard LAN OpROM These settings enable/disable the initialization of the onboard/onchip LAN Boot ROM during bootup. Selecting [Disabled] will speed up the boot process. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 44 ▶ GPIO Group Configuration ▶ GPO0 ~ GPO3 These settings control the operation mode of the specified GPIO. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 45: B O O
<Enter> to enter the sub-menu. Then you may use the arrow keys ( ↑↓ ) to select the desired device, then press <+>, <-> or <PageUp>, <PageDown> key to move it up/down in the priority list. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 46: S E C U R I T
Security ▶ Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 47 ▶ Security Device Support This setting enables/disables BIOS support for security device. When set to [Disable], the OS will not show security device. TCG EFI protocol and INT1A interface will not be available. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 48 [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen. Besides, all data received from the serial port is interpreted as keystrokes from a local keyboard. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 49 PuTTY is a terminal emulator for Windows. This setting controls the numeric keypad for use in PuTTY. ▶ Redirection After BIOS POST This setting determines whether or not to keep terminals’ console redirection running after the BIOS POST has booted. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 50 The setting enables/disables TXE HMRFPO (Host ME Region Flash Protection Override). ▶ TXE Firmware Update This setting enables/disables TXE FW update. ▶ TXE EOP Message This setting determines whether or not to send EOP (Exchange Online Protection) message before entering ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 51: C H I P S E
Microsoft that includes encryption, output protection and Digital Rights Management (DRM). Window’s PlayReady 3.0 DRM can support 4K content but use more restrictive digital rights management technology to curb illegitimate streams at the same time. ELGENS CO., LTD LPC P-cap Series User Manual... -
Page 52: P O W E
Leaves the computer in the power off state. [Power On] Leaves the computer in the power on state. [Last State] Restores the system to the previous status before power failure or interrupt occurred. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 53 The item allows the activity of the USB device to wake up the system from S3/ S4 sleep state. ▶ RTC When [Enabled], your can set the date and time at which the RTC (real-time clock) alarm awakens the system from suspend mode. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 54: S A V E & E X I
▶ Restore User Defaults Restore the user’s default profile. ▶ Launch EFI Shell from filesystem device This setting helps to launch the EFI Shell application from one of the available file system devices. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 55 Please download “MSI Smart Tool Kits” from the website below: https://drive.google.com/drive/u/0/folders/0B0ap8HaD1zCCOU5sN2cyZ1JMSjQ MSI Smart Tool Kits 1. Click ”Source folder” choose the location of your Windows 7 disc. 2.choose ”USB storage” as bootable USB for your Windows 7 3.Click”Start” 4.Click”YES” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 56 Plug your modified USB to USB 3.0 port, and keyboard Then turn on the LPC series press “Delete” to enter BIOS mode, A-2. In BIOS mode, go to “Boot” page and select “Hard Drive BBS Priorities” A-3. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 57 Then go to “Save & Exit” page choose “Save Changes and Reset” A-5. A-6. Then the Win 7 installation will appear on the screen. Now you can install Windows 7 with your keyboard through USB 3.0. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 58: Chapter 5 Installation Of Drivers
Chapter 5 Installation Drivers 1. Windows 7 Patch Setup 1.1. Go to X:\Win_patch，Choose” NDP451-KB2858728-x86-x64-AllOS-ENU.exe” 1.2. Choose ”Yes” 1.3. Choose”I have read and accept the license tems.” Then Choose ”Install” ELGENS CO., LTD LPC P-cap Series User Manual... - Page 59 1.4. Then press ”Finish” 1.5. Choose 32 or 64 Bit installation file ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 60 1.6. Choose”Yes” 1.7. After installation, choose”Restart Now” ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 61: Chipset Driver Setup
2. Chipset Driver Setup 2.1. Go to X:\Chipset\ and choose” SetupChipset.exe” 2.2. Choose”Next” 2.3. Choose”Accept” ELGENS CO., LTD LPC P-cap Series User Manual... - Page 62 2.4. Choose”Install” 2.5. Choose”Yes”, and wait to complete the installation. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 63: Audio Driver Setup
3. Audio Driver Setup 3.1. Go to X:\Audio\ and choose ”Setup.exe” 3.2. Choose”Yes”, and wait until the installation is completed. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 64 3.3. Choose”Yes, I Want to restart my computer now”, and press”OK” to restart. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 65: Graphics Driver Setup
4.1. Go to X:\Graphics\4277(Win7 8.1 64bit)\win64\ and choose” Setup.exe” according to your OS 32 bits or 64 bits. This SOP is based on Win 7 64 Bit. 4.2. Choose ”Yes” 4.3. Choose”Next”, and then ”Yes” and ”Next” until the installation is completed. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 66 4.4. 點選”Yes, I Want to restart my computer now”後按”Finish”重開機 ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 67: Lan Driver Setup
5. LAN Driver Setup 5.1. Go to X:\ LAN\Install_Win7_7097_11232015\ and choose” Setup.exe” 5.2. Choose”Yes” 5.3. Choose”Next” ELGENS CO., LTD LPC P-cap Series User Manual... - Page 68 5.4. Choose”Install” 5.5. Choose ”Finish” to complete the installation. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 69: Sio Driver Setup
6. SIO Driver Setup 6.1. Go to X:\SIO\1.2.3.0616(Win7)\ and choose ”Intel Processor Win7 IO Drivers 64Bit.msi” according your OS by 32 or 64 Bits. This SOP is based on Win 7 64 Bit. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 70 6.2. Choose ”Next” 6.3. Choose ”I accept the terms in the license agreement” and ”Next”, ”Install”, ”Yes”, ”OK” until the installation is completed. 6.4. Choose ”Finish” to complete the installation. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 71: Txe Driver Setup
7. TXE Driver Setup 7.1. Go to X:\TXE\ and choose ”SetupTXE.exe” ELGENS CO., LTD LPC P-cap Series User Manual... - Page 72 7.2. Choose ”Yes” and ”Next” 7.3. Choose ”I accept the terms in the license agreement” and ”Next” until the installation is completed. 7.4. Choose ”Finish” after the installation. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 73: Usb3.0 Driver Setup
8. USB3.0 Driver Setup 8.1. Go to X:\USB3.0\4.0.3.49\ and choose ”Setup.exe” 8.2. Choose ”Yes” , ”Next” and “Yes” until the installation is completed. ELGENS CO., LTD LPC P-cap Series User Manual... - Page 74 8.3. Choose ”Finish” until the installation is completed. ELGENS CO., LTD LPC P-cap Series User Manual...
-
Page 75: Chapter 6 Touch Screen Driver Installation
Chapter 6 Touch Screen Driver Installation Touch Driver installation for Windows 7 1. Install Touch Driver in DVD ROM 2. Go to file of X:\EETI Touch Driver\eGalaxTouch_5.11.0.9126 , then choose ”setup” (X:\ means DVD location) ELGENS CO., LTD LPC P-cap Series User Manual... - Page 76 3. Choose ”Yes” to start installation 4. Choose ”Next” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 77 5. Choose “Next” 6. Choose “Next” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 78 7. Choose “Next” 8. Choose “OK” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 79 9. Choose “Next”” 10. Choose “Next” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 80 11. Choose “Next” 12. Choose “Next”” ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 81 13. Waif for installation to complete 14. Choose ”Yes” for 4 points calibration ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 82 Please repeat it for next 3 calibration points. It requires totally 4 calibration points for complete touch screen installation. 16. After 4 points calibration, we have completed the touch function installation. ELGENS CO., LTD LPC P-cap Series User Manual...
- Page 83 WDT & GPIO WDT Sample Code SIO_INDEX_Port equ 04Eh SIO_DATA_Port equ 04Fh SIO_UnLock_Value equ 087h SIO_Lock_Value equ 0AAh WatchDog_LDN equ 007h WDT_UNIT equ 60h ;60h=second, 68h=minute, 40h=Disabled Watchdog timer WDT_Timer equ 30 ;ex. 30 seconds Sample code: ;Enable config mode dx, SIO_INDEX_Port al, SIO_UnLock_Value dx, al...
